LEICA SL3
FIRMWARE UPDATE 2.0.1
NEW
White Balance/Video ISO Lock:
Added lock function for white balance settings
and
.
Auto ISO
Auto WB
This function ensures a constant ISO value and automatic white bal-
ance during video recording until recording is stopped, or settings are
changed via menu settings.
Joystick
_Additional assignment options:
Factory setting:
AFs
is now also available for MF lenses and Leica M lenses.
Magnification
_Additional function
and
for AF-L, AE-L, and AF-L +
Click
Hold
AE-L:
In the
setting, the joystick will no longer need pressing and hold-
Click
ing, and will be simply activated and deactivated with a single click
instead.
_Additional function for the joystick assignment:
When
is selected for the joystick, AF metering via the shutter
AF-ON
button is deactivated. The metering function is instead activated by
pressing the joystick.
EN

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SL3 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Leica SL3

Summary of Contents for Leica SL3

  • Page 1 Joystick _Additional assignment options: Factory setting: is now also available for MF lenses and Leica M lenses. Magnification _Additional function for AF-L, AE-L, and AF-L + Click...
  • Page 2 IMPROVEMENT User profile: Preparation for future firmware updates. Updates for Version 2.0.0 and later will automatically apply existing settings for User profiles Language Time Date Thumbwheel: New functionality as function button Perspective Control: The perspective control function is now also available in continuous shooting mode for , and 2 fps...

  • Page 3: Capture Mode

    Review mode: Improved user interaction for the deletion of multiple shots. Connecting to Leica FOTOS App The problem of Leica FOTOS being unable to connect if another smart- phone was already connected to the camera via Wi-Fi was remedied. Exif 3.0: Support for Exif 3.0 and the GPS version 2.4.0.0 was added.

  • Page 4: Firmware Updates

    Leica will notify you of any new updates, once you have registered your camera. Users of Leica FOTOS will also be automatically notified about firmware updates for their Leica cameras.
  • Page 5 EXECUTING A FIRMWARE UPDATE Any interruption of a running firmware update may cause serious and irreparable damage to your equipment! You will therefore have to take particular note of the following, when carrying out a firmware update: • Do not switch off the camera! •...
  • Page 6 →Follow the instructions provided by the Leica FOTOS app Notes • The Leica FOTOS Version 4.8.0 or higher is required for the firmware update function of the camera. • A warning message will appear if the battery is insufficiently charged. Recharge the bat- tery and then repeat the process described above.
  • Page 7 UPDATING THE LENS FIRMWARE Where available, firmware updates can be performed for Leica SL lenses and for all other lens types by L-Mount Alliance. Firmware updates for Leica SL lenses are generally uploaded alongside the latest version of the camera firmware and will not have to be implemented manually. Provided an SL lens is attached during the camera update, it will automatically receive the latest firmware version.

  • Page 8: Iso Sensitivity

    ISO SETTINGS IN LIVE VIEW ISO SENSITIVITY The ISO setting covers a range between ISO 50 and ISO 100 000, allowing you to adapt to the relevant situation as required. There is more leeway for the use of preferred shutter-speed/aperture combinations when choosing an automatic ISO setting.
  • Page 9 DYNAMIC ISO SETTING (PHOTO/VIDEO) The left dial is preconfigured to allow manual ISO settings in real time. The setting will cycle through all available values. That means that can also be selected. When the Auto ISO lowest value is reached by turning the left dial, then will be displayed to note the transition to the setting.

  • Page 10: White Balance

    WHITE BALANCE (IM VIDEO MODE) In white balance ensures neutral color rendering in any light. White Balance relies on the setting made in the camera, which light color is to be rendered as 'white'. Five methods are available: – automatic control –...

  • Page 11: Joystick Functions

    JOYSTICK FUNCTIONS (IN SHOOTING MODE) You can assign various functions to the joystick in photo mode. The settings for AF and MF mode are done separately. AF MODE →Select in the main menu Customize Control →Select Joystick →Select AF Mode →Select the desired setting AF-L AE-L...
