- Page 1 High Efficiency Power Amplifier Product Instructions Model：X-DA1500EN X-DA2250EN X-DA4125EN M_2000060685_EN_1.4 M_2000061174 _FCC_1.0...
- Page 3 Precautions Danger This sign reminds users of “dangerous voltage” on the product. Caution This sign reminds users of important instructions attached to the product. In order to prevent electric shock, this equipment plug shall not be used as conductor to extend power supply Safety line.
-
Page 4: Important Safety Instructions
Ventilation To offset heat generated by the unit, it is necessary to provide ample ventilation around the unit. Avoid blocking or impeding the ventilation holes on the unit. To prevent unnecessary problems, install the unit in a place free from any vibrations, direct sunlight, humidity or dust circulation. Prevent liquids or other materials to enter cabinet If the unit gets wet or any foreign material enters the amplifier cabinet, immediately disconnect the AC power cord and consult your dealer or... -
Page 5: Network Security
• Use only with the cart, stand, tripod, bracket or table specified by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over. • Unplug this apparatus during lightning storms or when unused for long periods of time. - Page 6 • It is forbidden to communicate X-618 system with third party system unless updating the configuration. Password Precaution • Please change the password during the system deployment. • Users need to change the password regularly. • The password with six numbers is preferred.
- Page 7 Introduction The Class-D amplifies audio signal power it receives from audio input devices to maintain clarity and volume when broadcast over many speakers in X-618 PA system. Features • A CLASS-D power amplifier with high efficiency and energy conservation • Support 24V power supply backup •...
- Page 8 Front Panel(X-DA1500EN) Front Panel (X-DA2250EN) Front Panel (X-DA4125EN)
- Page 9 Indicator Light Description Power indicator. POWER The light is green when the DA is working normally. Indicates the main power supply status. If this light is turned off, the main power AC FAULT supply is operating normally. If the light turns yellow, the main power supply has experienced a fault.
- Page 10 Rear Panel (X- DA1500EN) Rear Panel (X- DA2250EN) Rear Panel (X- DA4125EN) Port Description Connects to an external audio input RJ45 Control Interface device Cooling fan...
- Page 11 If a DA fault occurs, it is protected, or FAULT it is self-tested, ports A and B experience a short circuit. Audio input Balanced positive input control Balanced negative input ports Grounding (Connect to the “-“port if 1/2/4 the input is an unbalanced input connection.) 100V 100V high impedance audio output...
-
Page 12: Technical Specifications
Technical Specifications Parameter Value Nominal output power 1 X 500W 2 X 250W 4 X 125W Main power supply ~ 100V-240V 50/60Hz voltage Backup power supply 21.5V DC ~ 28.5V DC voltage Power consumption <700W 1/3 Rated Power Working Current ≤10A/24VDC Backup Power Input Full Power Working Current ≤30A/24VDC... - Page 13 Parameter Value 2 signal lights 2 Channels 2 peak clipping lights 2 equipment protection lights 4 signal lights 4 Channels 4 peak clipping lights 4 equipment protection lights Number of channels 95%，humidity Operating conditions Operating temperature 0C~+40C Storage temperature -10C～+55C Product dimensions 482 mm×88 mm ×420 mm...
-
Page 14: Packing List
Packing List Components Qty. High Efficiency Power Amplifier （X-DA1500EN/X-DA2250EN） Network cable （X-DA4125EN） （X-DA1500EN/X-DA2250EN） Input cable terminal （X-DA4125EN） （X-DA1500EN/X-DA2250EN） Output cable terminal （X-DA4125EN） （X-DA2250EN/X-DA4125EN） Safety shield （X-DA2250EN/X-DA4125EN） Screws AC power cable Power connector kit Product manual... - Page 15 Honeywell Security and Fire 12 Clintonville Road Northford, CT 06472, USA Tel: 1-800-289-3473 www.honeywellav.com Life Safety A/V (Guangzhou) Co., Ltd Address: No. 257 Junye Road, Guangzhou GETDD East 510530, China Tel: +86 (0)20 2839 9600 Fax: +86 (0)20 2820 8706...
