BS EN ISO 9001
Certificate No. FM 15094
Amplicon products are designed and manufactured in the United Kingdom under a
quality system approved by the British Standards Institution
P C I 2 2 4 & P C I 2 3 4
MULTI-FUNCTION
ANALOG AND DIGITAL
supplied with the PCI224/234 to provide
This Instruction Manual is
purchased product in a proper and efficient manner. The information contained has been reviewed and is believed to be
accurate and reliable, however Amplicon Liveline Limited accepts no responsibility for any problems caused by errors
or omissions. Specifications and instructions are subject to change without notice.
PCI224/234 Instruction Manual Part Nº 859 893 94 Issue A1
INPUT/OUTPUT
BOARDS
© Amplicon Liveline Limited
Prepared by D.N. Cooper
Approved for issue by A.S. Gorbold, Operations Director
PCI224/234
Affirmed by
Declaration of Conformity
the user with sufficient information to utilise the
Advertisement
Table of Contents
Related Manuals for Amplicon 200 Series
Summary of Contents for Amplicon 200 Series
- Page 1 The information contained has been reviewed and is believed to be accurate and reliable, however Amplicon Liveline Limited accepts no responsibility for any problems caused by errors or omissions. Specifications and instructions are subject to change without notice.
-
Page 2: Declaration Of Conformity
CENTENARY INDUSTRIAL ESTATE HOLLINGDEAN ROAD BRIGHTON BN2 4AW UK We declare that the product(s) described in this Instruction Manual are manufactured by Amplicon Liveline Limited and perform in conformity with the following standards or standardisation documents: Electro Magnetic Compatibility (EMC): EN55022... -
Page 3: Table Of Contents
Enhanced Features......................2 1.4.2 The Hardware ........................2 1.4.3 The Software ........................3 What the Package Contains.......................4 The Amplicon Warranty Covering the PCI224/234..............4 Contacting Amplicon Liveline Limited for Support or Service ............5 1.7.1 Technical Support .......................5 1.7.2 Repairs..........................5 GETTING STARTED ........................6 General Information ........................6 Host Computer Requirements ....................6... - Page 4 Analog Power Supplies ......................22 4.5.1 DAC Transfer Functions ....................23 Multiple PCI224/234 Boards in a Single Application..............24 Testing and Troubleshooting....................24 STRUCTURE AND ASSIGNMENTS OF THE REGISTERS............25 Register Assignments ......................25 Register Groups ........................25 Register Assignment Summary ....................26 5.3.1 PCI224 I/O Registers ......................26 The Register Details.........................27 5.4.1 DACCON Control register for DAC and FIFO ..............27...
- Page 5 LIST OF FIGURES FIGURE TITLE PAGE FIGURE 1.1 PCI224 BLOCK SCHEMATIC ....................2 FIGURE 1.2 PCI234 BLOCK SCHEMATIC ....................3 FIGURE 2.1 INTERNAL/EXTERNAL REFERENCE VOLTAGE SELECTION LINK ......9 FIGURE 3.1 PCI224 SK1 37 WAY USER INTERFACE PIN DESIGNATIONS........11 FIGURE 3.2 PCI234 SK1 37 WAY USER INTERFACE PIN DESIGNATIONS........12 FIGURE 3.3 EXTERNAL REFERENCE VOLTAGE CONNECTIONS..........13 FIGURE 3.4 37-WAY SCREW TERMINAL ASSEMBLY PIN DESIGNATIONS........14 FIGURE 3.5 PCI224/234 TWISTED PAIRS..................14...
-
Page 6: Introduction
When a large scale system is required, multiple boards can be added from the 200 Series without conflict. For analog input systems, the capacity of the PC mounted hardware can be extended by external expansion panels to provide a convenient to use system with low cost per channel and maintained high performance. -
Page 7: General Description
General Description The PCI224/234 range of boards provide multi-channel data acquisition functions for any IBM PC or compatible computer that supports PCI bus version 2.1 All models are supported by Windows 95 & NT drivers. These drivers allow the advanced features of the cards to be fully utilised by the application software. -
Page 8: The Software
PCI234 BLOCK SCHEMATIC 1.4.3 The Software The PCI224/234 is supplied with the SOFTMAN CD-ROM Part No 869 865 59, this contains all the software for the card, and is documented in the Amplicon ADIO manual elsewhere on the CD ROM. PCI224/234... -
Page 9: What The Package Contains
When removed from the bag, inspect the board for any obvious signs of damage and notify Amplicon if such damage is apparent. Do not plug a damaged board into the host computer. Keep the protective bag for possible future use in transporting the board. -
Page 10: Contacting Amplicon Liveline Limited For Support Or Service
Before returning the goods, please request an individual RMA number by contacting Amplicon Customer Services by telephone or fax on the above numbers. Give the reason for the return and, if the goods are still under warranty, the original invoice number and date. -
Page 11: Getting Started
BEFORE INSTALLING OR REMOVING ANY EXPANSION BOARD. OBSERVE HANDLING PRECAUTIONS NOTED IN SECTION 1.4. REPAIR OF DAMAGE CAUSED BY MIS-HANDLING IS NOT COVERED UNDER THE AMPLICON WARRANTY. DO NOT MAKE ANY MODIFICATIONS OTHER THAN SWITCH CHANGES TO A BOARD THAT IS ON EVALUATION Please refer to the manufacturer's hardware manual supplied with the PC for instructions on how to remove the cover and install devices into an input/output slot. -
Page 12: Windows Nt Installation
Windows will now proceed to copy the driver software from the CD. If Windows asks for the ‘Amplicon DIO Drivers Disk’ to be inserted, ensure the SOFTMAN CD is in the drive, click ‘OK’, click ‘Browse’, browse to the top-level directory of the SOFTMAN CD (which contains the file Windows is trying to find) and click ‘OK’. -
Page 13: Card Configuration
After rebooting the PC, the PCI224 or PCI234 will be detected by the installed driver and configured automatically. The Amplicon DIO control panel applet can be used to verify that the board has been detected. This will also show the base address and IRQ settings for the board. -
Page 14: Selection Of Internal/External Voltage Reference
(e.g. C:\AMPLICON\AMPDIO), the examples and DLL source code can be found in subdirectories off this directory. The software supplied with this card supports operation with Windows 95, 98 &... -
Page 15: Verifying Installation For Windows 95/98
(a) Open the Control Panel, e.g. via ‘Start’ -> ‘Settings’ -> ‘Control Panel’. (b) Double click the ‘Amplicon DIO’ icon (or open it from the Control Panel’s File menu). (c) Select each of the ‘DIOn’ entries from the list in turn. For each selected entry, click the ‘Settings’... -
Page 16: Making The Connections
MAKING THE CONNECTIONS This chapter describes the signal and control connections that the user must make between the PCI224/234 and any external devices. These input/output connections are made through the D-type connector protruding from the PC adapter slot corresponding to the chosen board position. The metal shell connected to the local PC chassis ground. -
Page 17: Danger Of Electric Shock
Pin Number EXTCLK OUT2 EXTTRIG DGND EXTREFIN AGND AGND REFOUT AGND REFOUT AGND AGND DAC0 AGND DAC0 AGND AGND DAC1 AGND DAC1 AGND AGND DAC2 AGND DAC2 AGND AGND DAC3 AGND DAC3 AGND FIGURE 3.2 PCI234 SK1 37 WAY USER INTERFACE PIN DESIGNATIONS BE AWARE DANGER OF ELECTRIC SHOCK When the PCI224/234 board is in use in an open... -
Page 18: Digital Input / Output Connections
Connections to the PCI224/234 I/O lines are made via D-Type connectors on the rear panel. The on-board connectors are 37 way female SK1. The mating connectors are available as accessories. Provision is made for securing by screw jacks. The following cables and connection assemblies are available from Amplicon: Amplicon Device... -
Page 19: Use Of Shielded Cables
connector pin-out does not map directly onto the screw terminal layout. The loose terminal identification tags supplied with the assembly should be fitted as shown below. The terminal numbers then correspond to the 37 way connector pin-out. 20 21 26 27 11 12 FIGURE 3.4 37-WAY SCREW TERMINAL ASSEMBLY PIN DESIGNATIONS... -
Page 20: Figure 3.6 Pc Back-Plane Pci Bus Connections
The PCI224/234 does not use all the functions of the bus. 82 Pin Connector (Pins B1 and A1 are at the bracket end of the board) -12V < < TRST# < < > +12V Ground < < > > < <... -
Page 21: The Ground Connections
The Ground Connections Each connector is equipped with one or more different ground connections and care must be taken in the use of these grounds and the cable design to ensure that the EMC requirements are met. The choice of proper, screened cables is important for the system to maintain Electro-Magnetic Compatibility. -
Page 22: Figure 3.8 Analog Output Wiring To Loads With Common Ground
PC224/234 USER’S EQUIPMENT Channel 0 Channel 0 Load Channel 1 Channel 1 Load Channel 2 Channel 2 Load Channel X * Channel X * Load PC224 Analog Ground Equipment Star-Point Ground FIGURE 3.8 ANALOG OUTPUT WIRING TO LOADS WITH COMMON GROUND To maintain measurement accuracy, the following precautions must be observed:- Use separate ground wires for analog output, digital I/O and power lines. -
Page 23: Using The Pci224/234
This chapter describes the various hardware operations associated with implementing the user’s application. Programming operations are discussed in the Amplicon ADIO driver manual elsewhere on the softman CD ROM. Details of the registers and software are given in chapters 5 and 6 respectively. -
Page 24: Pci224 Output Voltage Range
4.1.2 PCI224 Output Voltage Range The output ranges of the DACs can be selected by varying the reference voltage supplied to the DACs. The output voltage range is established by the gain setting of the analog amplifiers preceding the DAC. Selection of internal reference voltage is made in software by writing to the DACMOD register. -
Page 25: Pci234 Output Voltage Range
4.2.1 PCI234 Output Voltage Range The output ranges of the DACs can be selected by varying the reference voltage supplied to the DACs. When using the internal voltage reference the output voltage can be varied between ±10 volts or ±5 volts. Alternatively the user may use an external reference voltage. The Factory default output voltage range is ±10V bipolar using the internal reference. -
Page 26: Continuous Fifo Mode' Interrupt Controlled D/A Conversion
4.3.2 ‘Continuous FIFO Mode’ Interrupt Controlled D/A Conversion In this mode upto sixteen channels of analog output, can be updated continuously. Timing is controlled by a hardware generated clock thereby making conversion rates deterministic. The clock may come from one of the 82C54 timer/counters. The driver software will default to use Counter 1 and will program it as a square wave generator at the required sampling interval. -
Page 27: Channelling
4.3.4 Channelling Each time a conversion is initiated In ‘Interrupt Controlled D/A Conversion’ mode the card automatically outputs the sample to the next channel in ascending number order from the channels enabled in the DAC channel enable register. In this way the card automatically cycles all analog outputs sequentially outputting from the FIFO if it is enabled. -
Page 28: Dac Transfer Functions
4.5.1 DAC Transfer Functions The DAC transfer functions for unipolar and bipolar operation, when programmed for complementary or straight binary input, are shown diagrammatically below. 011…111 111…111 011…111 111…111 011…111 111…111 011…111 111…111 Unipolar … Transfer … Function … 100…011 000…011 100…010 000…010... -
Page 29: Multiple Pci224/234 Boards In A Single Application
If the card has not installed correctly there could be a hardware problem. To check that your PC hardware and BIOS can detect the card you may run the FINDCARD.EXE program found in the UTILS directory on the Softman CD supplied with the card. If FINDCARD.EXE does not find your card then contact Amplicon Technical support. PCI224/234... -
Page 30: Structure And Assignments Of The Registers
5 STRUCTURE AND ASSIGNMENTS OF THE REGISTERS The set of demonstration programs and routines provided with the PCI224/234 allows user access to all the operational functions of the board. However, in some circumstances, the user may wish to program the application at the lowest level using input/output instructions. This section provides the necessary information on the accessible registers. -
Page 31: Register Assignment Summary
Register Assignment Summary 5.3.1 PCI224 I/O Registers I/O Space 1 PC i/o 200 series PORT FUNCTION 8/16 driver ADDRESS Mnemonic (Base + Offset) BA1 + 00 RESERVED BA1 + 02 RESERVED BA1 + 04 RESERVED BA1 + 06 RESERVED BA1 + 08... -
Page 32: The Register Details
The Register Details The following paragraphs describe the operations of each of the accessible registers. Additional information on the register usage can be found in chapter 4 'USING THE PCI224/234 '. 5.4.1 DACCON Control register for DAC and FIFO PCI224 WRITE Global Fifo... - Page 33 PCI234 WRITE Global Fifo FIFO Interrupt Trigger Level reset reset 000 FIFO Empty FIFO 001 FIFO Not Empty Enable 010 FIFO Not Half Full 011 FIFO Half Full 100 FIFO Not Full 101 FIFO Full FIFO Start conversion source Wrap 000 –...
-
Page 34: Dacout Output Data To Dac Or Fifo
5.4.2 DACOUT Output data to DAC or FIFO Reading from this register initiates a conversion if the card is set for software controlled conversion. PCI224 ($8000) ($4000) ($2000) ($1000) ($800) ($400) ($200) ($100) ($80) ($40) ($20) ($10) ($8) ($4) ($2) ($1) RESERVED FOR EXPANSION PCI234... -
Page 35: Timing And Control
Unipolar Bipolar pattern input input range range ±10 0-10 ±5 ±2.5 0-2.5 ±1.25 5.4.5 Timing and Control All timing of operations in the PCI224 is under the control of a 10 MHz crystal clock source. This source is used internally and divided down for input to an 82C54 triple 16 bit programmable counter/timer. -
Page 36: Group X Clock Configuration Register
5.4.6 Group X CLOCK Configuration Register ($80) ($40) ($20) ($10) ($8) ($4) ($2) ($1) Counter Timer Clock Source 000 – Reserved 00 – Counter 0 001 - 10MHz 01 – Counter 1 010 - 1MHz 10 – Counter 2 011 - 100kHz 11 –... -
Page 37: Programming The Pci224/234
Copyright Software supplied with the PCI224/234 is Amplicon copyright. Permission is granted for the purchaser of the PCI224/234 to incorporate any part of the Amplicon copyright software into related application programs, and to use, resell or otherwise distribute such application programs for operation with PCI224/234 hardware purchased from Amplicon Liveline Limited. -
Page 38: Appendix A Pci224/234 Technical Specifications
APPENDICES APPENDIX A PCI224/234 TECHNICAL SPECIFICATIONS Except where otherwise stated, all figures quoted in the specifications are typical at 25°C. HARDWARE SPECIFICATION FUNCTION PCI bus compatible multi-function data acquisition board providing high speed, sixteen, 12bit or four, 16bit, analog outputs with counter/timer facilities. A.1.1 ANALOG OUTPUTS Number of Output Channels PCI224 has sixteen analog output channels in four groups of... - Page 39 Digital to Analog Converter PCI224 DAC Resolution 12 bits (1 part in 4096) Settling Time 10 µSecs typical Reference Derived from on board or external reference voltage PCI234 DAC Resolution 16 bits (1 part in 65535) Monotonicity 16 bits Settling Time <5 µSecs max Reference Derived from on board or external reference voltage...
-
Page 40: Counter / Timer
Typical maximum continuous useable sampling rates under Windows NT or 95/98 allowing time to respond to interrupts and write samples to the card in single channel operation are: Program Mode 10 ks/s Continuous 100 ks/s FIFO Wrapround 100 ks/s Data Acquisition FIFO The FIFO is a 4096 words (8192 bytes) FIFO shared between enabled channels. -
Page 41: Power Rails
Interrupts Single PCI interrupt. multi-function, each interrupt maskable and read by interrupt status word. Interrupt functions to include: Divided Clock interrupt External interrupt source (2) Conversion complete (or FIFO interrupt) Power-up Default On power-up, all DAC outputs will be at zero volts Data FIFO 4096 words (8192 bytes) shared between enabled channels Full, half-full and empty flags and re-transmit (wraparound) -
Page 42: Environmental Conditions
Order Codes The Order Code for the PCI224 is 909 893 83 The Order Code for the PCI234 is 909 893 73 Optional Accessories A.5.1 Hardware Options Amplicon Order Description Code 70870390 25way 'D' socket with solder buckets 90891952... -
Page 43: Appendix B Circuit Layout And Schematic Drawings
APPENDIX B CIRCUIT LAYOUT AND SCHEMATIC DRAWINGS A full layout drawing and circuit diagram of the PCI224/234 Board are given in this appendix. Assembly Detail FIGURE B.1 PCI234 PRINTED CIRCUIT LAYOUT FIGURE B.2 PCI224 PRINTED CIRCUIT LAYOUT PCI224/234... -
Page 44: Figure B.3 Pci224 Circuit Diagram
FIGURE B.3 PCI224 CIRCUIT DIAGRAM Page 39 PCI224/234... -
Page 45: Figure B.4 Pci224 Circuit Diagram
FIGURE B.4 PCI224 CIRCUIT DIAGRAM PCI224/234 Page 40... -
Page 46: Figure B.5 Pci234 Printed Circuit Layout
FIGURE B.5 PCI234 PRINTED CIRCUIT LAYOUT Page 41 PCI224/234... -
Page 47: Figure B.6 Pci234 Printed Circuit Layout
FIGURE B.6 PCI234 CIRCUIT DIAGRAM PCI224/234 Page 42...
