- Page 1 Uninterruptible Power Supply USER MANUAL MRT 1-3kVA MODSECUR UPS...
-
Page 2: Table Of Contents
Table of contents Safety rules Transport, unpacking UPS 2.1. Rack 19’’ Installation 2.2. Tower Installation Design and connection 3.1. Rear panel view 3.2. Internal battery connection 3.3. Connecting external batteries 3.4. Power connection 3.5. Load connection 3.6. Connection of remote REPO switch 3.7. -
Page 3: Safety Rules
Uninterruptible Power Supply USER MANUAL MRT 1-3kVA 1. Safety rules This manual contains information on the safe use of the UPS. Before unpacking and installing the power supply, please read it carefully and follow its recommendations. Meets the standards - EXECUTION EN 62040-3 Uninterruptible power systems (UPS): The methods for determining the properties and test requirements. - Page 4 Uninterruptible Power Supply USER MANUAL MRT 1-3kVA - Keep this user manual! It contains important information regarding the operations of UPS which which should be used during installation and maintenance of the UPS and batteries. - If the power supply is cold and will be moved to a warm room, condensation may occur. Therefore, you should wait at least 2 hours until its launch.
-
Page 5: Transport, Unpacking Ups
Uninterruptible Power Supply USER MANUAL MRT 1-3kVA 2. Transport, unpacking UPS Check carefully that the carton and the contents are not damaged. If any damage is found, immediately notify the shipping company and distributor of power supply. Do not dispose carton of UPS. If there was not any damage carefully open the carton. -
Page 6: Design And Connection
Uninterruptible Power Supply USER MANUAL MRT 1-3kVA Step 1 Step 2 Step 3 3. Design and connection 3.1. Rear panel view MODSECUR UPS | 6... -
Page 7: Internal Battery Connection
Uninterruptible Power Supply USER MANUAL MRT 1-3kVA Programmable output sockets: can be switched o , suitable for less critical applications. Critical output connections : to connect receivers critical. The voltage on these slots is non-stop as soon as the UPS is in normal mode or with a battery. Supply socket. -
Page 8: Power Connection
Uninterruptible Power Supply USER MANUAL MRT 1-3kVA Warning! The maximum number of battery modules to connect is 4. When attaching additional battery modules, the UPS must be checked and possibly adjusted for the connected capacity of the battery. 3.4. Power connection Connect the power supply to an electrical outlet that is equipped with a protective conductor with a conductor supplied by the manufacturer. -
Page 9: Load Connection
Uninterruptible Power Supply USER MANUAL MRT 1-3kVA 3.5. Load connection The UPS has been equipped with standard IEC 320 sockets. The IEC 320 C13 - C14 (10A) or IEC 320 C19-C20 (16A) cables are required to connect the receivers. 1 - 3kVA UPSs are equipped with 8 IEC 320 - C13 (10A) sockets. -
Page 10: Connection Of Tvss
Uninterruptible Power Supply USER MANUAL MRT 1-3kVA To enable automatic management and monitoring of the UPS, connect the UPS supplied with the UPS, from one side to the USB port on the UPS and the other to the USB port on the computer. Delivered with UPS software allows you to automate the on / o processes of the UPS connected to the UPS depending on the events that occur on the UPS (eg power outage, low battery, overload, etc.). -
Page 11: Lcd Panel
Uninterruptible Power Supply USER MANUAL MRT 1-3kVA 4.2. LCD panel Display Function Information on time autonomy Displays estimated autonomy time of the power supply H: hours, M: minutes, S: seconds Con guration and error information Displays the value of the parameter. A description of possible indications is contained in subsection 3.5. -
Page 12: Alarm Signals
Uninterruptible Power Supply USER MANUAL MRT 1-3kVA Display Function Information on the operation Indicates that the UPS is connected to a 230V network. Indicates that the UPS is running on battery. Indicates that the UPS is in Bypass mode. Indicates that the ECO mode is on. Indicates that the UPS inverter is working. -
Page 13: Lcd Display Letter Abbreviations
Uninterruptible Power Supply USER MANUAL MRT 1-3kVA 4.4. LCD display letter abbreviations Short Display Meaning Enabled Disabled Escape High Loss Low Loss Battery Capacity Ah Current of charger Boost voltage Float voltage Converter Turn on EPO – emergency power o EPO NC active EPO NO active Temperature... -
Page 14: Menu Ups
Uninterruptible Power Supply USER MANUAL MRT 1-3kVA 4.5. Menu UPS Use of the UPS con guration menu is possible when the UPS is o (stand-by mode). To enter the con guration menu, press SELECT for 3 seconds as described in chapter 4.1. View con guration menu and description of setting options below. - Page 15 Uninterruptible Power Supply USER MANUAL MRT 1-3kVA Display Settings 05 – AECO Availability of advanced economic mode (AECO mode) ENA: AECO function available DIS: AECO function unavailable (default) 06 – Voltage tolerance range in ECO / AECO mode Setting the lower and upper power supply tolerances for ECO / AECO mode. HLS: Upper voltage supply voltage range.
- Page 16 Uninterruptible Power Supply USER MANUAL MRT 1-3kVA Display Settings 11 - Setting the time for the availability of voltage on the programmable sockets Setting the timeout of devices connected to the sockets programmable from 0 to 999 minutes in battery mode. The time is counted from the time the UPS enters the battery mode.
- Page 17 Uninterruptible Power Supply USER MANUAL MRT 1-3kVA Display Settings 17 – EPO action logic setting Setting EPO input logic. AO: Active opening - indicates the state of the EPO pins in the NC con guration (normally closed). Disconnected means EPO activation (default). AC: Active closed - indicates the status of the EPO pins in the NO (normally open) con guration.
-
Page 18: Error Codes
Uninterruptible Power Supply USER MANUAL MRT 1-3kVA Mode Mode Display Bypass mode If the supply voltage is within tolerable tolerances but an overload or any other event occurs, the UPS switches to Bypass mode. The sound signal is issued every 10 seconds. UPS is o , no voltage is output. -
Page 19: Operating The Ups
Uninterruptible Power Supply USER MANUAL MRT 1-3kVA Warning Icon Alarm Beep every 2 seconds EPO active Beep every second Overheated Beep every second Charger fail Beep every 2 seconds Battery fail (UPS is turn o ) Beep every 2 seconds Bypass out of tolerance Beep every 2 seconds Unstable bypass... -
Page 20: Software Installation
Uninterruptible Power Supply USER MANUAL MRT 1-3kVA 5.5. Software installation To fully utilize the UPS capability, you must install the supplied ViewPower communication software. Follow the instructions that appear on the computer screen during installation. When the installation process is complete, restart the computer. Restarting your computer will automatically launch ViewPower, which is re ected in the ViewPower icon in the Windows system tray. - Page 21 Uninterruptible Power Supply USER MANUAL MRT 1-3kVA Replacing the battery according to the recommendations below is safe for the user. Only use batteries that are identical to the original capacities, voltages and dimensions. When the batteries are disconnected, the receivers are not protected from power failure. The battery must not be replaced when the UPS is in battery mode! MODSECUR UPS | 21...
