- Page 1 USER MANUAL INDUCTION COOKTOPS WHI632BE, WHI642BE, WHI942BE...
-
Page 2: Table Of Contents
PNC: ......................this manual may result in personal injury, property damage and affect your ability to make a claim under the Westinghouse manufacturer’s warranty provided with your product. Products must be used, installed and operated in accordance with this manual. You may not be able to claim on the Westinghouse manufacturer’s warranty in the... -
Page 3: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS Installation TIPS & INFORMATION IMPORTANT Check for any damage or marks WARNING WARNING If you find the cooktop is damaged or marked, you must Only a qualified person must install this appliance. report it within 7 days if you wish to claim for damage/ marks under the manufacturer’s warranty. - Page 4 IMPORTANT SAFETY INSTRUCTIONS Electrical connection supply to prevent the electrical shock. • Users with a pacemaker must keep a distance of minimum 30 cm from the induction cooking zones WARNING WARNING when the appliance is in operation. Risk of fire and electrical shock. •...
-
Page 5: Installation Instructions
• Replace the damaged mains cable with special cable (type H05V2V2-5/H05VVF) minumim 3x1.5mm with an all-pole 16A breaker for WHI632BE, and 3x2.5mm with an all-pole 20A breaker for WHI642BE and WHI942BE. Speak to your local service center. • The cable conditions must be in accordance with AS/ NZS 3000 and the terminal screws tightened securely. - Page 6 INSTALLATION INSTRUCTIONS (CONTINUED) WHI642BE, WHI632BE TIPS & INFORMATION IMPORTANT It is recommended to centre the bench cutout with equal distance front and back as shown but the product has also been certified to be installed with no clearance between the rear edge of the cooktop glass and rear wall if required.
-
Page 7: Specifications
60mm SPECIFICATIONS Technical data WHI632BE WHI642BE WHI942BE 949163543 949163541 949163540 Product dimensions (w x d) 590 x 520 590 x 520 900 x 520 Cut-out dimensions (w x d) 560 x 490 560 x 490 880 x 490 Voltage (volts) -
Page 8: Product Description
BOOST BOOST ON/OFF LOCK TIMER Control panel WHI632BE Induction cooking zone 1800 W, with Power function 2800 W (minimum cookware diameter =150 mm). Induction cooking zone 1400 W, with Power function 2500 W (minimum cookware diameter =125 mm). Induction cooking zone 2300 W, with Power function 3200 W (minimum cookware diameter =205 mm). - Page 9 Control panel layout - WHI642BE BOOST BOOST PAUSE BOOST BOOST ON/OFF LOCK TIMER Control panel layout - WHI632BE TIMER Control panel layout - WHI942BE PrOduCT dESCrIPTION...
- Page 10 PRODUCT DESCRIPTION (CONTINUED) Use the sensor fields to operate the appliance. The displays, indicators and sounds tell which functions operate. SENSOr fIEld fuNCTION It activates and deactivates the appliance It locks/unlocks the control panel Left front (LF) cooking zone To set the timer function TIMER It increases or decreases the time A heat setting display...
-
Page 11: Operating Instructions
These settings will flash on the control panel display and will be automatically adjusted to the highest possible heat level within the power limit. Model number: WHI642BE 20amp (4.6kw) WHI632BE 15amp (3.5kw) WHI942BE 20amp (4.6kw) ** Please consult a qualified electrician. OPEraTINg INSTruCTIONS... - Page 12 WHI642BE 20AMP (4.6KW) When using more than one zone at the same time, the power sharing feature will activate to reduce the overall load. This may restrict the maximum heat level achievable for each zone. It may be necessary to lower the settings on other zones before increasing the heat setting or activating an additional cooking zone.
- Page 13 WHI632BE 15AMP (3.5KW) When using more than one zone at the same time, the power sharing feature will activate to reduce the overall load. This may restrict the maximum heat level achievable for each zone. It may be necessary to lower the settings on other zones before increasing the heat setting or activating an additional cooking zone.
- Page 14 WHI942BE 20AMP (4.6KW) When using more than one zone at the same time, the power sharing feature will activate to reduce the overall load. This may restrict the maximum heat level achievable for each zone. It may be necessary to lower the settings on other zones before increasing the heat setting or activating an additional cooking zone.
- Page 15 Count down timer also stop this function. Use the Count Down Timer to set how long the cooking The child safety device zone operates for only this one time. Set the Timer after the selection of the cooking zone. You can set the heat This function prevents an accidental operation of setting before or after you set the timer.
- Page 16 OPERATING INSTRUCTIONS (CONTINUED) Automatic modes automatic operation of the function and allows you to change the fan speed manually. When you press raise the fan speed by one. When you reach an intensive auTOmaTIC BOIlINg fryINg lIgHT level and press again you will set fan speed to 0 which deactivates the hood fan.
-
Page 17: Helpful Hints And Tips
To find the full range of rangehoods which work with this function refer to our consumer website. The • Not correct: aluminium, copper, brass, glass, Westinghouse rangehoods that work with this function ceramic or porcelain. must have the symbol FIND THE RIGHT COOKWARE Only magnetic pots and pans work with induction. - Page 18 HELPFUL HINTS AND TIPS (CONTINUED) Examples of cooking applications The relation between the heat setting and the cooking zone consumption of power is not linear. When you increase the heat setting it is not proportional to the increase of the cooking zone consumption of power. It means that the cooking zone with the medium heat setting uses less than half the power of the high setting.
-
Page 19: Care And Cleaning
CARE AND CLEANING Care and cleaning Clean the appliance after each use. Always use cookware with clean bottom. TIPS & INFORMATION IMPORTANT Scratches or dark stains on the glass ceramic have no effect on how the appliance operates. To remove the dirt: remove immediately: melted plastic, plastic foil, If the deposit does not clean off easily, use a non-abrasive and food with sugar. -
Page 20: Troubleshooting
TROUBLESHOOTING PrOBlEm POSSIBlE CauSE rEmEdy You cannot activate The hob is not connected to an electrical Check if the hob is correctly connected to or operate the hob. supply or it is connected incorrectly. the electrical supply. Refer to the connection diagram. - Page 21 PrOBlEm POSSIBlE CauSE rEmEdy There is no cookware on the zone. Put cookware on the zone. comes on. The cookware is unsuitable. Use suitable cookware. Refer to "Hints and tips". The diameter of the bottom of the cookware Use cookware with correct dimensions. Refer is too small for the zone.
- Page 22 TROUBLESHOOTING (CONTINUED) FAQs Display is flashing This is normal during power sharing mode. The power for the zone is automatically reduced to ensure the maximum power available is not exceeded. The display is switching between 2 power settings The heat setting display of the reduced zones changes between the initially selected heat setting and the reduced heat setting, it will stop switching after about 1 minute.
-
Page 23: Warranty
(c) ‘ASC’ means Electrolux’s authorised serviced centres; the Appliance; (d) ‘Westinghouse’ is the brand controlled by Electrolux Home Products In addition, Electrolux is not liable under this warranty if: Pty Ltd of 163 O’Riordan Street, Mascot NSW 2020, ABN 51 004... - Page 24 NEW ZEalaNd phone: 0800 10 66 20 email: customercare@electrolux.co.nz web: westinghouse.co.nz and WESTINGHOUSE are trademarks of Westinghouse Electric Corporation. Used under license. All Rights Reserved. Part Number: A19136414-A © 2024 Electrolux Home Products Pty Ltd ABN 51 004 762 341...
