VisionPRO
APPLICATION
The VisionPRO® 8000 with RedLINK™ features an
effortless, 7-Day programmable touchscreen thermostat
that provides control of temperature, humidification,
dehumidification, and ventilation for up to 4 Heat/2 Cool
heat pump systems or up to 3 Heat/2 Cool conventional
systems for residential and commercial applications.
FEATURES
• RedLINK™ Compatible
Increase your content and profit per job by including
RedLINK™ accessories that meet your customers'
comfort and convenience needs. RedLINK accessories
include the Wireless Outdoor Sensor, Portable Comfort
Control (PCC), Equipment Interface Module (EIM),
RedLINK Internet Gateway, Wireless Indoor Sensor, Tru-
eSTEAM™ humidifier with Wireless Adapter,
TrueZONE™ zoning panel with Wireless Adapter, Vent
Boost Remote and Entry/Exit Remote.
• Also Compatible with Equipment Remote Module
(ERM) ERM5220R
®
8000 with RedLINK™
• Customizable Service Reminders
Set up to 10 service reminders. Choose from the pre-set
options or customize your own. Reminders can be
based on date or the outdoor temperature.
• Universal Inputs
Thermostat - S1
EIM - S1, S2, S3, S4
Assignable inputs allow you to setup Indoor and
Outdoor Temperature Sensors, Discharge and Return
Air Sensors or Dry Contact Devices. Dry Contact
Devices can be used to trip pre-set or customized alerts
on the thermostat home screen. Note: Dry Contact
Alerts require an Equipment Interface Module (EIM).
• User Interaction Log
The interaction log stores history of thermostat setting
changes including temperature, system and installer
setup. You can use the interaction log to save time by
determining if the issue is a system error or an acciden-
tal user error. The Interaction Log is only viewable on a
computer after you download it from the thermostat to
a microSD card.
• Selectable for Residential and Light Commercial
Applications
One thermostat does it all to meet the needs of Resi-
dential and Light Commercial applications. Simply
select Residential or Commercial during the installer
setup. If Commercial is selected, the thermostat will use
commercial language, meet building codes and offer
365 day holiday scheduling.
• MicroSD Card Port for Quick Installer Setup
Save time by using a microSD card to upload installer
settings and service reminders in one simple step.
• Selectable Sensors
When paired with a Wireless Indoor Sensor(s) you have
the ability to choose which sensor(s) to use for tem-
perature, humidification and dehumidification. They
can be used in combination for temperature averag-
ing—or individually—to condition humidity levels in
separate spaces.
PRODUCT DATA
68-0312-05
