  • Page 1 Instruction manual Spindle moulder TF 200 SE TF 200 SE...

  • Page 2: Table Of Contents

    Stürmer Maschinen GmbH is the sole owner of the con- tent of these operating instructions. 12.1 Ordering spare parts........17 12.2 Spare Parts Drawing TF 200 SE ....18 Forwarding and reproduction of this document as well as use and notification of its content is not permitted without 13 Electrical wiring diagram....

  • Page 3: Introduction

    This combination of symbol and signal term indica- make during application of the machine as these may be tes a immediate dangerous situation which may valuable for product improvements. cause death or serious injury if not averted. TF 200 SE | Version 1.10...

  • Page 4: Responsibility Of The Operator

    TF 200 SE | Version 1.10...

  • Page 5: Personal Protective Equipment

    Safety boots The safety boots protect the feet against crushes, fal- ling parts and slipping over on slippery under-ground. Protective clothing Protective work clothing means tight-fitting clothing with low tear resistance. TF 200 SE | Version 1.10...

  • Page 6: Intended Use

    Intended Use Intended Use Technical Data The Spindle moulder TF 200 SE is used to mill wooden Type TF 200 SE boards and strips with versatile angles. The processing Engine power 400 V / 50Hz 2,8 kW of solid wood, chipboard, panels and profiles is possible.

  • Page 7: Transport, Packaging, Storage

    The spindle moulder must be thoroughly cleaned before it is stored in a dry, clean and frost-free environment. Cover the machine with a protective tarpaulin. Ambient temperature range: -25 ° C to +55 ° C. TF 200 SE | Version 1.10...

  • Page 8: Description Of The Device

    - Milling guard hood The illustrations in these operating instructions serve the general comprehension and may deviate from the actual type. Fig. 5: Supplied material and tool for TF 200 SE 6.3 Accessories - Delivery table for TF 200 SE (Item number: 5912000) This table boom can easily be retrofitted to the machine.

  • Page 9: Setting Up The Spindle Moulder

    Step 2: Insert the two M8x150 clamp levers with the 8 mm shim into the hood and tighten the hood clockwise by turning the levers. Step 3: Slide the milling stopper onto the guide and fa- sten. Fig. 6: Mount the milling tool TF 200 SE | Version 1.10...
  • Page 10 Fig. 11: Mount holding arm Step 2: Attach the upper table boom to the machine using the two setscrew screws in the front groove in the sliding carriage. Fig. 10: Mount angle stop TF 200 SE | Version 1.10...

  • Page 11: Electrical Connection

    (Fig.12) must be loosened again slightly. Fig. 14: Adjustment in height Step 5: Place the telescopic stop on the table and clmap it at any angle. TF 200 SE | Version 1.10...

  • Page 12: Operation

    The belt should not push th- Wear Protective clothing rough more than 1/4 of the pulley diameter. If necessary, retighten the belt. Step 7: Close the door of the machine housing and tigh- ten the screws. TF 200 SE | Version 1.10...

  • Page 13: Setting The Cutter Height

    The direction of rotation of the milling cutter can be selected with a special switch. The switch has a locking mechanism that blocks direct switching of the direction of rotation with the switch. TF 200 SE | Version 1.10...

  • Page 14: Adjust The Stop

    Step 5: Place the workpiece and carry out the milling process. Step 6: After completing the milling work, switch off the machine with the red STOP button and pull out Fig. 22: Adjust the stop the power plug. Switch off the suction device. TF 200 SE | Version 1.10...

  • Page 15: Care, Maintenance And Overhaul/Repair

    - Loose screws and nuts - Worn or damaged switches - Worn or damaged router Step 8: Every 3 months, check the drive belt once a month for daily use, replace if worn or damaged. TF 200 SE | Version 1.10...

  • Page 16: Troubleshooting

    2. Machine not sufficiently secured 2. Firmly anchor the machine, the ground must be level. 3. Milling tool is damaged 3. Replace the milling tool. 4. Loose screws, nuts or bolts. 4. Tighten screws, nuts or bolts. TF 200 SE | Version 1.10...

  • Page 17: Disposal, Recycling Of Used Devices

    European countries with a separate collection sys- Example tem for these appliances). The drive belt for the Spindle moulder TF 200 SE must The symbol on the product or its packaging indi- be ordered. The drive belt has the number 22 in the cates that this product should not be treated as normal spare parts drawing 3.

  • Page 18: Spare Parts Drawing Tf 200 Se

    The following drawings are intended to help in case of service, to identify necessary spare parts. To order send a copy of the parts drawing with marked components to your dealer. Spare parts Drawing 1 Fig. 24: Spare parts drawing 1 - Spindle moulder TF 200 SE TF 200 SE | Version 1.10...
  • Page 19 Spare parts Spare parts drawing 2 Fig. 25: Spare parts drawing 2 - Spindle moulder TF 200 SE TF 200 SE | Version 1.10...
  • Page 20 Spare parts Spare parts drawing 3 Fig. 26: Spare parts drawing 3 - Spindle moulder TF 200 SE TF 200 SE | Version 1.10...
  • Page 21 Spare parts Spare parts drawing 4 Fig. 27: Spare parts drawing 4 - Spindle moulder TF 200 SE TF 200 SE | Version 1.10...
  • Page 22 Spare parts Spare parts drawing 5 Fig. 28: Spare parts drawing 5 - Spindle moulder TF 200 SE TF 200 SE | Version 1.10...
  • Page 23 Spare parts Spare parts drawing 6 Fig. 29: Spare parts drawing 6 - Spindle moulder TF 200 SE a) above; b) below TF 200 SE | Version 1.10...
  • Page 24 Spare parts Spare parts drawing 7 Fig. 30: Spare parts drawing 7 - Spindle moulder TF 200 SE TF 200 SE | Version 1.10...
  • Page 25 Spare parts Spare parts drawing 8: Table boom with telescopic crosscut fence (optional) Fig. 31: Spare parts Drawing 8 - Spindle moulder TF 200 SE TF 200 SE | Version 1.10...
  • Page 26 Spare parts Spare parts Drawing 9 Fig. 32: Spare parts Drawing 9 - Spindle moulder TF 200 SE TF 200 SE | Version 1.10...
  • Page 27 Spare parts Spare parts Drawing 10 Fig. 33: Spare parts Drawing 10 - Spindle moulder TF 200 SE TF 200 SE | Version 1.10...

  • Page 28: Electrical Wiring Diagram

    Electrical wiring diagram 13 Electrical wiring diagram Fig. 34: Electrical wiring diagram TF 200 SE TF 200 SE | Version 1.10...

  • Page 29: Ec Declaration Of Conformity

    DIN EN ISO 19085-6:2018-04 Woodworking machines - Safety - Part 6: Single spindle vertical moulding machines ("toupies") (ISO 19085-6:2017) Responsible for documentation: Kilian Stürmer, Stürmer Maschinen GmbH, Dr.-Robert-Pfleger-Str. 26, D-96103 Hallstadt Hallstadt, 13.04.2016 ______________________ Kilian Stürmer Manager TF 200 SE | Version 1.10...
