Baby Jogger City Mini - Baby Stroller Manual

WARNING

Keep these instructions for future reference.

Read these instructions carefully before use. Your child' s safety may be affected if you do not follow these instructions.

SINGLE STROLLER

• This stroller seats one passenger
• This vehicle is suitable from birth to 5 years Maximum weight: 15 kg, maximum height: 111.8 cm
• Total weight load recommended for this stroller is 20.5 kg (15 kg in seat, 1 kg in seat back pocket, 4.5 kg in basket)
•
  This stroller is not suitable for running, jogging, skating or rollerblading
•
  Never leave your child unattended
•
  Always use the restraint system
•
  Child may slip into leg openings and strangle. Never use in reclined carriage position unless safety harness is properly fastened
•
  Check that the pram body or seat unit attachment or car seat attachment devices are correctly engaged before use
•
  To avoid injury, ensure that your child is kept away when unfolding and folding this product
•
  Do not let your child play with this product
•
  Parcels or accessory items, or both, placed on the unit may cause the unit to become unstable
•
  Any load attached to the handle affects the stability of the pushchair
• Recommended weight for seat back pocket is 1 kg and basket is 4.5 kg. Excessive weight may cause a hazardous unstable condition to exist
• Stroller is not meant to be used for transporting children up or down stairs. Damage resulting to stroller will not be covered under warranty
• Accessories which are not approved by the manufacturer or distributor shall not be used
• Watch out for cars - never assume that a driver can see you and your child
• The passenger shall remain seated (no standing in the stroller)
• It may be unsafe to use replacement parts other than those supplied or approved by the manufacturer
• The product may become unstable if a parcel bag, other than one recommended by the manufacturer, is used
• Always keep fingers away from moving parts when folding, unfolding, or adjusting the stroller to prevent entrapment or pinching
• This stroller does not replace a cot or a bed. Should your child need to sleep, then it should be placed in a suitable pram body, cot, or bed
• The seat should be used in the most reclined position until a child can sit up unaided, rollover, or push itself up on it' s hands and knees

FEATURES

1. Handlebar
2. Weather Cover
3. Auto-lock
4. Accessory Mounting Bracket
5. Safety Strap
6. Rear Wheel Release Button
7. Rear Wheel
8. Parking Brake
9. Storage Basket
10. Front Wheel
11. Swivel Lock
12. Front Wheel Release Button
13. Footwell
14. Fold Handle
15. Harness Buckle
16. Harness Pads
17. Canopy

FRAME

1. Unpack the stroller frame from the box and set the wheels aside

2. Unfold the stroller by pulling the Autolock Lever and lifting the handlebar away from the lower frame The stroller will click into place

3. Place the stroller in the upright position

4. Snap the red Safety Strap to the frame under the fold mechanism before use


Ensure that all the locking devices are engaged before use

FRONT WHEELS

1. Installation

   • Lay stroller on its back so the Handlebar is resting on the floor
   • Attach the Front Wheel by sliding it into the front wheel mount until it clicks. Gently pull on the Front Wheel to make sure it is properly attached
2. Removal

   • While pressing the front wheel release button, gently slide the Front Wheel out of the front wheel mount

SWIVEL FEATURE

1. Raise the Swivel Lock to allow the front wheel assembly to swivel

2. Press down on the Swivel Lock to lock the front wheel assembly in a fixed position for long distance strolling


NOTE: When loading and unloading child, lock the front wheel in a fixed position. Although the front wheel of your stroller locks, it is not intended for jogging or exercise purposes.

REAR WHEELS

1. Installation

   • Align the Rear Wheel axle with the wheel mount on the stroller frame and insert it into the wheel mount until it clicks into place
   • Gently pull on the Rear Wheel to make sure it is properly attached
2. Removal

   • While pressing the Wheel Release Button, gently slide the Rear Wheel out of the wheel mount

BRAKE

1. Simply push the parking brake pedal down to engage the brakes

2. Lift it up to release


Engage the parking device before loading and unloading a passenger

CANOPY

1. Attach the canopy to the frame: Slide the canopy peg into the top hole of the Accessory Mounting Bracket until it clicks into place

2. At the top and on the side of the Canopy, snap the webbing together around the top of the frame on both sides

3. Secure the canopy by aligning the Velcro strips on the console and canopy

4. Remove the canopy: Press the top gray button on the Accessory Mounting Bracket to release the canopy peg and unfasten snaps and Velcro at the top of the canopy


SAFETY HARNESS

1. From the back of the seat, open Velcro pocket and locate the plastic square stopper. Turn stopper and pass through the openings in the PE board and seat fabric

2. Reinsert stopper at seat opening closest to child' s shoulders. Pass back through seat fabric and PE board. Tug on strap to ensure stopper is engaged. Repeat on both sides


Avoid serious injury from falling or sliding out Always properly adjust and fasten safety harness

Always use the crotch strap in combination with the shoulder straps and waist belt

3. Slide the Harness Pads up to access plastic guide on strap

4. Hold the plastic guide and pull strap to tighten or loosen

5. Insert side strap buckle into harness buckle on both sides

6. Insert connected harness and side strap buckles into the sides of the crotch buckle

7. Press button on crotch buckle to release


SEAT RECLINE

1. Pinch the clamp behind the seat, and slide it down to desired recline

2. Pull seat down on both sides to match recline position of clamp. Reverse steps to return to the upright position


WEATHER COVER

3. If desired, pull the weather cover down and over the seat back mesh. Secure firmly over both sides of the seat. When not in use, roll up the weather cover and fasten it with the elastic loop and barrel provided under the canopy fabric


SEAT REMOVAL

1. Remove the canopy. Starting with the top snap closest to the handle and working your way down the entire frame, unsnap seat from frame

2. Unfasten seat straps from around the bottom/back of the frame, located behind the Front Wheel

3. Locate the fold strap rings connected to the stroller frame underneath the stroller seat. Unscrew the fold strap rings and unhook from the fold mechanism


BASKET REMOVAL

1. From the rear of the stroller: Unsnap the top snaps of the Basket from around the frame tubing above the middle crossbar. Unsnap the bottom snaps of the basket from around the frame tubing below the middle crossbar

2. From the front of the stroller: Unsnap lower seat fabric to expose the bottom front portion of frame. Unfasten the hook-and-loop tab from around the frame tubing. Snap the seat fabric to the frame once complete


QUICK FOLD TECHNOLOGY

1. Remove the child from the seat. Unsnap the red Safety Straps from the Frame

2. Pull upwards on the "Pull to Fold" Fold Handle with a gentle tug and your stroller will fold in half


Always be sure the safety strap is securely snapped onto the frame before using stroller!

CARE AND MAINTENANCE

To preserve the longevity of your stroller, it is important to perform simple, regular maintenance. From time to time, make sure that the joints and folding areas are still in good condition. If you hear any squeaking or feel tension, you can take your stroller to a local bike shop for added lubrication. All repairs should only be carried out by an authorized dealer.

WASHING

Seat Fabric

• You can machine wash your stroller's seat in cold water with a mild detergent
• Be sure to remove the metal frame and PE boards from the seat before washing
• Do not use solvents, caustic or abrasive cleaning materials
• To minimize shrinkage, simply reattach the seat to the frame to dry
• Do not press, iron, dry clean, tumble dry or wring the fabric
• If the seat covers need to be replaced, only use parts from a Baby Jogger Authorized Dealer. They are the only ones that are guaranteed to have been safety tested and designed to fit this seat

Plastic/Metal Parts

• Wipe clean using a mild soap and warm water
• You must not remove, dismantle or alter any part of the seat folding mechanism or brakes

Wheel Care

• The wheels can be cleaned using a damp cloth. They will need to be dried completely with a soft towel or cloth

STORING

• Sunshine can fade seat fabric and dry out tires, so storing your stroller indoors will prolong its good looks
• DO NOT store outside
• Ensure that the stroller is dry before storing for prolonged periods
• Always store the stroller in a dry environment
• Store the stroller in a safe place when not in use (i.e. where children cannot play with it)
• DO NOT place heavy objects on top of the stroller
• DO NOT store the stroller near a direct heat source such as a radiator or fire

PRODUCT LIMITED WARRANTY

If your stroller was purchased outside of the United States, please contact the distributor in the country nearest you. Their contact information can be found on our website at http://www.babyjogger.com/retailers/#international.

NOTE: When contacting Baby Jogger distributor regarding your stroller, please have your stroller's serial number and manufacturing date ready.
It can be found on the right fold mechanism
