Rhythm Healthcare KN1000 Quick Start Manual

OPERATING INSTRUCTIONS
Knee walker rovides strength and comfort to anyone
who may have an injury below the knee. It allows an
even distribution of body weight by supporting half
of the weight on the device and the other half on
the non-injured leg. The walker has a cushion to
support both the injured leg and the ankle to make
certain that no weight will be placed on the lower
leg. Designed for easy steering and stopping.
Brakes included.
1. With brake applied, place injured leg on knee pad
centered side to side and positioned forward, to
cover the full length of the knee pad.
2. With injured leg on knee pad, stand as straight as
possible. Adjust the height of the knee walker pad
as necessary.
3. With injured foot pointing down, the propulsion
leg should be kept as close as possible to the knee
pad.
4. Start out with small steps with the propulsion leg,
while concentrating on keeping the leg next to the
knee pad. With practice, you should be more
comfortable with moving forward without deviating
to the opposite side.
ASSEMBLY INSTRUCTIONS
1. Remove contents from carton.
2. Insert tiller into front of frame.
3. Raise the tiller and lock in place by sliding the spring
loaded lever to the right side (from the knee pad looking
forward).
4. Slide locking mechanism into groove on tiller, depress
locking handle to secure tiller lock.
5. To adjust the height of the tiller: Slide up or down until
it is in a comfortable position. Lock in place with knob and
bolt.
6. Insert knee pad post into receptacle on frame. Set to
desired height. Secure in place by inserting knob and bolt
on left side of frame facing forward and turning clockwise
until tight.
HAND BRAKE USE
1. Squeeze the lever to engage the brake.
2. To lock the brake: Pull the lever toward the
handle bar and push down the spring loaded
push button (located on the top of the brake).
When done correctly, push button will remain
down and brake lever will be locked in place.
3. To release brake: Squeeze lever. Push button
will pop up automatically.
Rhythm Healthcare, LLC
Clearwater, FL 33762
contactus rhythmhc.com
@
Website: www.rhythmhc.com
(877) 843-6464
V4: 9/15/23
