Double Insulated
Laminate Trimmer
Please make certain that the person who is
to use this equipment carefully reads and
understands these instructions before
starting operations.
The Model and Serial No. plate is located on the main
housing of the tool. Record these numbers in the
spaces below and retain for future reference.
Model No. ______________________________________
Type ___________________________________________
Serial No. _______________________________________
ESPAÑOL: PÁGINA 11
FRANÇAISE : PAGE 23
MODEL 309
IMPORTANT
Part No. 890870 - 04-05-02
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Porter-Cable 309
Summary of Contents for Porter-Cable 309
- Page 1 Instruction Laminate Trimmer manual MODEL 309 IMPORTANT Please make certain that the person who is To learn more about Porter-Cable to use this equipment carefully reads and visit our website at: understands these instructions before http://www.porter-cable.com starting operations. The Model and Serial No. plate is located on the main housing of the tool.
-
Page 2: General Safety Rules
890870 - 04-05-02.qxd 4/16/02 11:46 AM Page 2 WARNING: SOME DUST CREATED BY POWER SANDING, SAWING, GRINDING, DRILLING, AND OTHER CONSTRUCTION ACTIVITIES contains chemicals known to cause cancer, birth defects or other reproductive harm. Some examples of these chemicals are: ·... - Page 3 890870 - 04-05-02.qxd 4/16/02 11:46 AM Page 3 Dress properly. Do not wear loose clothing or jewelry. Contain long hair. Keep your hair, clothing, and gloves away from moving parts. Loose clothes, jewelry, or long hair can be caught in moving parts. Avoid accidental starting.
- Page 4 WARNING: There are certain applications for which this tool was designed. Porter-Cable strongly recommends that this tool NOT be modified and/or used for any application other than for which it was designed. If you have any questions relative to its application DO NOT use the tool until you have written Porter-Cable and we have advised you.
-
Page 5: Replacement Parts
When servicing use only identical replacement parts. MOTOR Many Porter-Cable tools will operate on either D.C., or single phase 25 to 60 cycle A.C. current and voltage within plus or minus 5 percent of that shown on the specification plate on the tool. Several models, however, are designed for A.C. -
Page 6: Functional Description
4/16/02 11:46 AM Page 6 FUNCTIONAL DESCRIPTION FOREWORD Model 309 Porter-Cable Laminate Trimmer can make both flush and shallow bevel cuts, using self-piloting bits. ASSEMBLY TO INSTALL BIT CAUTION: DISCONNECT TOOL FROM POWER SOURCE. Loosen clamping knob and lower the power unit to expose the collet nut. -
Page 7: Operation
890870 - 04-05-02.qxd 4/16/02 11:46 AM Page 7 TO REMOVE BIT Follow steps one through five under TO INSTALL BIT. Place one wrench on flats of shaft directly above collet nut. Let far end of wrench rest on bench to your left. Place other wrench on collet nut and turn counterclockwise and loosen only enough to allow removal of bit. -
Page 8: Maintenance
890870 - 04-05-02.qxd 4/16/02 11:46 AM Page 8 CARE OF CARBIDE BITS Please read these suggestions carefully. They will help you obtain maximum benefits from the use of carbide bits. Never drop a carbide tool. Never let it strike against anything. A sharp blow may cause the carbide to crack or shatter. -
Page 9: Service And Repairs
(model number, type, serial number, etc.). ACCESSORIES A complete line of accessories is available from your Porter-Cable • Delta Supplier, Porter-Cable • Delta Factory Service Centers, and Porter-Cable Authorized Service Stations. Please visit our Web Site www.porter-cable.com... - Page 10 PORTER-CABLE LIMITED ONE YEAR WARRANTY Porter-Cable warrants its Professional Power Tools for a period of one year from the date of original purchase. We will repair or replace at our option, any part or parts of the product and accessories covered under this warranty which, after examination, proves to be defective in workmanship or material during the warranty period.
- Page 11 Pour obtenir des pièces et accessoires pour les produits Porter-Cable • Delta, s’adresser à tout distributeur Porter- Cable • Delta, centre de service agréé ou centre de service d’usine Porter-Cable • Delta. Si vous n’avez accès à aucun de ces centres, appeler le 888-848-5175 et on vous dirigera vers le centre de service d’usine Porter-Cable •...
