- Page 1 ITEM #S: KN2100-BK (Black) KN2100-OR (Orange) KNEE WALKER W/ SHOCK ABSORBERS & TOTE BAG WEIGHT CAPACITY 300 LBS...
-
Page 2: Parts Diagram
PARTS DIAGRAM 1. Handles 2. Brake with Parking Locker 3. Steering Column 4. Carry Bag 5. Triangle Knob 6. PU Pad 9. Back Wheel 7. Knob +Tenon Bolt 8. Front Wheel 9. Back Wheel 10. Clip... -
Page 3: Parts List
PARTS LIST 2 x Clips 2 x Tube Plugs 2 x Knob & Tension Bolts 4 x Triangle Knobs 2 x Five Star Knobs... - Page 4 INSTALL BACK WHEELS Step 1. Install the back wheels Take out the main frame (Figure 1). Align hole and lock the back wheel sets with clips (Figure 2 & 3). The distance between main frame and back wheels, there are 4 levels could be adjusted by clips.
-
Page 5: Install Front Wheels
INSTALL FRONT WHEELS Step 2. Install the front wheels Insert the tube plug into the square tube of the main frame on the left and right. Turn the front wheel tube downward, with the push button facing the mainframe. Insert into square tube of main frame which will make the push button pop out. - Page 6 INSTALLING STEERING COLUMN Step 3. Install the steering column Push the steering tiller upward until it’s positioned straight vertically. Lock the five star knob. Ensure the know is tightly secured in place. The five star knob is on the right side when you use the knee walker.
-
Page 7: Install Handle Bars
INSTALL HANDLE BARS Step 4. Install the handle bars Insert the handlebars into the steering column. Align holes and insert triangle knob through the steering column. - Page 8 INSTALL KNEE PAD Step 5: Install the knee pad - Insert the knee pad to desired height (Figure A). - Insert tension bolt and tight it with knob securely.(Figure B) - Move knee pad forward or backward, adjust it to your desired distance then tighten with triangle knob.
- Page 9 INSTALL BAG Step 6: Install the bag Hang the bag from the steel plate (Figure A &B), and then attach the Velcro on the bottom to make it firm enough to keep it secure when using the knee walker.（Figure C（...
-
Page 10: Check Brakes
CHECK BRAKES Step 7: Check the brake Squeeze the brake lever and push down to engage brake lock. (Figure A and B) Squeeze the brake lever again to release the brake lock. *If your brakes become loose or need to be adjusted, please contact your provider for service. - Page 11 ADJUSTING HEIGHT OF HANDLE BARS Remove five star knob. Extend handlebars up to desired height, align holes in tiller (Figure A). Insert star screw through the steering tiller. Tighten knob securely. Handlebars should be set at wrist level to keep your back straight (Figure B).
- Page 12 STORAGE Remove the five star knob under the bag and the tiller to fold into compact unit for easy storage or transportation (Figure A).
-
Page 13: Cleaning & Maintenance
USING YOUR KNEE WALKER 1. Place your hands on the handlebars 2. Place the injured leg comfortably resting on the center of the knee pad. 3. Release the brake to move yourself forward or backward slowly with small steps with your other leg, keeping the knee of your injured foot centered on the knee pad. - Page 14 For Warranty Service, it is recommended but not required, that the product be returned to the Rhythm Healthcare, LLC dealer through whom it was originally purchased. However, all Rhythm Healthcare, LLC dealers are qualified to assist you in obtaining warranty service.
- Page 15 W: www.rhythmhc.com E: contactus@rhythmhc.com V3: 8/16/24...
