Foreword
Thank you for selecting a MITSUBISHI MOTORS prod-
uct as your new vehicle.
This owner's manual will add to your understanding and full enjoy-
ment of the many fine features of this vehicle.
It contains information prepared to acquaint you with the proper way
to operate and maintain your vehicle for the utmost in driving pleasure.
MITSUBISHI MOTORS CORPORATION reserves the right to make
changes in design and specifications and/or to make additions to or
improvements in this product without obligation to install them on
products previously manufactured.
It is an absolute requirement for the driver to strictly observe all laws
and regulations concerning vehicles.
This owner's manual has been written in compliance with such laws
and regulations, but some of the contents may become contradictory
with later amendment of the laws and regulations.
Please leave this owner's manual in this vehicle at time of resale. The
next owner will appreciate having access to the information contained
in this owner's manual.
Throughout this owner's manual the words WARNING and CAU-
TION appear. These serve as reminders to be especially careful.
E09200109231
Failure to follow instructions could result in personal injury or dam-
age to your vehicle.
Indicates a strong possibility of severe personal injury or death if
instructions are not followed.
Means hazards or unsafe practices that could cause minor per-
sonal injury or damage to your vehicle.
You will see another important symbol:
Gives helpful information.
*: Indicates optional equipment.
It may differ according to the sales classification; refer to the
sales catalogue.
Abbreviations used in this owner's manual:
LHD: Left-Hand Drive
RHD: Right-Hand Drive CVT: Continuously Variable Trans-
mission
The symbol used on the vehicles:
: See owner's manual
This manual explains operation of LHD and RHD vehicles. Illustra-
tions represent LHD operation. Depending on the item, however,
RHD illustrations may also appear.
©2022 Mitsubishi Motors Corporation
M/T: Manual Transmission
