Troubleshooting - Deca Fast 20k Instruction Manual

Use as power supply
Insert the cable USB (C) into the USB socket (2)
1
Press the key(5) to ON.
2
Insert the cable in the device to be powered.
3
Use led light
Press for a few seconds the key (5) to enable the
1
continuous light.
Briefly press several times the key (5) for: the
2
intermittent light; the SOS light; turning off the LED
light.
Charging the starter
L
To obtain maximum performance charge the
appliance before each use, after use and anyway
regularly every 3 months.
L
Before charging the appliance after use, wait for the
battery cool down.
To recharge the appliance, use only the power supply
unit supplied.
¾ Charge from home mains.
Insert the power supply unit cable (E) into the socket
(3).
LED charge status
¾ Briefly press the key (5): the charge status led illuminate:
1 led on battery discharged; 4 led on battery fully charged.

Troubleshooting

L
The appliance is protected against polarity reversals,
short-circuits, overloads or deep discharge of the battery,
thermal protection.
„ By pressing the key (5) nothing happens
The starter is flat: recharge it.
„ The led (7) is red + audible alarm.
You have reversed the polarity to the battery or the
grippers are shorted circuit: check the connection.
„ The led (7) flashes red and green.
After 4 starting attempts the device protection is
automatically activated. Wait at least 2 minutes before
trying again. If you are unable to start the vehicle, ask
the help of a qualified person and do not try to start it
again.
„ The led (7) is off.
The battery of the vehicle could be damaged and does
not supply voltage. Carefully check that the connection
of the grippers is correct and the polarity of the battery
is respected. Press the key (4) "Boost" until the light is
steady green and start the engine within 30 seconds.
Fast 20k Technical Specifications
„ Lithium-polymer rechargeable sealed battery
„ Battery Capacity: 20.000mAh
„ Starting voltage 12V
„ Starting Current Max 2.000A
„ Starting current (1V/C) 600A
„ J-BME3s (Joule battery maximum energy on 3s) 12000J
„ Starting cylinders 25°C Petrol 6000cc - diesel 4000cc
„ USB output 5V 1A; 5V, 2,1A
„ Input for USB-C charger 5V, 9V
„ Charging time 7h
„ Automatic end of charge for battery protection
950702-00 02/03/20
„ Weight 650g
The exhausted battery of the starter should be recycled. In
some States recycling is mandatory: contact the local body in
charge for more information.
Do not discard the appliance into the fire.
Manufacturer's Warranty
The equipment is covered by a 12-month warranty starting
from the purchase date. The warranty period starts from
the date on which the equipment is purchased by the first
user, proved by presenting the purchase receipt showing the
purchase date and the product description. Within this period
the Manufacturer agrees to eliminate any manufacturing
defects. These defects are eliminated by repairing the
product free of charge.
The warranty excludes the following: - Parts that are subject
to normal wear and tear. - Faults originating from natural
wear, overloads or improper utilization of the equipment
outside declared performance specifications. - Minor faults,
which do not alter the value and performance of the product.
- Products tampered with or damaged by the use of non-
original accessories or spare parts.
The battery is considered a part of wear in consideration of its
normal chemical decay. Battery life is a function of its correct
use and conservation. In order to maximize the battery life, it
is recommended to follow the instructions contained in this
manual.
Appliances returned, even if they are under warranty, shall
be sent to us CARRIAGE PAID, and shall be delivered
CARRIAGE FORWARD.
These terms do not apply to appliances classified as
consumer goods according to the European Union Directive
1999/44/CE, provided that these appliances are sold in the
Member States of the European Union.
The warranty does not extend to rights other than the
elimination of defects identified in the product.
6
Autogoods "130"
Battery disposal
