Summary of Contents for HOTO QWLDM001
- Page 1 Manual of HOTO 35in1 Rotary Tool Kit...
-
Page 2: Product Overview
Please read this manual carefully before using the product and keep it for future reference. Thanks for using HOTO 35in1 Rotary Tool Kit. This product is used as grinding miller, sand mill, steel brush, polishing machine, carving machine or grinding machine. Please read all security warnings, instructions, legends and specifications provided about this electric... -
Page 3: How To Use
02 How to Use Instructions for accessories installation （1） （2） Press the shaft lock button , and use your hand to turn the main shaft until the main shaft is locked. Don't use the shaft lock when the tool is running. 白电... - Page 4 Pet nail grinder Please make use of the sand ring accessory when using the nail grinding head. Align the dot marking of the nail grinding head with that of the main body, and connect the head 。 to the front end of the body. Please confirm that 。...
- Page 5 Attention Do not set the speed above '3' when using the steel brush. Instructions for charging When the turn-on button shows a red light, it indicates that remaining battery is less than 10%. When the red light flickers, remainning battery is under 5%.
- Page 6 6. Sand ring, cutting blade or other accessories to install the dabber must be totally inserted into the clamp cover or three-jaw chuck. If the dabber is not adequate to support and/or the length of the sand ring is too long after extension, the installed sand ring may get loose and eject at a high speed.
- Page 7 respirators must be able to filter particles generated during operation. A long time of exposure to high intensity noise may lead to the hearing damages. 13. Use the pincer clamp to support the workpiece when it is feasible. It is prohibited to hold a small workpiece in one hand and the tool in the other during the process of using the pincer clamp.
- Page 8 04 Accesory instructions Carving and drilling Milling cutter For operations such as car ving, trimming, and s l ott i n g , o n s u c h m ate r i a l s a s w o o d , p l a st i c , fiberglass, and soft metals.
- Page 9 Polishing Corundum grinding head It is suitable for operations such as trimming, grinding, and sanding, on such materials as metal, stone, and wood. Disc metal brush It is suitable for such operations as cleaning, deburring, and derusting, on such materials as metal and wood. Also suitable to reach inaccessible corners.
-
Page 10: General Power Tool Safety Warnings
05 General Power Tool Safety Warnings WARNING! Read all safety warnings, instructions, illustrations and specifications provided with this power tool. Failure to follow all instructions listed below may result in electric shock, fire and/or serious injury. Save all warnings and instructions for future reference. The term “power tool”... -
Page 11: Personal Safety
Personal Safety Stay alert, watch what you are doing and use common sense when operating a power tool. Do not use a power tool while you are tired or under the influence of drugs, alcohol or medication. A moment of inattention while operating power tools may result in serious personal injury. - Page 12 Power Tool Use And Care Do not force the power tool. Use the correct power tool for your application. The correct power tool will do the job better and safer at the rate for which it was designed. Do not use the power tool if the switch does not turn it on and off. Any power tool that cannot be controlled with the switch is dangerous and must be repaired.
- Page 13 Battery tool use and care Recharge only with the charger specified by the manufacturer. A charger that is suitable for one type of battery pack may create a risk of fire when used with another battery pack. Use power tools only with specifically designated battery packs. Use of any other battery packs may create a risk of injury and fire.
- Page 14 Safety warning of HOTO 35in1 Rotary Tool Hold the tool by the insulated gripping surface if the cutting and drilling accessories could contact hidden wires during operation. Were cutting and drilling accessories to contact live wires, exposed metal parts may conduct the electricity and cause electric shock to the operator.
- Page 15 Safety instructions for all operations Safety warnings common for grinding, sanding, wire brushing, polishing, carving or abrasive cutting-off operations: a) This power tool is intended to function as a grinder, sander, wire brush, polisher, carving or cut-off tool. Read all safety warnings, instructions, illustrations and specifications provided with this power tool.
- Page 16 Please contact the installer or local authorities for more information about the location as well as terms and conditions of such collection points. We Shanghai HOTO Technology Co., Ltd., hereby, declares that this equipment is in compliance with the applicable Directives and European Norms, and amendments.
- Page 17 Federal Communications Commission Supplier’s Declaration of Conformity This supplier’s declaration of conformity is hereby for Product: HOTO Lithium Electric Grinder Model Number(s): QWLDM001 Brand/Trade: HOTO We declare that the above mentioned device has been tested and found in compliance with CFR 47 Part 15 Regulation.
-
Page 18: Troubleshooting
Representative of Responsible Party for SDoC Company: Shanghai HOTO Technology Co., Ltd. Address: Building 45, No.50 Moganshan Road, Putuo District, Shanghai, China Country: China Telephone No.: 400-021-8696 Troubleshooting Issues Causes Solutions During the process of Continuous use of the Properly adjust the gear to a... -
Page 19: Specifications
Cutting: Metal electrolon cutting blade with a diameter of 22mm×4, core bar of the cutting blade×1 Wrench×1 Dust cover×1 Pet nail grinder×1 Manufacturer: Shanghai HOTO Technology Co., Ltd. Address: Building 45, No. 50 Moganshan Rd, Putuo District, Shanghai, PRC, 200060. - Page 20 EU Declaration of Conformity Shanghai HOTO Technology Co., Ltd. Declare that the product: HOTO 35in1 Rotary Tool Kit / QWLDM001 Complies with the essential health and safety requirements of the following directives: 2006/42/EC The Machinery Directive References to the following harmonized standard were made:...
