Cloer 7521, 7520 Manual

Before the first use

  • Read these operating instructions carefully before using the appliance for the first time.
  • Remove all packing parts and possibly stickers, but not the type plate nor the serial number.
  • Clean the device with a moist cloth.
  • Place the coffee grinder on a dry, slip-resistant and level surface.

Assembly

  • To begin with, make sure that the appliance is not connected to the mains and that the standby switch is set to the OFF "O" position.
  • Prior to assembly, ensure that the grinder is free of any old coffee beans.
  • Fit the grinding ring incl. seal on the grinding cone (below the coffee bean receptacle . The three teeth of the grinding ring will fit exactly into the three notches in of the device. Beware! Sharp edges
    Assembly - Step 1
  • Attach the empty coffee bean holder to the device. Do this by aligning the triangle on the coffee bean holder with the grey mark on the appliance. Now press the coffee bean holder down and turn it clockwise towards the grinding coarseness setting.
    Assembly - Step 2
  • warningAttention! If the coffee bean container cannot be inserted correctly, the plastic ring underneath the bean container is probably not in the correct position. Proceed as follows:
    • Remove the coffee bean container and the grinding ring incl. seal.
    • Turn the plastic ring with your hands or with a screwdriver to the left as far as it will go. The arrow on the plastic ring must point to the marking on the housing .
    • Reinsert the grinding ring incl. seal and bean container. The bean container must point with the triangle to the grey marking on the machine. Press the container down and turn it clockwise to the desired grind.
      Assembly - Step 3
  • Please note that for safety reasons, your coffee grinder will not function if the coffee bean holder is not properly fitted.
  • Now place the ground coffee receptacle with its lid into position.

Operation

  • Insert the plug into the socket.
  • Select the desired coarseness , by turning the cof- fee bean holder .
    NOTE
    The lower the number, the finer the degree of grinding. The lower the number, the finer the degree of grinding.
    Operation - Step 1
  • You can also use the cup number selector for pre-setting the grinding time.
    Operation - Step 2
  • The grinder is optimised for filter coffee. A coarseness setting between 7-9 corresponds to commercially available ground filter coffee. The cup number selector (2-12) is designed to grind approx. 5-7 g of coffee per cup. The amount of ground coffee produced is also influenced by other factors such as coffee type and moisture content.
  • Pour coffee beans into the coffee bean holder (max. 300 g).
    NOTE Change coarseness setting
    In case the coffee beans have already been added, only adjust the coarseness setting.
  • Set the power switch to ON "I" to provide the electrical supply.
  • To start the device, briefly press the stop/start button
    Operation - Step 3
  • The machine stops automatically when the desired amount of ground coffee has been produced.
  • You can also turn the machine off manually by briefly pressing the stop/start button again.
    Advice about the ground coffee receptacle
    Please make sure that the ground coffee receptacle does not overflow during operation.
  • You can now remove the coffee bean holder.
  • Transfer the ground coffee directly into your coffee machine or into a storage container.
    Operation - Step 4

Ground coffee static
Due to friction produced in the conical grinder, it is unfortunately unavoidable for the ground coffee to become electrostatically charged and possibly stick to the plastic ground coffee receptacle. For easy removal of the ground coffee, we recommend tapping the ground coffee container lightly on the work surface a few times after removing it from the appliance.

  • The power consumption in stand-by mode complies to European guidelines.
  • Should you also wish to eliminate this power consumption, switch the grinder off to the "O" position by using the mains switch .

Espresso and mocha

  • Even though the coarseness setting of the coffee grinder is optimised for filter coffee, it can also be used to make espressos.
  • For espressos, the coarseness should be set below 4.
  • You can also select settings below 1. You will obtain a really fine powder by turning the dial all the way to its stop position. Depending on the coffee bean size, this may however prevent any beans from falling into the grinding mechanism.
  • As a result, the engine runs on empty and the engine noise is louder than usual. If this is the case, turn to a slightly coarser setting.
  • You cannot set the number of cups as you would with filter coffee, as it takes longer to grind coffee very finely. Turn the knob to a larger setting or start the grinding process several times over.

French Press

  • A French press requires a coarseness setting of greater than 16.
  • You can also set grinding coarseness beyond the markers along the white line. Be careful not to turn past the line however, unless you wish to remove the container. Be sure there is enough space in the coffee receptacle to allow for overfilling.
  • The coarser the coffee is ground, the more ground coffee is produced within the same period of time. For the same number of cups, grinding for a French press will produce more ground coffee than grinding at a filter coffee setting. Should this not be to your liking, you can adjust the setting higher or lower.

Cleaning

  • Pull the power plug prior to cleaning the device for safety reasons.
  • Never put the device in the dishwasher.
  • Remove the coffee bean holder and ground coffee receptacle from the device, rinse normally and allow to dry. Make sure that the coffee bean holder is empty when you remove it.
  • Wipe the housing with a moist cloth.
  • Regularly remove coffee bean residues from the grinder and grinding ring. Use the brush provided for this purpose.
  • We recommend you use a soft brush to remove any residual ground coffee that still adheres to the appliance after use.
  • Please note: When using the finer grinding settings, the passage between the grinder and the ground coffee receptacle may clog more quickly and more frequent cleaning of the machine and the cone grinder is recommended.
  • Do not use abrasive cleaning agents, cleaning sprays or scouring pads.

Cleaning the conical grinder

  • Pull the power plug prior to cleaning the device for safety reasons.
  • You can loosen the nut of the grinding cone with a size 8 open-ended spanner. To do this, you need to counter it with a screwdriver on one of the wings below the cone.
    Cleaning the conical grinder


Do not injure yourself on the sharp edges.

  • Below the locknut you will find a washer as well as a toothed washer.
  • Below it is the cone and below the cone is the win-ged ring, which can also be removed.
  • This brief disassembly step then allows you to remove the ground coffee from all components.
  • Please use the supplied brush or a damp cloth for cleaning.
  • When assembling, please make sure that the winged ring and the cone are positioned correctly.

Basic safety instructions

  • The appliance is intended to be used in household only and using in:
    • staff kitchen areas in shops, offices and other working environments, in farm houses,
    • by clients in hotels, motels and other residential type environments,
    • on bed and breakfast type environments.
  • Have repairs of Cloer electronic appliances carried out only by authorized Cloer specialist dealers or by the Cloer customer service. Improper repairs can involve substantial dangers for the user. Furthermore, this will void your warranty claims.
  • Only operate the appliance at household-usual power sockets. Check if the mains voltage stated on the type plate is up to that of your power supply network.
  • If the supply cord is damaged, it must be replaced by Cloer, its service agent or similarly qualified persons in order to avoid a hazard.
  • Pull power plug of the power socket
    • in case of a defect,
    • if the appliance is not used for a longer time,
    • before any cleaning,
    • during no supervision,
    • before removing the lid.
  • Do not stretch the feed cable over sharp edges and do not tighten it too tight, do not use it for carrying and protect it from heat (hotplate, for example).
  • This appliance can be used by people with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved.
  • This appliance must not be used by children. Cleaning and user maintenance shall not be made by children. Keep the appliance and its cord out of reach of children to ensure they do not play with it.
  • Do not use the appliance outdoors.
  • Protect the appliance from humidity (splashing water or rain)
  • More information about proper cleaning on the following pages. Do not immerse appliance in water or any other liquids.

  • The grinding ring of the coffee grinder is sharp. Danger of injury!
  • The coffee grinder is exclusively intended to grind coffee beans. Do not fill any other foodstuffs (other beans, nuts etc.) into the device.
  • The device has a capacity of max. 300 g.

    Do not fill the device with coffee beans above the edge. Please note that the ground coffee receptacle has a maximum volume of 110 g.
  • Never operate the appliance without coffee beans.
  • Never operate the appliance without the grinding ring. The grinding ring, in turn, may not be used without the fitted seal.
  • Never leave the machine unattended when in use.
  • Never use the coffee bean holder or the ground coffee receptacle without a lid.
  • Only remove the coffee bean holder when it is empty, otherwise the beans will fall through the bottom openings. If necessary, pour out the beans. First disconnect the appliance from the mains supply and remove the ground coffee receptacle.
  • Should the grinder not start properly, this could be due to trapped coffee beans. In this case, select "18" the coarsest grinding setting, and try again. You can then revert to the original grinding setting while the machine is running.

Technical Data

type volt hz watt
752 220-240 50/60 140-150
