- Page 1 Operating Instructions CROSSLINE GREEN NX Line laser for horizontal and vertical operation www.sola.at...
- Page 2 (Translation of Original Version) About this Manual Congratulations on the purchase of your new CROSSLINE GREEN NX! You have acquired a SOLA measurement device, which can make your work easier, faster, and more precise. To utilize the complete functionality range of this measurement device, and to ensure safe operation, please observe the following instructions: ∙...
-
Page 3: Table Of Contents
2. Delivery Contents and Accessories 11. Troubleshooting 3. Description 12. Disposal 4. Technical Data 5. Safety Instructions 13. Manufacturer’s Guarantee 6. Laser Safety / Classification 14. EU Declaration of Conformity 7. Getting Started 8. Operation 9. Checking the Leveling Accuracy www.sola.at... -
Page 4: General Information
General Information 1. General Information 1.1 Signal Words and their Meaning 1.2 Pictograms and Other Information DANGER 1.2.1 Warning Signs Warning label on packages with For an imminent danger that could lead to Li-Ion rechargeable batteries. serious injury or death. Warning of dangers in general WARNING Do not heat battery above 60°C. -
Page 5: Delivery Contents And Accessories
Delivery Contents and Accessories 2. Delivery Contents and Accessories 2.1 CROSSLINE GREEN NX Delivery Contents 1 line laser CROSSLINE GREEN NX 1 battery adapter BA LGD0 GREEN GREEN 3 Mignon batteries (AA) 1 wall mount WB 2.2 Optional Accessories 1 case... -
Page 6: Description
Description 3. Description 3.1 Device Components, Display and Operating Elements Outlet opening laser radiation On/Off switch, transport lock Status/battery voltage display “BATT-ON” H/V button Operating mode status “PULSE” Tripod screw connection 1/4" Battery compartment cover Rotatable stand base... - Page 7 Description 3.2 Intended Use The CROSSLINE GREEN NX is a line laser with which a single can be used to locate the laser lines in poor lighting conditions, or at person is able to level and align both horizontally and vertically.
-
Page 8: Technical Data
Technical Data 4. Technical Data CROSSLINE GREEN NX r = 25 m* (laser line) Working range* Laser class 2, DIN EN 60825-1: 2014 r = 80 m* (receiver) Tripod screw connection ¼" Max. measuring tolerance ±0.2 mm/m (laser lines) Weight without rechargeable battery450 g... -
Page 9: Safety Instructions
The operator shall ensure that the product is not utilized any ∙ The CROSSLINE GREEN NX is suitable for continuous use in an further if defects become evident, and they will have the product atmosphere which can be inhabited by humans. - Page 10 ∙ Never open the SOLA Li-Ion charger and charging station. ∙ Only use the SOLA Li-Ion charger and charging station in a dry environment and do not bring them into contact with liquids. WARNING Blinding by laser radiation can indirectly lead to serious ac-...
- Page 11 Damaged rechargeable batteries, chargers and charging and create an injury or fire hazard. stations may not be used. ∙ Repairs must only be performed by SOLA. ∙ Do not transport or store batteries in the pockets of garments. ∙ Do not bring the battery contacts in contact with jewelry, keys, or other electrically conductive objects.
- Page 12 Safety Instructions WARNING 5.5.1 Interference with Other Devices by CROSSLINE GREEN NX If disposed of improperly, third parties may possibly be seriously ∙ Although the product meets the strict requirements of the relevant injured and the environment polluted. directives and standards, SOLA cannot completely exclude the...
-
Page 13: Laser Safety / Classification
Laser Safety / Classification 6. Laser Safety / Classification The CROSSLINE GREEN NX emits two visible laser lines and WARNING one laser point. Looking directly into the laser beam with optical aids The laser is subject to class 2 according to DIN EN 60825-1:2014. -
Page 14: Getting Started
Getting Started 7. Getting Started Open the battery compartment cover. Insert the batteries into the SOLA battery adapter observing the correct polarity. Insert the SOLA battery adapter in the correct position. Close the battery compartment cover (audible click of the cover). -
Page 15: Operation
Operation 8. Operation 8.1 CROSSLINE GREEN NX If the vertical laser line is not projected perpendicular to the wall or the detection surface, unevenness can lead to incorrect 8.1.1 Switching the Laser On/Off measurement results. Ensure that the vertical line is projected perpendicular to the wall or detection surface. - Page 16 Operation 8.1.3 Creating Inclinations Outside of the Self-leveling Range Switch off CROSSLINE GREEN NX (On/Off switch, switch position OFF). Press and hold the H/V button for 5 seconds - PULSE and BATT-ON displays illuminate. To indicate that self-leveling is disabled, the lines flash every 4 seconds.
- Page 17 Operation 8.2 Applications 8.2.1 Horizontal Leveling 8.2.2 Vertical Leveling 8.2.3 90° Angle 8.2.4 Inclination 8.2.5 Working at a Distance...
-
Page 18: Checking The Leveling Accuracy
Checking the Accuracy 9. Checking the Accuracy Check the accuracy of the CROSSLINE GREEN NX before carrying 9.2 Checking the Leveling Accuracy of the Horizontal Line out every measurement. Before starting the check, let the device acclimatize to the ambient conditions. - Page 19 20 cm Checking the Accuracy ca. 10 m 9. Checking the Accuracy 180° 20 cm ca. 10 m Rotate the CROSSLINE GREEN NX by 180° and mark point on wall A. ∙ Measure vertical distance of the selected points and vertical...
-
Page 20: Maintenance, Storage, And Transportation
Maintenance, Storage, and Transportation 10. Maintenance, Storage, and Transportation 10.1 Cleaning 10.3 Transport ∙ Wipe off the dirt with a soft damp cloth. ∙ Check the outlet openings of the laser distance meter regularly, 10.3.1 General and thoroughly clean them if necessary. Do not touch the glass ∙... -
Page 21: Troubleshooting
Troubleshooting 11. Troubleshooting Error Possible Cause Remedy ∙ Replace battery ∙ Battery flat ∙ Charge or replace rechargeable battery ∙ Rechargeable battery flat Device is switched on, display is not ∙ Insert the battery / rechargeable ∙ Battery / rechargeable battery illuminated and no laser beam is visible battery correctly incorrectly inserted... - Page 22 Troubleshooting Error Possible Cause Remedy Laser lines flash at one-second intervals ∙ Device outside of self-leveling range ∙ Align device horizontally BATT-ON display flashes ∙ Battery capacity less than 10% ∙ Have new batteries ready ∙ Press H/V button for 5 seconds, or switch Laser lines flash every 4 seconds ∙...
-
Page 23: Disposal
∙ If disposed of improperly third parties may possibly be seriously injured and the environment polluted. Your SOLA dealership will accept returned batteries, as well ∙ Burning plastic components generate toxic fumes which may as old equipment, and will ensure proper disposal. -
Page 24: Manufacturer's Guarantee
Manufacturer’s Guarantee 13. Manufacturer’s Guarantee “The manufacturer warrants to the original purchaser stated on the The duration of the guarantee will not be extended through repair guarantee card, freedom from defects of the device for a period of or spare parts work which is carried out within the scope of two years, with the exception of batteries, from such time as the the guarantee. -
Page 25: Eu Declaration Of Conformity
SOLA-Messwerkzeuge GmbH auquel(s) se réfère cette déclaration est conforme aux normes. EN 61326-1: 2013 EN 61326-2-2: 2013 Mag. Wolfgang Scheyer CEO SOLA-Messwerkzeuge GmbH, Unteres Tobel 25, 6840 Götzis, Austria, T +43 5523 53380-0, sola@sola.at, www.sola.at... - Page 26 Passion for Precision SOLA-Messwerkzeuge GmbH SOLA-Messwerkzeuge GmbH & Co. KG SOLA Suisse AG Unteres Tobel 25 Heuriedweg 69 Grenzstrasse 24 6840 Götzis, Austria 88131 Lindau, Germany 9430 St. Margrethen, Switzerland T +43 5523 53380-0 T +49 8382 28585 T +41 71 740 1616 sola@sola.at, www.sola.at...
