TECHNICAL MANUAL
OPERATION AND INSTALLATION
INSTRUCTIONS
V33085AM-CL ANTENNA
Document No: VTM-05-004A
Valcom Manufacturing Group, Inc.
175 Southgate Drive, P.O.Box 603, Guelph, Ontario, Canada N1H 6L3 Tel: 519-824-3220 Fax: 519-824-3411
Web Site: www.valcom-guelph.com Email: enquiries@valcom-guelph.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Valcom V33085AM-CL
Summary of Contents for Valcom V33085AM-CL
- Page 1 TECHNICAL MANUAL OPERATION AND INSTALLATION INSTRUCTIONS V33085AM-CL ANTENNA Document No: VTM-05-004A Valcom Manufacturing Group, Inc. 175 Southgate Drive, P.O.Box 603, Guelph, Ontario, Canada N1H 6L3 Tel: 519-824-3220 Fax: 519-824-3411 Web Site: www.valcom-guelph.com Email: enquiries@valcom-guelph.com...
-
Page 2: Revision Sheet
V33085AM-CL REVISION SHEET Revision Date Brief Description of Change Entered By October 3, 2005 Original Issue J.S. August 16, 2007 Amended Maintenance Section J.Soper VTM-05-004A... -
Page 3: Table Of Contents
V33085AM-CL TABLE OF CONTENTS Section Page 1.0 GENERAL INFORMATION AND SAFETY PRECAUTIONS ....1 General Safety Precautions ......... 1 Specific Warnings . -
Page 4: List Of Tables And Figures
Table 1-1 - Electrical Properties of the V33085AM-CL ....... 2... -
Page 5: General Information And Safety Precautions
V33085AM-CL SECTION 1.0 GENERAL INFORMATION AND SAFETY PRECAUTIONS 1.1 GENERAL SAFETY PRECAUTIONS The following general safety precautions are not related to any specific procedures and therefore do not appear elsewhere in this publication. These are recommended precautions that personnel must understand and apply during many phases of operation and maintenance. -
Page 6: Introduction
V33085AM-CL INTRODUCTION This manual describes the electrical and mechanical properties of the V33085AM-CL antenna. It provides the information necessary to install, operate and maintain the antenna. TECHNICAL REFERENCE DATA Table 1-1 Electrical Properties of the V33085AM-CL PARAMETER SPECIFICATION FREQUENCY RANGE... - Page 7 V33085AM-CL Table 1-2 Mechanical Properties of the V33085AM-CL PARAMETER SPECIFICATION Assembled Length 85 feet (25.9 m) Weight 895 lbs (406 kg) Copper wire and strips embedded in the fiberglass and thermo- Material setting epoxy resin composite Epoxy polyamide paint Finish...
-
Page 8: Functional Description
FUNCTIONAL DESCRIPTION GENERAL The V33085AM-CL is intended to be used as part of an overall communication system which consists of a transmitter (or receiver or transceiver), an antenna coupler and the antenna. It is used around the world in many applications with requirements in the 100 kHz to 1700 kHz bands for AM broadcast communication systems as well as marine and aeronautical radio beacon systems. -
Page 9: Maintenance
V33085AM-CL SECTION 3.0 MAINTENANCE SCHEDULED MAINTENANCE The antenna is virtually maintenance free. The external finish is an epoxy polyamide two part compound paint. The minimum finish life before showing signs of deterioration should be at least six years under normal climate condition. -
Page 10: Installation
Open the shipping crates and remove the antenna sections. Remove all packing material including the male ferrule protectors on the antenna sections. The V33085AM-CL antenna, as shipped, consists of the items listed in Table 5-1. Check that all of the items are present and in good condition. -
Page 11: Electrical Installation
V33085AM-CL Support the second section (item 2 of Table 5-1) on the other two saw horses so that the two sections lie in the same straight line. Make sure the threads of the male ferrule on the base section and the threads of the female ferrule on the next section are clear of foreign material and free of burrs. - Page 12 V33085AM-CL Figure 4-1 - Gin Pole Arrangement VTM-05-004A...
-
Page 13: Parts List
V33085AM-CL SECTION 5.0 PARTS LIST GENERAL A list of parts shipped with the V33085AM-CL antenna appears in Table 5-1. Table 5-1 - List of Parts for the V33085AM-CL Antenna Item No. Part Number Description Notes VD-99-00085 Base Section VD-99-00086 Section 2 (Strap only) -
Page 14: Quick Reference Data
GENERAL Quick reference engineering data for use during planning and installation activities for the V33085AM-CL antenna is presented on the following pages. * Quick Reference Data - V33085AM-CL Antenna * Foundation Details For VHB-17AM Hinge Plate or VTGS-20BH AM Steel Tower... - Page 15 12 x .718 IN (1.79CM) DIA EQUASPACED ON A 14.625 IN (36.56CM) DIA. BOLT CIRCLE SIDE FEED POINT 17.50 IN (43.75 CM) SIDE VIEW BOTTOM VIEW P.O. BOX 603 GUELPH, ONTARIO, CANADA, N1H 6L3 TEL 519-824-3220 FAX 519-824-3411 INTERNET: www.valcom-guelph.com EMAIL: enquiries@valcom-guelph.com VTM-05-004A...
- Page 16 V33085AM-CL FOUNDATION DETAILS FOR VHB-17AM HINGE PLATE OR VTGS-20BH AM STEEL TOWER NOTES: 8 X ANCHOR-BOLTS (REF. ONLY) 1. FOUNDATION BASE TO BE ON UNDISTURBED SOIL. EQL SP. ON A 17.50 IN (44.45 cm) 2. FOUNDATION EXCAVATION MUST BE FREE OF WATER DIAMETER BOLT CIRCLE (NOTE 11) BEFORE PLACEMENT OF CONCRETE.
- Page 17 V33085AM-CL VTM-05-004A...
- Page 18 2. FLATWASHER, 5/8 NOM, ZINC/PL STEEL, QTY 24 3. WASHER, LOCK-SPRING, HELICAL, 3/4 NOM, ZINC/PL STEEL, QTY 12 4. NUT, HEX, 3/4-10 UNC, ZINC/PL STEEL, QTY 8 P.O. BOX 603 GUELPH, ONTARIO, CANADA, N1H 6L3 TEL 519-824-3220 FAX 519-824-3411 INTERNET: www.valcom-guelph.com EMAIL: enquiries@valcom-guelph.com VTM-05-004A...
- Page 19 VGS-120XXX AM Broadcast Antenna Ground Screen VALCOM'S VGS-120XXXAM GROUND SCREEN CONSISTS OF 120 RADIALS JOINED TO A CENTER RING AT THE BASE OF THE ANTENNA. THE RING IS PLACED ON A 12 X 12 FOOT COPPER MESH GRID. THE ENDS OF EACH RADIAL ARE TERMINATED BY A 10 FOOT LONG GROUND ROD.
- Page 20 QUARTER WAVELENGTH IN FEET: 245.89 operating frequency (in MHz) QUARTER WAVELENGTH IN METERS: 73.48 SEE CHART FOR RADIAL LENGTH operating frequency (in MHz) P.O. BOX 603 GUELPH, ONTARIO, CANADA, N1H 6L3 TEL 519-824-3220 FAX 519-824-3411 INTERNET: www.valcom-guelph.com EMAIL: enquiries@valcom-guelph.com VTM-05-004A...
- Page 21 V33085AM-CL VTM-05-004A...
- Page 22 V33085AM-CL VTM-05-004A...
- Page 23 V33085AM-CL VTM-05-004A...
- Page 24 V33085AM-CL VTM-05-004A...
