- Page 1 HOTO Precision Screwdriver Set...
- Page 3 01 Product Overview Thank you for purchasing the HOTO Precision Screwdriver Set. Please read this manual carefully before use, and retain it for future reference. Storage box cover Screwdriver handle Storage box base...
- Page 4 02 How to Use Opening/Closing the Cover Turn the storage box cover upward to the natural open position (the maximum open angle is 115°), please do not turn it forcibly. Turn the storage box cover downward to zero degree, and the storage box will be closed. Bit Storage Bits are stored in the base magnetically.
- Page 5 Screwdriver Handle Storage Insert the tip of the precision screwdriver into the circular hole and press it for storage. Illustrations of the product, accessories, and user interface in the user manual are for reference purposes only. Due to product updates and upgrades, the actual product may be slightly different from the schematic.
- Page 6 03 Precautions A part of the finger may be clipped if the storage box cover is being turned upward too fast. Please make sure the power of the live equipment has been cut off before using this product. This product is not a toy and should not be used by children.
- Page 7 Dimension of storage box： Maximum manual torque： 2N·m 149.5×78×19.5mm Bit material: S2 alloy steel Dimension of screwdriver： Bit specification： C4×L28mm 126.5×10.1×10.1mm Bit model： Y0.6/TW1/PH000/PH00/PH0/PH1/SL1.5/SL2/SL2.5/SL3/ W1.5/P2/P5/P6/T1/T2/T3/T4/T5H/T6H/T8H/T9H/T10H/H1.5/H2/ H2.5/U2.6 /▲2.3 Follow us:@hoto_tools Manufacturer: Shanghai HOTO Technology Co., Ltd. Address: Building 45, No.50 Moganshan Road, Shanghai, China...
