- Page 1 Operating Instructions X2 GREEN Line laser for horizontal and vertical operation www.sola.at...
- Page 2 (Translation of Original Version) About this Manual Congratulations on the purchase of your new X2 GREEN! You have acquired a SOLA measurement device, which can make your work easier, faster, and more precise. To utilize the complete functionality range of this measurement device, and to ensure safe operation, please observe the following instructions: ∙...
-
Page 3: Table Of Contents
1. General Information 2. Delivery Contents and Accessories Checking the Leveling Accuracy 10. Maintenance, Storage, and Transportation 3. Description 4. Technical Data 11. Troubleshooting 5. Safety Instructions 12. Disposal 13. Manufacturer’s Guarantee 6. Laser Safety / Classification 7. Getting Started www.sola.at... -
Page 4: General Information
General Information 1. General Information 1.1 Signal Words and their Meaning 1.2 Pictograms and Other Information DANGER 1.2.1 Warning Signs Warning label on packages with For an imminent danger that could lead to Li-ion rechargeable batteries. serious injury or death. Warning of dangers in general WARNING Do not heat battery above... -
Page 5: Delivery Contents And Accessories
Delivery Contents and Accessories 2. Delivery Contents and Accessories 2.1 Delivery Contents X2 GREEN 1 × Line laser X2 GREEN 4 × 1.5 V mignon (AA) batteries 1 × Case LGD0 5/8" ML 5 GREEN GREEN 2.2 Optional Accessories Laser receiver REC LGD0... - Page 6 Delivery Contents and Accessories 2.3 Delivery Contents X2 GREEN PROFESSIONAL 1 × Line laser X2 GREEN 4 × 1.5 V mignon (AA) batteries LGD0 5/8" ML 5 GREEN GREEN 1 × Wall mount WB 1 × Case 2.4 Optional Accessories...
-
Page 7: Description
Description 3. Description 3.1 Device Components, Display and Operating Elements Outlet opening laser radiation On/Off switch, transport lock Function mode status H/V button (horizontal/vertical) Battery compartment cover Tripod adapter 1/4"... - Page 8 Description 3.2 Intended Use The X2 GREEN is a line laser with which a single person is able to to locate the laser lines in poor lighting conditions, or at greater level and align both horizontally and vertically. The device is distances.
-
Page 9: Technical Data
Technical Data 4. Technical Data X2 GREEN r = 30 m* (laser line) Laser class 2, DIN EN 60825-1:2014 Application range* r = 80 m* (receiver) Measuring tolerance ±0.2 mm/m (laser lines) Tripod adapter ¼" Protection class IP54 Weight without rechargeable battery545 g Dimensions 110 ×... -
Page 10: Safety Instructions
5.1.1 Manufacturer ∙ Use of the device and the accessories without instruction. ∙ SOLA is responsible for the safe delivery condition of the product, ∙ Use of third-party accessories or additional equipment. including the operating instructions and the original accessories. - Page 11 ∙ Never open the SOLA Li-ion charger and charging station. ∙ Only use the SOLA Li-ion charger and charging station in a dry WARNING environment and do not bring them into contact with liquids. Blinding by laser radiation can indirectly lead to serious accidents, especially for people who are driving a vehicle or operating machinery.
- Page 12 Do not transport or store batteries in the pockets of garments. stations may not be used. ∙ Do not bring the battery contacts in contact with jewelry, keys, ∙ Repairs must only be performed by SOLA. or other electrically conductive objects. ∙ Do not charge the batteries. ∙...
- Page 13 Safety Instructions WARNING 5.5.1 Interference with other Devices by X2 GREEN If disposed of improperly third parties may possibly be seriously ∙ Although the product meets the strict requirements of the relevant injured and the environment polluted. directives and standards, SOLA cannot completely exclude the...
-
Page 14: Laser Safety / Classification
LASER RADIATION DON’T STARE INTO BEAM OR VIEW DIRECTLY WITH OPTICAL INSTRUMENTS CLASS 2 LASER PRODUCT DIN EN 60825-1:2014 λ=505-520nm MAX. OUTPUT <1mW SOLA-Messwerkzeuge GmbH Unteres Tobel 25 A-6840 Götzis sola@sola.at MADE IN P.R. CHINA See cover page for the type plate position. -
Page 15: Getting Started
Getting Started 7. Getting Started Open the battery compartment cover. Place the batteries in the device with the correct polarity. Close the battery compartment cover (audible click of the cover). ∙ Only use 1.5 V mignon (AA) batteries! ∙ Remove the batteries if the device is not used for an extended period. NOTICE The intensity of the laser lines may vary depending on the battery quality. -
Page 16: Operation
Operation 8. Operation 8.1 X2 GREEN If the vertical laser line is not projected perpendicular to the wall or the detection surface, unevenness can lead to incorrect 8.1.1 Switching On and Off measurement results. Ensure that the vertical line is projected perpendicular to the wall or detection surface. - Page 17 Operation 8.1.3 Creating Inclinations Outside of the Self-leveling Range Switch off X2 GREEN (On/Off switch, switch position OFF). Press and hold the “H/V” button for 3 seconds, function mode status illuminates red and the device transmits all lines from the outlet openings.
- Page 18 Operation 8.2 Applications 8.2.1 Horizontal Leveling 8.2.2 Vertical Leveling 8.2.3 90° Angle 8.2.4 Inclination 8.2.5 Working at a Distance...
-
Page 19: Checking The Leveling Accuracy
Checking the Accuracy 9. Checking the Accuracy Test the accuracy of the X2 GREEN before taking any measurement. 9.2 Checking the Leveling Accuracy of the Horizontal Line Before starting the check, let the device acclimatize to the environ- mental conditions. - Page 20 20 cm Checking the Accuracy ca. 10 m 9. Checking the Accuracy 180° 20 cm ca. 10 m Rotate the X2 GREEN by 180° and mark point on wall A. ∙ Measure vertical distance of the selected points and vertical...
-
Page 21: Maintenance, Storage, And Transportation
Maintenance, Storage, and Transportation 10. Maintenance, Storage, and Transportation 10.1 Cleaning 10.3 Transport ∙ Wipe off the dirt with a soft damp cloth. ∙ The device may be damaged if it falls or is subjected to strong ∙ Check the outlet openings of the laser distance meter regularly, vibrations. -
Page 22: Troubleshooting
Troubleshooting 11. Troubleshooting Error Possible Cause Remedy ∙ Replace battery ∙ Battery or rechargeable battery discharged ∙ Charge or replace rechargeable battery Device is switched on, display is not ∙ Battery or rechargeable battery incorrectly ∙ Insert the battery or rechargeable battery illuminated and no laser beam is visible inserted correctly... - Page 23 Troubleshooting Error Possible Cause Remedy Laser lines flash at one-second intervals ∙ Device outside of self-leveling range ∙ Align device horizontally ∙ Battery or rechargeable battery capacity is ∙ Have a rechargeable battery or new Function mode status display flashes below 10% batteries ready ∙...
-
Page 24: Disposal
Disposal 12. Disposal ∙ If disposed of improperly third parties may possibly be seriously Your SOLA dealership will accept returned batteries as well as injured and the environment polluted. old equipment, and will ensure proper disposal. ∙ Burning plastic components generate toxic fumes which may impair health. -
Page 25: Manufacturer's Guarantee
Manufacturer’s Guarantee 13. Manufacturer’s Guarantee “The manufacturer warrants to the original purchaser stated on the If the guarantee claim is justified, the manufacturer shall bear the guarantee card, freedom from defects of the device for a period of transport costs. The duration of the guarantee will not be extended two years, with the exception of batteries, from such time as the through repair or spare parts work which is carried out within the device is handed over. - Page 26 Passion for Precision SOLA-Messwerkzeuge GmbH SOLA-Messwerkzeuge GmbH & Co. KG SOLA Suisse AG Unteres Tobel 25 Heuriedweg 69 Grenzstrasse 24 6840 Götzis, Austria 88131 Lindau, Germany 9430 St. Margrethen, Switzerland T +43 5523 53380-0 T +49 8382 28585 T +41 71 740 1616 sola@sola.at, www.sola.at...
