Technical Support and E-Warranty Certificate
www.vevor.com/support
LABELING MACHINE
USER MANUAL
We continue to be committed to provide you tools with competitive price.
"Save Half", "Half Price" or any other similar expressions used by us only represents an
estimate of savings you might benefit from buying certain tools with us compared to the major
top brands and does not necessarily mean to cover all categories of tools offered by us. You
are kindly reminded to verify carefully when you are placing an order with us if you are
actually saving half in comparison with the top major brands.
Advertisement
Table of Contents
Related Manuals for VEVOR MT-50Alu-V1
Summary of Contents for VEVOR MT-50Alu-V1
- Page 1 Technical Support and E-Warranty Certificate www.vevor.com/support LABELING MACHINE USER MANUAL We continue to be committed to provide you tools with competitive price. "Save Half", "Half Price" or any other similar expressions used by us only represents an estimate of savings you might benefit from buying certain tools with us compared to the major top brands and does not necessarily mean to cover all categories of tools offered by us.
- Page 2 This is the original instruction, please read all manual instructions carefully before operating. VEVOR reserves a clear interpretation of our user manual. The appearance of the product shall be subject to the product you received. Please forgive us that we won't inform you again if there are any technology or software updates on our product.
-
Page 3: General Safety Rules
1. Read carefully and understand all ASSEMBLY AND OPERATION INSTRUCTIONS before operating. 2. Failure to follow the safety rules and other basic safety precautions may result in serious personal injury. GENERAL SAFETY RULES Important reminder 1.Before use, please carefully read the product manual and ensure that you understand and comply with all safety warnings and usage precautions. - Page 4 mismatched devices to avoid risks such as electric shock and fire. 3. When foreign objects are found on the surface of the product, please immediately stop using and remove the foreign objects before continuing to use. 4. When using this product continuously for a long time, please rest in good time to avoid excessive fatigue.
- Page 5 MODEL AND PARAMETERS Model MT-50Alu-V1 MT-50Alu-V2 MT-50SS-V2 MT-50SS-V3 Applicable 20-120mm 20-120mm 20-120mm 20-120mm Bottles of Diameter Label Width 13-150mm 13-150mm 13-150mm 13-150mm Label Length 25-300mm 25-300mm 25-300mm 25-300mm Label Roll I.D ＞75mm ＞75mm ＞75mm ＞75mm Label Roll ＜300mm ＜300mm ＜300mm ＜300mm...
-
Page 6: Structure Diagram
STRUCTURE DIAGRAM 1.Label Baffle 2.Label Holder 3.Press Roll 4.Sensor 5.Scroll and Paper Clip 6.Adjustable Bolt tripper Plate 7.Bottle Holder Roller 9.Time Delay Button - 5 -... - Page 7 COMPONENTS Model MT-50Alu-V1 MT-50Alu-V2 MT-50SS-V2 MT-50SS-V3 Parts Baffle ×2 ×2 ×2 ×2 Label Holder A ×1 ×1 ×1 ×1 Label Holder B ×1 ×1 ×1 ×1 Power Cord ×1 ×1 ×1 ×1 Micro-switch ×1 ×1 ×1 ×1 Locating Rod ×1 ×1...
- Page 8 OPERATING INSTRUCTIONS 1.Remove the screws,install the label mounting assembly and lock it with the removed screws as shown. 2.Assemble two baffles and label holders(A,B) and fasten with screws （M4*8). Insert the A , B and label roll in turn as shown. Place the green O tape over the label holder A.
- Page 9 4.Pull the label across C,D,E ,and then across between F and G. Pull the label through C, D, E, then out between F and G, and down through H,I. Finally Wrap the label backing paper tightly around the scroll(J) and attach the paper clip as shown. Note:a) The installed labels should be aligned smoothly from the fixed axis to the scroll.(from beginning to end) Otherwise, the label will be easily torn.
- Page 10 Label Paper Route 5.Install the and lock as shown. locating rod located block 6.Insert the power cord as shown. 7.Product assembly completed. - 9 -...
- Page 11 The operating instructions 1.Label extension setting Turn on the machine, slowly press down the press roll,Observe the extension length of the label as shown. When the label does not come out, adjust the delay(K) until the label comes out.(Note:Please reset to zero before using the delay function.) Adjust the sensor(D) position according to label extension length-the sensor is adjusted to the left, and the extension length of the label is increased;the sensor is adjusted to the right, and the extension length of...
- Page 12 3)After the above adjustment, the press roll pressed the bottle, adjust the screw(P) length to just trigger the micro-switch as shown. Note:If the micro-switch is not triggered, the machine will not start working. 3.After the above installation and adjustment are completed, put on the bottle, press down the pressure roller once to label once.
-
Page 13: Maintenance
MAINTENANCE 1.Operators must be trained in advance and familiar with the product. 2.Before each use, check that the components are locked and clean. 3.Inspect periodically all parts and accessories and replace them if damaged. 4. Have damaged parts replaced by an authorized service center. 5.Check the nuts periodically and tighten them if they are loose. -
Page 14: Troubleshooting
TROUBLESHOOTING Problem Possible Cause Possible Solution The micro-switch won't Adjust the trigger screw trigger length. micro-switch The label didn't come Replace the micro-switch damaged The press roll slipped on Re-lock the press roll the bottle The power switch is not Turn on the power turned on. - Page 15 Address：Baoshanqu Shuangchenglu 803long 11hao 1602A-1609shi Shanghai Imported to AUS: SIHAO PTY LTD, 1 ROKEVA STREETEASTWOOD NSW 2122 Australia Imported to USA: Sanven Technology Ltd, Suite 250, 9166 Anaheim Place, Rancho Cucamonga, CA 91730 SHUNSHUN GmbH Römeräcker 9 Z2021, 76351 Linkenheim-Hochstetten, Germany Pooledas Group Ltd Unit 5 Albert Edward House, The Pavilions Preston, United Kingdom...
- Page 16 Technical Support and E-Warranty Certificate www.vevor.com/support...
