Keychron Q2, Q2-C1, Q2-J1 Manual

QUICK START GUIDE

If you are a Windows user, please find the appropriate keycaps in the box, then follow the instructions below to find and replace the following keycaps.

1. Switch To The Right System

   Please make sure the system toggle in the top left corner has been switched to the same system as your computer's operating system.
2. The VIA Key Remapping

   Please visit caniusevia.com to download the latest VIA software to remap the keys. If the VIA software cannot recognize your keyboard, please reach out to our support to get the instruction.
3. The Layers
   There are five layers of key settings on the keyboard.
   The layer 0 is for the Mac system.
   The layer 1 is for the Windows system.
   The layer 2 is for the Mac Multimedia keys.
   The layer 3 is for the Windows Multimedia keys.
   The layer 4 is for the Function keys.

   If your system toggle is switched to Mac, then the layer 0 will be activated.

   If your system toggle is switched to Windows, then the layer 1 will be activated.

4. Multimedia Key and Function Key
   Multimedia keys

   Function keys

   In order to get Multimedia Key, you need to press fn1 and Key.
   In order to get Function Key, you need to press fn2 and Key.
5. The Backlight
   Press fn1 + Q to change the lighting effect

   Press fn1 + tab to turn the backlight on/off.

6. Adjust The Backlight Brightness
   fn1 + W to increase the backlight brightness

   fn1+ S to decrease the backlight brightness

7. Adjust The Backlight Speed
   Press fn1 + T to increase the light effect speed

   Press fn1+ G to decrease the light effect speed

8. Warranty
   The keyboard is highly customizable and easy to be rebuilt. If anything goes wrong with any of the keyboard components of the keyboard during the warranty period, we will on y replace the defective parts of the keyboard, not the whole keyboard.
9. Watch The Building Tutorial On Our Website
   If you are building the keyboard for the first time, we highly recommend you watch the building tutorial video on our website first, then start building the keyboard yourself.
10. Factory Reset

    Troubleshooting? Don't know what's going on with the keyboard?
    1. Try factory reset by pressing fn1+J +Z (for 4 seconds)
    2. Download the right firmware for your keyboard from our website. Remove the power cable from the keyboard.
    3. Remove the space bar keycap to find the rest button on the PCB.
    4. Hold the reset key while plugging in the power cable, and then release the reset key. The keyboard now will enter DFU mode.
    5. Flash the firmware with the QMK Toolbox.
    6. Factory reset the keyboard again by pressing fn1 + J+ Z (for 4 seconds)

* Step by step guide can be found on our website

Q2 CUSTOMIZABLE KEYBOARD SPECIFICATIONS

1. Type-C Port
2. Mac Layout
3. Windows Layout

DEFAULT KEY LAYOUT:
LAYER 0:This layer will be activated when your keyboard's system toggle is switched to Mac.

Third party input tools are not compatible with the keyboard.
Due to compatibility, versions, brands and drivers of Windows/macOS, functionalities of third Party input tools may be affected while using the keyboard. Please make sure your operating system and drivers are up to date.

Certain fn keys or multimedia keys does not work under Windows/Android mode.
Functionalities of certain multimedia keys may be disabled due to compatibility, versions, brands and drivers of Windows/Android OS.

Safety Precaution:
Keep the product, accessories and packaging parts out of reach of children to prevent any accidents and choking hazards.

Always keep the product dry to avoid corrosion.

Do not expose the product to extreme temperatures below -10C (5F) or above 50C(131F) to preserve the lifespan of the keyboard.

Q2Q2 Non-Knob Version Keymap JSON file
https://cdn.shopify.com/s/files/1/0059/0630/1017/files/Q2_ANSI_VIA_keymap_V1.0.2.json.zip?v=16392

VIA Software for macOS:
https://github.com/the-via/releases/releases/download/v1.3.1/via-1.3.1-mac.dmg

VIA Software for Windows:
https://github.com/the-via/releases/releases/download/v1.3.1/via-1.3.1-win.exe

VIA Software for Linux:
https://github.com/the-via/releases/releases/download/v1.3.1/via-1.3.1-linux.deb

How to Use VIA onYour Keychron Q Series Keyboard:
https://www.keychron.com/blogs/archived/how-to-use-via-to-program-your-keyboard
