- Page 1 KINKI STUDIO EX-M1 INTEGRATED AMPLIFIER INSTRUCTION MANUAL - We are from China -...
- Page 2 KINKI STUDIO Congratulations on your purchase! Before you begin, you would need to have a CR2032 battery for the remote control. Due to restriction of shipping the lithium ion battery via courier services, we have decided to exclude the battery in the package. It should be easily available in the local hardware shop.
- Page 3 In order to obtain the best results, KINKI STUDIO insists on using the advanced technology in the audio industry, continuous improvement and refinement over the years, created KINKI STUDIO today.
- Page 4 WARNING 警 告 These instructions must be read before starting the connection or operation, otherwise the amplifier may be risk to mis-operational damage. Please read and understand the operation and application in detail below. This is a very high quality amplifier, features with new technology. It is the industry leading audio system for reproducing accurate sound.
-
Page 5: Table Of Contents
CONTENT 目 录 0 1 U n p a c k i n g - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 1 02 Place me nt &... -
Page 6: 1 U N P A C K I N G
KINKI STUDIO 1. Unpacking KINKI STUDIO EX-M1+ comes with： - Amplifier - Remote Control - Instruction Manual - El cheapo Power Cord (Please use your own audiophile power cord for best sound) Note: If the amplifier needs to be returned to the factory for servicing/warranty or secondary transportation, please use the original packaging. -
Page 7: 2. Placement & Cold Start
KINKI STUDIO 2. Placement & Cold Start KINKI STUDIO EX-M1+ amplifier, like all high-quality amplifiers, generates a certain amount of heat and must be properly dissipated. To ensure good heat dissipation and cooling, do not place temperature sensitive equipment on top of the amplifier. -
Page 8: 4 C O N N E C T I O N S
KINKI STUDIO 4. Connections Connect the power cord to the IEC inlet of the amplifier and plug it into the power plug socket. For safety reasons, a 3-wire grounding (earth) plug must be used, whenever possible. In order to get the best sound from the amplifier, avoid using any multiple plugs socket or extension cords. -
Page 9: 5 C O N T R O L
KINKI STUDIO 5. Control Power Up The power inlet IEC of the EX-M1+ is located at the rear panel. After the power is supplied to the amplifier, it will be in Standby state. Press the Power Button located at the middle of the front panel once. The display indicator light flashes signify a Start Up sequence. - Page 10 KINKI STUDIO 5. Control – Con’t Input Source Selection By turning the left knob (SELECT) to switch between Input CH1, CH2, CH3, CH4. Volume adjustment Rotate the front panel right knob (VOLUME) to adjust the volume, to reduce volume, turn left; to increase volume, turn right.
- Page 11 KINKI STUDIO 5. Control – Con’t Preamp Output The preamp output can be enabled/disabled by using Remote Control or the Power Button. Modes: • OUT1: EX-M1+ as integrated amp • OUT2: EX-M1+ power amplifier stage defeated, it works as a preamp, output via the Preamp Output RCA jack •...
-
Page 12: 6 O P T I M I Za T I O N
KINKI STUDIO 6. Optimization Placement platform The EX-M1+ has extraordinary dynamic capabilities and sound transparency. To fully unleash its performance, it must be placed on a rigid platform or proper HiFi rack. Please avoid the use of any soft materials such as carpets underneath the amplifier. -
Page 13: 7 R E M O Te C O N T Ro L
KINKI STUDIO 7. Remote Control The EX-M1+ comes with full function remote control. • POWER: On/Off EX-M1+ • MUTE: Mute Speaker Output • MODE: Preamp Output Mode Selection • DISPLAY: Off/Dim/Brighten the Display • HT BYPASS: Enable HT Bypass Mode •... -
Page 14: 8 P Ro D U C T C A Re
KINKI STUDIO 8. Product Care The EX-M1+ usually requires no maintenance and requires only occasional cleaning of the physical surface. The power must be turned off and removed before cleaning the amplifier. Clean the surface of the amplifier with a soft, slightly damp cloth. Wipe gently with a soft cloth dampened with water or a mild detergent solution. -
Page 15: Te C H N I Ca L Pa Ram E Te
KINKI STUDIO 9. Technical Parameters Frequency Response: 10-150kHz (±3dB) THDN: 0.0232%; 0.006% (A-Weighted) S/N Ratio: >103dB Output Power: 215W (8Ω), Both channel driven Damping Factor: 2000 Max Output Voltage: 55VAC AC Power: 110/240VAC, 50/60Hz (Factory configure) Input Sensitivity: 2.25Vrms - 3.6Vrms Input Impedance: 50kΩ... -
Page 16: Front Panel
KINKI STUDIO Input Selection Display Power Volume Control Front Panel... -
Page 17: Rear Panel
KINKI STUDIO 1. Loudspeaker Output 4. Fused AC Power Inlet 2. Input Signals Channel 1-4 5. Preamp Output 3. HT Bypass Signal Input 6. Gain Switch High – Normal Low – Minus 4db Gain Rear Panel... - Page 18 KINKI STUDIO...
