Amplicon 200 Series Manual

72 line programmable digital input/output board
Hide thumbs Also See for 200 Series:
Table of Contents

Advertisement

Quick Links

Download this manual
Affirmed by
BS EN ISO 9001
Declaration of Conformity
Certificate No. FM 15094
Amplicon products are designed and manufactured in the United Kingdom under a
quality system approved by the British Standards Institution
P C I 2 7 2
72 LINE
PROGRAMMABLE
DIGITAL
INPUT/OUTPUT
BOARD
This Instruction Manual is supplied with the PCI272 board to provide the user with sufficient information to properly
utilise the product as purchased. The information contained has been reviewed and is believed to be accurate and
reliable, however Amplicon Liveline Limited accepts no responsibility for any problems caused by errors or
omissions. Specifications and instructions are subject to change without notice.
PCI272 Instruction Manual Part Nº 860 035 24 Issue A3
© Amplicon Liveline Limited
Prepared by D.N.Cooper
Approved for issue by A.S. Gorbold, Operations Director
PCI272
