Instruction Manual
High Voltage Differential Probe
SS-320

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SS-320 and is the answer not in the manual?

Questions and answers

Summary of Contents for Iwatsu SS-320

  • Page 1 Instruction Manual High Voltage Differential Probe SS-320...
  • Page 2 Ⓒ 2012 IWATSU ELECTRIC CO., LTD. All rights reserved.
  • Page 3: Table Of Contents

    Contents Introduction ··································································· 1 To ensure the Safety Operation ········································· 1 Warnings ······································································ 2 Cautions ······································································· 5 Checking packed materials ··············································· 6 Components ·································································· 6 Management of product ··················································· 7 Repair and sending of repair goods ·································· 7 Cleaning of this product ··················································· 7 Measurement categories ··················································...
  • Page 4 Memo...
  • Page 5: Introduction

    Introduction ◇ Thank you for purchasing the Iwatsu's product. We hope that it can be used for a prolonged period. ◇ We would ask you to thoroughly read this instruction manual before commencing the operation and keep it at a readily accessible location for future reference.
  • Page 6: Warnings

    Detach this product from the thing measured at once, and turn off the power supply of the equipment with which this product is connected, and remove the power plug from the receptacle, and then contact Iwatsu office or our sales distributors for repair. Do not attempt to repair the product yourself.
  • Page 7 Iwatsu office or our sales distributors for repair.
  • Page 8 If not, an electric shock or fire may occur. ● Do not use this product when being failed. If not, an electric shock or fire may occur. For a failure, contact Iwatsu office or our sales distributors for repair. [Read the next page.]...
  • Page 9: Cautions

    If applied, the product may fail, resulting in an electric shock or fire. If you do not have a proper packing or shock-absorbing material for transportation, contact Iwatsu office or our distributors. If transportation is asked to a forwarding agent, display "Including a precision machine" on each side of the packing box.
  • Page 10: Checking Packed Materials

    When receiving this product, check the packed materials referring to components below (for outside appearance, see below). If there is a lacked item or an item damaged during transportation, immediately contact Iwatsu office or our sales distributors. Components  ・・・・・・・・・1 Probe main unit ...
  • Page 11: Management Of Product

    Repair and sending of repair goods If a failure occurs, send the product to Iwatsu office or our sales distributors. When sending a product to be repaired, clearly write the product name, serial number (in the label on the rear of this product), and description of the failure, name, division, and telephone number of responsible person.
  • Page 12: Measurement Categories

    Measurement categories This product has suited IEC61010-031 Ed.1.1 (safety requirement of the probe assembly for an electric measurement and the examination) (Refer to "2.2 Certification") To ensure safe operation of measurement products, IEC61010 -2-30 categorizes the safety standard into CAT II to CAT IV below as measurement categories: CAT II : Primary electrical circuits in equipment connected to a wall outlet via a power cord (portable tools, household appliances,...
  • Page 13: Chapter 1 Overview

    Combination of this probe (SS-320), Iwatsu-recommended oscilloscope, and the probe power supply (PS-25) allows input to 1CH of the oscilloscope to observe the high-voltage differential signals. (For Iwatsu-recommended oscilloscopes, see Appendix 1 at the end of this document.)
  • Page 14: Examples Of Use

    1.2 Examples of use This probe is used in combination with the Iwatsu-recommended oscilloscope and the Iwatsu probe power supply (P25) as shown in the examples (images) of use (1) and (2) below. (1) Example of combination of Iwatsu ViewGo II main unit and probe...
  • Page 15: Appearance Of Probe

    Chapter 1 Overview 1.3 Appearance of probe ● Appearance ① ⑦ ③ ② ⑨ ⑧ ⑩ ④ ⑤ ⑥...
  • Page 16: Name And Outline Of Each Part

    Chapter 1 Overview 1.4 Name and outline of each part The following describes the name and outline of each part (① to ⑩) in the previous section 1.3 ① Input leads (red, black) They are the input leads of the probe which connect to the measured item.
  • Page 17: Chapter 2 Specifications

    Chapter 2 Specifications Chapter 2 Specifications 2.1 Product specifications Note1 Frequency characteristics DC to 100 MHz (3dB) Note 1: See “2.4 Derating characteristics.” Rise time 3.5 ns  Calculated value Attenuation ratio 50:1 and 500:1 ±2  (20 C to 30 C) Accuracy ±4 ...
  • Page 18: Certification

    Chapter 2 Specifications Output offset Adjustable with other combined equipment Noise referenced to input Less than 300 mVrms (500:1) Less than 50 mVrms (50:1) Connector Output side BNC type Power supply side Special 6-pin connector 2000 mm 30 mm Total length ...
  • Page 19: Appearance

    Chapter 2 Specifications 2.3 Appearance (1) Probe main unit Unit: mm...
  • Page 20 Chapter 2 Specifications (2) Crocodile clip Knob cap  If the knob cap is pressed in, the tip of the clip opens. If released, it closes. Terminal insertion Unit: mm Tip of clip (3) Plunger hook clip Knob cap  If the knob cap is pressed in, the tip of the clip opens.
  • Page 21: Derating Characteristic

    Chapter 2 Specifications 2.4 Derating characteristic Frequency (MHz) Figure 2.1 Derating curve of SS-320...
  • Page 22: Chapter 3 Measurement

    ③ While turning OFF POWER switch on PS-25, connect the power supply cord. ④ Connect the power supply plug of this probe (SS-320) to the power supply receptacle of PS-25. ⑤ Turn ON the POWER switch of the waveform observation equipment...
  • Page 23 ③ Set the POWER switch of ViewGo II to the stand by status and connect the power supply cord. ④ Connect the power supply plug of this probe (SS-320) to the power supply receptacle of DS-579. ⑤ Press the POWER switch of ViewGo II to power on it.
  • Page 24: Connection To Waveform Observation Equipment And Offset Adjustment

    DC1MΩ or AC1MΩ. If the input impedance is 50Ω, correct measurement cannot be done. ③ Connect the output terminal of this probe (SS-320) to the input terminal of the waveform observation equipment. ④ While checking the monitor on the waveform observation equipment, adjust the offset to zero position on the waveform observation equipment.
  • Page 25: Measurement Method

    Chapter 3 Measurement 3.3 Measurement method ① Check that the safety is ensured and preparation in Section 3.1 and 3.2 is done. ② Select the attenuation ratio (50:1 or 500:1) on the attenuation ratio setting switch in the main box of this probe. Attenuation ratio switching switch ...
  • Page 26 Chapter 3 Measurement Memo...
  • Page 27: Appendix

    Appendix Appendix 1 Oscilloscopes and probe power supply of recommendation ◎ Iwatsu digital oscilloscope (probe power supply PS-25 not required) ・ViewGo II series (equipped with probe power supply option DS-579)  The option can be purchased separately. ○ Iwatsu oscilloscopes (probe power supply PS-25 required) ・ViewGo II series (not equipped with probe power supply option DS-579)
  • Page 28 Contact Us Overseas Sales Sect. Sales Dept. No.2, Address : 7-41 Kugayama 1-chome Suginami-ku, Tokyo, 168-8501 Japan Phone : +81 3 5370 5483 Facsimile : +81 3 5370 5492 URL : http://www.iti.iwatsu.co.jp E-mail : info-tme@iwatsu.co.jp...
