STEEL STUD WALL KIT
KIT POUR MUR ÀMONTANTS EN ACIER
KIT PARA PAREDES DE PERFILES DE ACERO
Manuel de l'utilisateur
Manual del usuario
100 lb
(45 kg)
Supporting your digital lifestyle ™
Supportant votre mode de vie digital™
Apoyo a su estilo de vida digital™
User Manual
SW-KIT
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Kanto SW-KIT
Summary of Contents for Kanto SW-KIT
- Page 1 User Manual Manuel de l’utilisateur Manual del usuario SW-KIT STEEL STUD WALL KIT KIT POUR MUR ÀMONTANTS EN ACIER KIT PARA PAREDES DE PERFILES DE ACERO 100 lb (45 kg) Supporting your digital lifestyle ™ Supportant votre mode de vie digital™...
- Page 2 Make sure there are no defective or missing parts. Do not use defective parts. Kanto cannot be liable for property damage or injury caused by incorrect mounting, incorrect assembly, lifting or incorrect use of this product. If there is hardware missing, or if you are uncertain whether a part is defective, please contact Kanto directly using one of the methods below.
- Page 3 Supplied Parts and Hardware Pièces et matériels fournis Piezas y hardware suministrados A: SNAPTOGGLE Hardware ® Matériel SNAPTOGGLE ® Alternador SNAPTOGGLE ® B: 1/4-20 x 2.5” C: 1/4” Required Tools Outils nécessaires Herramientas necesarias " Stud Finder Pencil Level Measuring Tape Drill Steel Bit Phillips Screwdriver...
- Page 4 1. Drill Holes Percez les trous Perfore los orificios CAUTION / ATTENTION / PRECAUCIÓN Stud type and structural strength must conform to the North America Specification for the Design of Cold-Formed Steel Structural Members [362 S 125 18, C-Shape, S – Stud Section]. Le type de montant et la résistance structurelle doivent être conformes à...
- Page 5 2. Install Anchors Installez les ancrages Instale les anclajes Hold metal anchor alongside plastic straps and slide anchor through hole. Tenez les sangles en plastique entre le pouce et l'index et faites glisser l'ancre dans le trou. Sostenga el anclaje metálico junto a las correas de plástico y deslice el anclaje a través del orificio.
- Page 6 2. Install Wallplate Installez la plaque murale Instala la placa de pared Mount height depends on TV size, viewing position, and personal preference. La hauteur du support varie selon la taille du téléviseur, la position de visualisation et de préférence personnelle. La altura a la que se instala el montaje depende del tamaño del televisor, la posición de visualización, y preferencias personales.
- Page 8 YU4 / YU6 TUK / YU / ORA YU6 / YU4 / ORA SP9 / SP6HD S6 / S4 / S2 SE6 / SE4 / SE2 kantoaudio.com Kanto Audio kantoaudio Kanto Solutions Kanto Living 23-L www.kantoliving.com support@kantoliving.com Toll Free: US & Canada: 1-888-848-2643...
