RIDGID SeeSnake CS6x VERSA Operator's Manual
Hide thumbs
Also See for SeeSnake CS6x VERSA:
- Operator's manual (20 pages) ,
- Operator's manual (20 pages) ,
- Operator's manual (20 pages)
Advertisement
Quick Links
WARNING!
Read this Operator's Man-
ual carefully before using
this tool. Failure to under-
stand and follow the con-
tents of this manual may
result in electrical shock,
fire, and/or serious per-
sonal injury.
Operator's Manual
For support and additional informa-
tion about using your CS6x Versa go to
support.seesnake.com/cs6xversa or
scan this QR code.
Companion Apps
Available
Advertisement
Related Manuals for RIDGID SeeSnake CS6x VERSA
Summary of Contents for RIDGID SeeSnake CS6x VERSA
- Page 1 Operator’s Manual Companion Apps Available WARNING! Read this Operator’s Man- ual carefully before using this tool. Failure to under- stand and follow the con- For support and additional informa- tents of this manual may tion about using your CS6x Versa go to result in electrical shock, support.seesnake.com/cs6xversa or fire, and/or serious per-...
-
Page 2: Table Of Contents
Pre-Operation Inspection..................6 SeeSnake CS6x Versa Overview Description........................ 7 Components ......................9 Operating Instructions SeeSnake CS6x Versa Safety ................10 Inspection Overview ....................11 Connecting to a Camera Reel ................11 Powering the System ....................11 Keypad ........................12 User Interface ......................14 Viewing System Mounting the CS6x Versa .................. -
Page 3: Regulatory Statements
This symbol indicates the risk of operation. electrical shock. UK lmporter Ridge Tool UK (RIDGID) 70 Gracechurch Street London EC3V 0HR, UK Contains Transmitter Module FCC ID: Z64- WL18SBMOD. CS6x Versa – English – 3... -
Page 4: General Safety Rules
• If using drain cleaning equipment and ment or plugs with wet hands can in- drain inspection equipment at the crease the risk of electrical shock. same time, wear RIDGID drain clean- ing gloves. Never grasp the rotating 4 – English – CS6x Versa... -
Page 5: Equipment Use And Care
• Use only accessories that are rec- cause hand injuries. Only wear latex or ommended by the manufacturer for rubber gloves underneath RIDGID drain your equipment. Accessories that may cleaner gloves. Do not use damaged be suitable for one piece of equipment drain cleaning gloves. -
Page 6: Pre-Operation Inspection
• Under abusive conditions, liquid may • The presence of flammable liq- eject from battery; avoid contact. If uids, vapors, or dust that may ig- contact occurs, flush with water. If liquid nite. If present, do not work in area contacts eyes, seek medical help. -
Page 7: Seesnake Cs6X Versa Overview
SeeSnake CS6x Versa Overview Description Download HQx Live, the free iOS The RIDGID SeeSnake CS6x Versa ™ ® ® ™ Android companion app to use your mo- ™ Wi-Fi-enabled reporting monitor is an er- bile device as a second screen. Using the gonomic, all-in-one solution for capturing CS6x Versa’s built-in Wi-Fi, pair a smart-... - Page 8 Brightness 460 cd/m temperatures. Media Standard video MPEG4 (H.264) Standard Equipment MPEG4 (H.264) • SeeSnake CS6x Versa Low, variable Autolog video frame rate for • AC Adapter (USA) decreased file size • AC Adapter (Europe) Photo • Operator’s Manual MPEG4 (H.264)
-
Page 9: Components
Components Note: The maximum USB drive length for the USB port cover to close is 50 mm [2 in]. Mounting Frame USB Port USB Status LED Keypad Microphone Speaker USB Port Cover Auxiliary Power Port for Front AC Adapter Cover LCD Display Screen Transmitter Clip-On Terminal... -
Page 10: Operating Instructions
Never carry the Compact SeeSnake CS6x Versa Safety series reel by the CS6x Versa’s handle • Read and understand this manual, the when transporting the system. Always... -
Page 11: Inspection Overview
Inspection Overview Connecting to a Camera Reel WARNING The CS6x Versa can connect to any SeeSnake camera reel with the SeeSnake system cable. 1. Pull back the outer locking sleeve on the system cable connector. Wear appropriate protective equipment 2. Align the connector ridge and plastic such as latex or rubber gloves, goggles, guide pin with the socket and push the face shields, and respirators when in-... -
Page 12: Keypad
Keypad Keys and Functions Keypad Key Name Function Power Power on and off. Navigate through menus and screens and increase or Arrows decrease volume during playback. Press left, right, or down arrow in live feed for Quick Access Menus. Select highlighted items and apply changes. When Select/Pause recording standard video or Autolog video, press to pause and resume recording. - Page 13 Keys and Functions Keypad Key Name Function Control the brightness of the LEDs in the camera. Brightness Long press (>3 seconds) to set the system measurement to zero at the beginning of an Zero inspection. Short press (<1 second) to start and stop temporary segment measurements.
-
Page 14: User Interface
User Interface User Interface Time and Date Options: Show time only, date only, both, or neither. Overlay Wi-Fi not connected. Wi-Fi connected. Connectivity Bluetooth enabled but not connected. Bluetooth connected. Sonde Sonde enabled and transmitting. Microphone enabled. Microphone Audio recording in progress. Microphone disabled. - Page 15 User Interface Photo captured. PhotoTalk media created. ™ Video recording. Media Video recording paused. Capture Icons Autolog video recording. Autolog video recording, motion detected. Autolog video recording paused. Open Job A job is open. USB drive inserted. Safe to remove the USB drive. Do not remove the USB drive! Media is being written to the USB drive.
-
Page 16: Viewing System
Viewing System Docking The CS6x Versa is designed to dock onto The CS6x Versa’s position can be adjusted the Compact M40, Compact C40, and to create a desired viewing angle. Grasp the Compact2 reels. mounting frame and rotate the kickstand to adjust the viewing angle. -
Page 17: Removing The Monitor
Removing the Monitor Docking Placement The monitor can be docked onto the reel 1. Place the Compact reel so you can while mounted in either the low or high po- grasp both quick-release knobs. sition. Mount the CS6x Versa in the desired 2. -
Page 18: Maintenance And Support
Maintenance and Transport and Storage Support Store and transport your system with the fol- lowing in mind: Product Support • Store in a locked area out of the reach of children and people unfamiliar with For support and additional information its purpose. -
Page 19: Service And Repair
Service and repair of the CS6x Versa must found locally. Dispose of the components in be performed at a RIDGID Independent compliance with all applicable regulations. Authorized Service Center. To maintain the... - Page 20 RIDGID and the RIDGID logo are trademarks of Ridge Tool Company, registered in the USA and other countries. All other registered and unregistered trademarks and logos mentioned herein are the property of their respective owners.
