NETGEAR C6300 Manual

Package Contents

Connection and Set Up

Connection and Set Up

  1. Connect a coaxial cable.
    Use a coaxial cable that is provided by your cable company to connect the cable port on the modem router to a cable wall outlet or a line splitter.
    warning Note: If Charter is your cable Internet service provider (ISP), Charter recommends connecting your modem router directly to a cable wall outlet. If you must use a splitter, use a splitter that is rated at 3.5 dBmv.
  1. Connect the power adapter.
    Connect the power adapter to the modem router, and plug the power adapter into an electrical outlet.
    The Power LED lights green. If the Power LED does not light, press the Power On/Off button.
  1. Connect a computer to the modem router.
    Use an Ethernet cable to connect a computer to the Ethernet port on the modem router.
    You can also connect with WiFi. Use the WiFi network name and password on the modem router label.
  1. Log in to the modem router.
    Launch a web browser. The modem router menu displays. If you do not see the modem router menu, enter http://routerlogin.net or http://192.168.0.1 in the address field of the web browser. Then enter admin for the user name and password for the password.
  1. Set up your Internet service.
    For information about how to set up your Internet service, see the other side of this installation guide.
  2. Get the genie app.
    Download the free genie app from www.NETGEAR.com/genie.

Easily share media, files, and printers on the network from your smartphone, tablet, or laptop.

Set Up Your Internet Service

  1. Contact your cable ISP and inform them that you are installing a new modem router that you bought from a retail store.
    Provide your cable ISP with the modem router's model number, which is C6300.
    warning Note: The modem router is certified by all major cable ISPs.
    You can also visit your cable ISP's website and follow the onscreen instructions to set up your Internet service.
Cable ISP Contact Information
Cablevision www.cablevision.com
www.optimum.com/contactus.jsp
Charter 1-888-438-2427
https://install.charter.com
Comcast 1-800-COMCAST (1-800-266-2278)
https://www.comcast.com/activate
Cox 1-877-891-2899
ww2.cox.com
Optimum http://play.optimum.net
https://www.optimum.net/support/phone-list
Time Warner Cable 1-800-892-2253
http://www.timewarnercable.com

warning Note: Your cable ISP's contact information might change. You can also find the contact number in your monthly Internet service billing statement.

  1. When asked, provide the modem router's serial number and MAC address on the product label on the modem router.
  2. Wait for your cable ISP to confirm that your modem router is active.
  3. If you do not have an Internet connection with the modem router, ask your cable ISP to look for your modem router online, then do one of the following depending on what your cable ISP tells you about your modem router:
    • If the modem router is not visible, your cable ISP can give you instructions to verify why the modem router does not connect with your high-speed Internet service.
    • If the modem router is visible to your cable ISP, reboot the modem router. Try checking your online status again.

Join the Modem Router's WiFi Network

To connect your computer or WiFi device (such as a smartphone or gaming device) to your modem router's WiFi network, you can use either the manual method or Wi-Fi Protected Setup (WPS) method.

Manual Method

  1. Open the soft ware utility that manages your WiFi connections on the computer or WiFi device that you want to connect to your modem router. This utility scans for all wireless networks in your area.
  2. Find and select your modem router's WiFi network name (SSID). The SSID is on the product label.
  3. Enter the modem router's password (or your custom password if you changed it) and click the Connect button. The password is on the modem router label.
  4. Repeat Step 1 through Step 3 to add other computers or WiFi devices.

WPS Method

If your computer or WiFi device supports WPS, you can use WPS to join the modem router's WiFi network.

warning Note: WPS does not support WEP security. If you are using WEP security, use the manual method.

  1. Press the WPS button on the modem router.
  2. Within two minutes, on your computer or WiFi device, press its WPS button or click its onscreen WPS button.
    warning Note: For help with the WPS button on your computer or WiFi device, check the instructions or online help that came with that computer or WiFi device. Some older equipment cannot use WPS.
    The WPS LED on the modem router lights solid green and the computer or WiFi device connects to your modem router.
  3. Repeat this process to add other computers or WiFi devices.

Support

After installing your device, locate the serial number on the label of your product and use it to register your product at https://my.netgear.com.

You must register your product before you can use NETGEAR telephone support. NETGEAR recommends registering your product through the NETGEAR website. For product updates and web support, visit http://support.netgear.com. NETGEAR recommends that you use only the official NETGEAR support resources.

For regulatory compliance information, visit http://www.netgear.com/about/regulatory/.
