Maxcom MX-OFSW-2X1 User Manual

Optical fiber 2×1 switch

Advertisement

Quick Links

SUMMARY
The MXOFSW-2X1 is a 2×1 prism optical switch. It will support two optical fibers input and
one fiber output with an auto detect switch. The unit supports a wide operating wavelength
range and a quick switching rate.
The MXOFSW-2X1- has two operational modes:
Manual mode: Through the LCD control interface or via a GUI web interface over a
network, the operator may trigger a switch of the fiber route in real time.
Automatic mode: Automatically detects and switches fiber inputs based on the
parameters set by the operator, or requirement. Example: if input 1 is set to -5 dBm, and if
the input power drops to a level below -5 dBm, the unit will automatically switch to input 2.
The MXOFSW-2X1 is mounted in a 19" rack mount 1U chassis. The LCD is located at the
front panel and provides all operating parameters and the current operator scheme. The
RS232 interface and RJ45 ethernet interface provide remote management and control, as
well as SNMP.
M
X
-
O
F
M
X
-
O
O
p
t
i
c
a
l
F
i
b
O
p
t
i
c
a
l
F
i
b
U
S
E
R
U
S
E
R
S
W
-
2
X
1
F
S
W
-
2
X
1
e
r
2
×
1
S
w
i
t
e
r
2
×
1
S
w
i
t
M
A
N
U
A
L
M
A
N
U
A
L
c
h
c
h

Advertisement

loading
Need help?

Need help?

Do you have a question about the MX-OFSW-2X1 and is the answer not in the manual?

Questions and answers

Summary of Contents for Maxcom MX-OFSW-2X1

  • Page 1 × × SUMMARY The MXOFSW-2X1 is a 2×1 prism optical switch. It will support two optical fibers input and one fiber output with an auto detect switch. The unit supports a wide operating wavelength range and a quick switching rate. The MXOFSW-2X1- has two operational modes: Manual mode: Through the LCD control interface or via a GUI web interface over a ①...
  • Page 2 CONTROLS, INDICATORS, AND ALARMS This section of the manual will give a brief overview of the available menu in the MXOFSW-2X1 series optical switch and their descriptions. All instructions in this Section refer to the representation of the front panel shown in the diagram below. The user may scroll through the menu using the push buttons found on the front panel, these are located just on the right of the LCD screen.
  • Page 3 TH Low Adjustable menu, +10 to -50 dBm. Allows the operator to set the optical power level. While in AUTO, if the optical power falls below this set point, the switcher will automatically switch to the alternate input. An alarm will also be displayed. TH High Adjustable menu, +10 to -50 dBm.
  • Page 4 STANDARD OPERATION METHOD Four indicators on the front panel show which light path is being used. Inputs are represented by 1 and 2 respectively, where 1 is the main input and 2 is the backup input. The main and standby optical paths are automatically switched: The operator may set the Optic Switch Point by adjusting the threshold settings in the menu (TH Low and TH High) * If optical signal powers are both less than switch point power, the device will maintain...
  • Page 5 Supplemental: Web Interface The MX-OFSW-2x1 may be accessed from a web interface using the RJ45 port. The web interface can be viewed using the default IP address 192.168.1.50 The default username is “admin”, and the default password is “admin” The categories will be displayed on the left side of the screen as follows. The right...
  • Page 7 Reference Internal Operation Diagram:...
  • Page 8: Specification

    Front Panel Indicator Lights: Turns Red if Alarm Condition Exists Turns Red if Input 1 Levels fall outside set parameters Turns Red if Input 1 Levels fall outside set parameters Turns off if not power to PS 1 Turns off if no power to PS 2 Specification: *The Active Input routed to the output will blink Performance...
