Summary of Contents for Maxcom MX1X2OS
- Page 1 User manual...
- Page 2 1. Product Overview The MX1x2OS Optical switch is an important device in an optical fiber communications system. It is mainly used as a backup switch of two-way optical signals or multi-way optical signals. When the primary optical channel experiences a fault, it automatically switches to the backup channel, ensuring the system’s continued operation.
- Page 3 ≤ 5 Switching time ≥ 55 Return loss Max input optical power Range of input optical -10 ~ +27 power ≥10 million times Switching life Connector type FC/APC or SC/APC voltage AC160V - 250V（50 Hz） ≤ 2 consumption Operating ℃ -5 - +55 temperature range Max operating...
- Page 4 5.2 back panel explanation 1. Input port of A-channel optical signal. 2. Output port of optical signal. When the equipment is operating normally, there is invisible laser beam emitting from this port, so this port should not be towards to the body or naked eyes, to avoid accidental injury.
- Page 5 Current work channel Work channel in manual mode, press “ok” to set. Switch threshold of auto control mode, when the input power of A-channel is less than this value，the working channel will automatically switch to B. You can press “ok” to set. Wavelength of the system.
- Page 6 Serial number of the machine Version number of the soft system Cumulative working time 2. Press any direction key, and then entrance of alarm menu appears. Now you can press “ok” to enter it. Displayed alarm contents Displayed contents meaning Input optical power alarm of port A.
- Page 7 4：No Connect 5：GND 6：No Connect 7：No Connect 8：No Connect 9：No Connect This equipment’s serial communication uses standard NRZ format, start bit is 1-bit, data bit is 8-bit, stop bit is 1-bit, and the baud rate is 115200. 2) LAN communication interface It uses standard RJ45 connectors;...
- Page 8 key in your PC keyboard to enter the bootstrap program, and create some advanced configuration. The bootstrap program looks like BIOS setup program in PC. In general, there is no need for the user to enter the bootstrap program to set parameters, so we added a password for the bootstrap program to prevent destroying the normal configuration.
- Page 9 The specific usage: help This command is used to display the version number, the program name, and the command list of system. You can also use the “help” command to display help information of other commands. For example, "help ethcfg", then following picture appears: ethcfg It is used to configure the Ethernet parameters, including IP address, subnet mask, and gateway.
- Page 10 As to the usage, you can refer to such command’s help information. trap This command is used to display or modify the IP address list that SNMP trap sends to the host. Trap-l command displays the target server list; trap-m command modifies the target server list, as follows: If the IP address is 0.0.0.0 or 255.255.255.255, it indicates these addresses are non-existent and the SNMP trap will not be sent to these addresses.
- Page 11 Note: 1. In the cleaning process for the optical fiber connector, the connector should not be aimed to the body or eyes, this may cause permanent injury. 2. The force used to install the optical fiber connector must be appropriate, or it may damage the ceramic tube in the adapter.
