CAMPBELL
HAUSFELD
OPERATING INSTRUCTION MANUAL
SANDBLASTING KITS
MODELS AT125102AJ, AT121002AJ, AND
AT121102AJ
READ CAREFULLY BEFORE ATTEMPTING TO ASSEMBLE, INSTALL, OPERATE OR MAINTAIN THE PRODUCT
DESCRIBED. PROTECT YOURSELF AND OTHERS BY OBSERVING ALL SAFETY INFORMATION. FAILURE TO COMPIY
WITH INSTRUCTIONS COULD RESULT IN PERSONAL INJURY AND/OR PROPERTY DAMAGEI
RETAIN INSTRUCTIONS FOR FUTURE REFERENCE
Description
Campbell Hausfeld sandblasting equipment is designed
for cleaning and removing rust, scale, paint, grime and dirt
for stripping, polishing and etching projects. This equip*
ment can be used with sand, abrasive powders, or water
and other liquids.
Unpacking
After unpacking the sandblasting kit, carefully Inspect for
any damage that may have occurredduring transit. Check
for loose, missing or damaged parts.
General Safety Information
1. Read this instruction manual before installing this
device to the compressor pump.
2. Safety glasses or face shield, gloves and a respirator
must be worn during operation. Always work in a well
ventilated area.
7. Check hoses and air lines for weak or worn condition
before each use. Make sure alt connections are se¬
cure before use.
AwarningA I
DO NOT POINT THE SANDBLAST GUN AT ANY¬
ONE OR OBJECTS OTHER THAN THE INTENDED
WORK OBJECT.
8. Do not depress the trigger when connecting the air
supply hose.
ADANGER
DO NOT WORK AROUND OILY RAGS OR FLAM¬
MABLE LIQUIDS. SAND STRIKING METAL CAN
CAUSE A SPARK AND CREATE A FIRE OR EXPLO¬
SION.
Figure 1
3. During operation, do not expose the hands or skin
directly in the line of the blast nozzle.
4. After installation, inspect to make sure all components
seal properly.
5. Keep children away at all times. AH visitors must be
kept a safe distance and wear safety glasses, gloves
and a respirator.
6. Do not exceed the maximum operating pressure of the
sandblasting equipment (125 PSI).
AwarningA
DISCONNECT THE SANDBLASTER FROM THE
AIR SUPPLY BEFORE CHANGING ACCESSORIES
OR ATTEMPTING TO INSTALL, SERVICE, RELO¬
CATE OR PERFORM ANY MAINTENANCE.
Copyright 1993, Campbell Hausfeld/Scott Fetzer Company
Figure 2
A
WARNING
A
DO NOT SPRAY ACIDS OR CAUSTICS.
Figure 3
IN241909AV 1/93
