imec Neuropixels OneBox Product Safety & Installation Manual page 28

3. ASSEMBLY PART DESCRIPTION
Item # Description
1 Screws M3x6 (8x, countersunk)
2 Top Cover Lid (w Neuropixels Embedded logo)
3 Thermal adhesive
4 Heat Sink + screw M3x6 (1x, countersunk)
5 Back Plate
6 Enclustra ZX-5 module
7 Screws M3x6 (non countersunk)
8 Acquisition Board
9 Front Plate
10 Mounting side plates (2x)
11 Module legs
12 Bottom Cover Lid
www.imec.com
Figure 18: Assembly Part Description.
