Amplicon 200 Series Instruction Manual

Analog input expansion panel
Hide thumbs Also See for 200 Series:
Table of Contents

Advertisement

Quick Links

Download this manual
BS EN ISO 9001
Certificate No. FM 15094
Amplicon products are designed and manufactured in the United Kingdom under a
quality system approved by the British Standards Institution
E X 2 0 1
ANALOG
INPUT
EXPANSION
PANEL
This Instruction Manual is supplied with the EX201 Expansion Panel to provide the user with sufficient information
to properly utilise the product as purchased. The information contained has been reviewed and is believed to be
accurate and reliable, however Amplicon Liveline Limited accepts no responsibility for any problems caused by
errors or omissions. Specifications and instructions are subject to change without notice.
EX201 Instruction Manual Part Nº 859 243 74 Issue B2
© Amplicon Liveline Limited
Prepared by C.A. Kenny
Approved for issue by A.S. Gorbold, Operations Director
EX201
