Register your product and get support at
Register your product and get support at
www.philips.com/welcome
www.philips.com/welcome
EN
User manual
FR
Manuel de l'Utilisateur
ES
Manual del usuario
EN: For further assistance, call the customer support service in your country.
•
To obtain assistance in the U.S.A., Canada, Puerto Rico, or the U.S. Virgin Islands, contact Philips
Customer Care Center at 1-866-309-0866
•
To obtain assistance in Mexico, contact Philips Customer Care Center at 01 800 504 62 00
FR: Pour obtenir de l'aide supplémentaire, communiquez avec le centre de service à la clientèle de
votre pays.
•
Pour obtenir de l'aide aux États-Unis, au Canada, à Puerto Rico ou aux Îles Vierges américaines,
communiquez avec le centre de service à la clientèle Philips au : 1-866-309-0866
•
Pour obtenir l'aide au Mexique, entrez en contact avec le centre de soin de client de Philips à
01 800 504 62 00
ES: Para obtener más información, llame al servicio de soporte al cliente de su país.
•
Para obtener asistencia en los Estados Unidos, en Canadá, Puerto Rico o en las Islas Vírgenes de los
Estados Unidos, comuníquese con Centro de atención al cliente de Philips al 1-866-309-0866
•
Solo para Mexico CENTRO DE ATENCIÓN A CLIENTES LADA. 01 800 504 62 00 Solo
Para México.
BDP5010
HTS3051BV/F7
HTS3051BV/F8
Advertisement
Table of Contents
Troubleshooting
Subscribe to Our Youtube Channel
Related Manuals for Philips HTS3051
Summary of Contents for Philips HTS3051
-
Page 1: En User Manual
à la clientèle Philips au : 1-866-309-0866 • Pour obtenir l’aide au Mexique, entrez en contact avec le centre de soin de client de Philips à 01 800 504 62 00 ES: Para obtener más información, llame al servicio de soporte al cliente de su país. -
Page 2: Precautions
Registering your model with PHILIPS makes you eligible for all of the valuable benefits listed below, so don't miss out. Complete and return your Product Registration Card at once, or register online at www.philips.com/welcome to ensure:... -
Page 3: Important Safety Instructions
PRECAUTIONS IMPORTANT SAFETY INSTRUCTIONS 1. Read these instructions. 10. Protect the power cord from being walked on or pinched particularly at plugs, convenience 2. Keep these instructions. receptacles, and the point where they exit from the 3. Heed all warnings. apparatus. - Page 4 PRECAUTIONS IMPORTANT COPYRIGHT INFORMATION Unauthorized copying, broadcasting, public performance and lending of discs are prohibited. This item incorporates copy protection technology that is protected by U.S. patents and other intellectual property rights of Rovi Corporation. Reverse engineering and disassembly are prohibited. Do not place the unit on the furniture that is capable of being tilted by a child and an adult leaning, pulling, standing or climbing on it.
-
Page 5: Maintenance
Notice Specifications are subject to change without notice. Servicing Trademarks are the property of Koninklijke Philips Electronics N.V. or their respective owners. P&F USA • Please refer to relevant topics on “TROUBLESHOOTING” reserves the right to change products at any time without on page 56 before returning the product. -
Page 6: Important
PRECAUTIONS Important Supplied Accessories Registering your model with Philips makes you eligible for all of the valuable benefits listed below, so don’t miss out. Complete and return your Product Registration Card at User Manual once, or register online at www.philips.com/welcome to... -
Page 7: Trademark Information
PRECAUTIONS Trademark Information “BONUSVIEW” is trademark of Manufactured under license Blu-ray Disc Association. from Dolby Laboratories. “Dolby”, “Pro Logic”, and the “BD-Live” and “BD-Live” logo double-D symbol are are trademarks of Blu-ray Disc trademarks of Dolby Association. Laboratories. Manufactured under license VUDU™... -
Page 8: Table Of Contents
CONTENTS Introduction Precautions ..............2 Special Playback ............32 Maintenance ................5 Fast Forward / Fast Reverse ..........32 Notice ....................5 Slow Forward Playback ............32 Important ..................6 Step by Step Playback ............32 Supplied Accessories ...............6 Repeat Playback ..............32 Trademark Information ............7 A-B Repeat .................32 Features ................ -
Page 9: Features
FEATURES Congratulations on your purchase, and welcome to Philips! To fully benefit from the support that Philips offers, register your product at www.philips.com/welcome. Pop-up menu Features Some BD-videos have a pop-up menu which is a navigation menu that can be called up and be operated on the TV screen Blu-ray Disc without interrupting playback. -
Page 10: Product Info
“Product Info” screen provides information about this unit’s hardware and software version. You can also download the latest software from the Philips web site and upgrade it yourself if it is newer than the version currently on your unit. The current version of software on your unit can be seen on the "Product Info"... -
Page 11: Functional Overview
FUNCTIONAL OVERVIEW Front Panel 5 6* * The unit can also be turned on by pressing these buttons. Q (standby/on) button SOURCE button • Press to turn on the unit, or to turn the unit into the • Press to switch the active source mode. standby mode. -
Page 12: Remote Control
FUNCTIONAL OVERVIEW Remote Control K / L / s / B buttons DISC: • Press to select items or settings. RADIO: • Press up or down to tune the radio frequency. • Press left or right to start auto search. OK button •... - Page 13 FUNCTIONAL OVERVIEW 24. SURROUND button Note • Press to select surround mode. 25. d (mute) button Incorrect use of batteries can result in hazards such as • Press to mute the volume. leakage and bursting. Please observe the following: 26. D (forward) button •...
-
Page 14: Front Panel Display
FUNCTIONAL OVERVIEW Front Panel Display * Brightness of the display can be adjusted. Refer to “Front Panel Brightness” in “LIST OF SETTINGS” on page 42. 1. Displays repeat icon. (Appears during repeat playback.) 2. Displays media mode icon (disc mode or SD card mode). 3. -
Page 15: Guide To On-Screen Display
FUNCTIONAL OVERVIEW Guide to On-Screen Display Home Menu When you turn on the unit, home menu will appear automatically. Otherwise, press [ (home)]. Blu-ray Disc Home Theater System Disc Tray SD Card External audio input Settings Product Info Watch HD movies “Disc Tray”... -
Page 16: Connections
CONNECTIONS Placing the Speakers The Philips Blu-ray Disc Home Theater is simple to install. However, proper system placement is critical to ensure an optimum sound experience. 1) Place the main unit near to the TV. 2) Place the speakers system at normal listening ear-level and directly parallel to the listening area. - Page 17 CONNECTIONS Better (Supports up to 1080i resolution.) COMPONENT VIDEO IN Your TV Go To RCA component video cable Video No supplied cables are used in this connection: Please purchase the necessary cables at your local store. Basic (Supports only 480i resolution.) Your TV VIDEO IN Go To...
-
Page 18: Component Video Connection
CONNECTIONS Component Video Connection Your TV HDMI OUT DIGITAL COMPONENT VIDEO OUT AUDIO IN AUDIO IN AUX 1 AUX 2 SPEAKERS 4 COAXIAL AC 120V 60Hz SUB- FRONT REAR FRONT VIDEO OUT WOOFER CENTER COMPONENT VIDEO IN PB/CB PR/CR RCA component video cable Standard Video Connection Your TV HDMI OUT... -
Page 19: Connecting Speakers And Subwoofer
CONNECTIONS Connecting Speakers and Subwoofer HDMI OUT DIGITAL COMPONENT VIDEO OUT AUDIO IN AUDIO IN AUX 1 AUX 2 SPEAKERS 4 COAXIAL AC 120V 60Hz SUB- FRONT REAR FRONT VIDEO OUT WOOFER CENTER SUBWOOFER FRONT CENTER REAR RIGHT REAR LEFT FRONT FRONT RIGHT... -
Page 20: Connecting Audio From Cable Box / Recorder / Game Console Or Tv
CONNECTIONS Connecting Audio from Cable Box / Recorder / Game Console or TV • This unit provides analog and digital audio connection. You can connect the audio output from an audio / video device (e.g. DVD Recorder, VCR, Cable / Satellite Box, game console or TV) to this Blu-ray Disc Home Theater in order to enjoy the multi-channel surround sound capabilities. -
Page 21: Connecting Portable Media Player
CONNECTIONS Connecting Portable Media Player Connect a 3.5mm stereo audio cable(not supplied) to the MP3 LINK jack on this unit and the headphone jack on your portable media player. No supplied cables are used in this connection: Please purchase the necessary cables at your local store. Note •... -
Page 22: Network Connection With Lan
CONNECTIONS Network Connection with LAN • By connecting this unit to the Internet, you can access VUDU services and applications, BD-Live features on a Blu-ray Disc and perform network upgrade. Telecommunications equipment (modem, etc.) Hub or broadband router LAN cable LAN cable Internet this unit... -
Page 23: Before You Start
This is the correct viewing channel (external input channel). • If a certain amount of time has passed since you turned on the unit, you may see the home menu instead of the PHILIPS splash screen. Home menu: Blu-ray Disc Home Theater System Disc Tray... -
Page 24: Playback
INFORMATION ON PLAYBACK Information on Playback Before you start playing back a disc, read the following information. • This unit cannot play back the disc contents protected by Playable Discs and Files Windows Media™ Digital Rights Management (DRM). This unit is compatible to play back the following discs / files. Readable cards Playable files / data To play back a disc / file, make sure that it meets the... - Page 25 INFORMATION ON PLAYBACK Unplayable Discs and Files Hint for Disc Playback The following discs will not be played back in this unit. The contents of disc are generally divided into sections or folders (groups of titles / files) as shown below. •...
-
Page 26: Guide To File List
INFORMATION ON PLAYBACK Picture Mode File List Guide to File List Audio CD Track List BD Home Theater System Disc Tray Pictures BD Home Theater System Music Track Track Track Track Track CDDA 00 : 00 : 39 Media Filter Page Down Track Track... -
Page 27: Basic Playback
BASIC PLAYBACK Playing Back a BD or a DVD Insert a disc (refer to “How to Insert a Disc” on page 26). Playback may start automatically. If not, press [B (play)]. Some discs may show a title or a disc menu. In this case, refer to “Using the Title / Disc Menu”... -
Page 28: Playing Back An Audio Cd Or A Disc With Mp3 / Windows Media™ Audio / Jpeg Files
BASIC PLAYBACK Playing Back an Audio CD or a Disc with MP3 / Windows Media™ Audio / JPEG Files How to Navigate through the Track / File List • Use [K / L] to move the highlight up and down in the list. - Page 29 BASIC PLAYBACK Insert a disc (refer to “How to Insert Select a group (folder) or track / file a Disc” on page 26). you want to play back. Then press [B (play)] or [OK] to start playback. • Home menu appears automatically. Refer to “How to Navigate through the Track / With “Disc Tray”...
-
Page 30: Kodak Picture Cd
BASIC PLAYBACK KODAK Picture CD Reading the SD Memory Card You can play back the MP3 / WMA / JPEG files in an SD This unit can also run JPEG files stored on KODAK Picture Memory Card. CD. You can enjoy picture images on the TV set by playing With the SD Memory Card, you can also enjoy the back the KODAK Picture CD. -
Page 31: Using The Title / Disc Menu
BASIC PLAYBACK Note • In the “SD Card” mode, the resume information will be cleared when; -[C (stop)] is pressed while in the Resume-On-Stop mode. -the SD Memory Card is removed. -the unit is turned into the standby mode. • Do not remove the SD Memory Card or turn the unit to the standby mode while the contents of the card are in playback. -
Page 32: Special Playback
SPECIAL PLAYBACK Fast Forward / Fast Reverse Repeat Playback Available repeat function varies depending on the discs. 1) During playback, press [REPEAT] repeatedly to 1) During playback, press [D (forward)] repeatedly select the desired repeat function. for fast forward. REPEAT MODE AVAILABLE MEDIA During playback, press [E (reverse)] repeatedly Chapter Repeat... -
Page 33: Slide Show
SPECIAL PLAYBACK Note Enjoying BD-Live Discs with Internet • Point B should be set within the same title or track as point A. • If you press [REPEAT A-B] when the repeat setting You can enjoy BD-Live which enables you to use for BD, DVD or CD playback is set, the repeat setting interactive features when the unit is connected to the will be cancelled. -
Page 34: Title / Chapter Search
SPECIAL PLAYBACK Title / Chapter Search Track Search Using [S (previous)] / [T (next)] Using [S (previous)] / [T (next)] 1) During playback, press [T (next)] to skip the 1) During playback, press [T (next)] to skip the current track or file and move to the next. current title or chapter and move to the next. -
Page 35: Switching Subtitles
SPECIAL PLAYBACK Switching Subtitles Switching Audio Soundtrack Some video materials may have subtitles in one or more When playing back video material recorded with two or languages. For commercially available discs, the more soundtracks (these are often in different audio supported languages can be found on the disc case. -
Page 36: Switching Camera Angles
SPECIAL PLAYBACK Switching Camera Angles Radio Operations By connecting the supplied FM wire antenna, you can listen to FM radio on this unit. Some BD-video and DVD-video contain scenes which have been shot simultaneously from various angles. You can Presetting Radio Stations change the camera angle when appears on the TV When you access radio mode for the first time, follow the... -
Page 37: Vudu Operations
SPECIAL PLAYBACK Guide to the FM Radio Screen VUDU Operations With this unit, you can enjoy VUDU HD on-demand movies / TV episodes and Internet applications. In order to use this feature, you must connect this unit to Nevada BD Home Theater System the Internet. - Page 38 SPECIAL PLAYBACK 3) Use [K / L] to select a desired quality option, then Guide to VUDU Menu Screen press [OK]. • Select the quality option that best suits your network App Home Screen environment. App Home screen is the entry point to VUDU applications Video Resolution Minimum Bit Rate including VUDU movies.
-
Page 39: List Of Settings
LIST OF SETTINGS In the settings menu, you can customize the various kinds of settings as you prefer. Refer to the following instruction to navigate through the settings menus. 1) Press [ (home)] to access the home menu. 2) Use [K / L] to select “Settings”, then press [OK]. 3) Use [K / L] to select the desired setting, then press [OK]. - Page 40 LIST OF SETTINGS Category Menus / Options Description Video HDMI Video HDMI 1080p/24 Auto “Auto”: Output Outputs the picture in 1080p/24 (1080 progressive with 24 frames per second) when it meets all the • This feature is available conditions listed below: only when the display •...
- Page 41 LIST OF SETTINGS Category Menus / Options Description Audio Night Mode Auto Compresses range between soft and loud sounds. “Auto”: Night Mode will be activated automatically when Dolby TrueHD audio is played back. “On”: Activates the Night Mode. “Off”: Deactivates the Night Mode. Blu-ray Disc Audio Mix Audio Output “Mix Audio Output”:...
- Page 42 • This feature is EasyLink (HDMI CEC) function. available only when EasyLink (HDMI CEC) function the display device is allows your PHILIPS brand connected with an EasyLink TV to act in conjunction HDMI cable, and with this unit or vice versa.
- Page 43 Upgrade You can upgrade the software more information. version by using a disc. To download the latest software version, please visit www.philips.com/support. Network Set the network upgrade. Upgrade You can upgrade the software version by connecting this unit to the Internet.
- Page 44 LIST OF SETTINGS Category Menus / Options Description Settings “Yes”: Resets all the settings, except for “Ratings Lock” and “Network Connection”, in “Settings” to the factory default. “No”: Does not perform the initialization. Format SD “Yes”: Card Re-format SD card. “No”: Does not format the SD card.
-
Page 45: Setups
SETUPS Actual Output Resolution by Media: TV Shape Media Setting in Source “Advanced home A “Settings” A A “Video Output” A “TV Shape” the “HDMI Setup” Video 480i/60 720p/60 1080i/60 720p/24 1080p/24 Resolution” Use this feature to adjust the aspect ratio of the video source which is different from your TV’s ratio to fit your TV 480p 480p/60... -
Page 46: Audio Output
SETUPS Audio Output A “Settings” A “Advanced Setup” A “Audio” A Audio Output home If you set to “Speakers” : The audio output from the 5.1ch speakers differs depending on the audio source and the setting of surround mode. (Refer to “Selecting Surround Mode” on page 54.) If you set to “HDMI Normal”... - Page 47 SETUPS “Audio Output” setting A “HDMI Normal” “HDMI LPCM” “Primary Audio “Mix Audio “Primary Audio “Mix Audio “Blu-ray Disc Audio” setting A Only” Output” Only” Output” Media Audio Source Which audio format can be output depends on the compatibility of the ...
-
Page 48: Ratings Lock
SETUPS 3) After entering the PIN code, “Rating Level” appears. Ratings Lock (If not, use [K / L] to select “Rating Level”.) Select desired rating level then press [OK]. “Ratings home “Settings” “Advanced Setup” Rating Level Lock” New PIN 8 [Adult] Some BD-video or DVD-video feature a ratings lock level. -
Page 49: Easylink (Hdmi Cec)
A “Others” A BD-Live, VUDU or network upgrade function. Setup” (HDMI CEC)” This unit supports Philips EasyLink, which enables your TV Connection Test (limited to PHILIPS brand EasyLink TV) to act in conjunction with this unit, or vice versa. Compliant TV “Advanced... - Page 50 SETUPS If you select “Manual”, follow the following Enable(Easy) instruction to set the IP address and DNS. 4-a) IP address setting screen will appear. Enter IP “Advanced “Network “Enable home A“Settings” A A“Others” A address, subnet mask and default gateway with Setup”...
- Page 51 SETUPS After you enter all correctly, press [YELLOW] to go to Note the proxy port setting screen. 4-b) Enter proxy port number with number buttons. • The range of input numbers is between 0 and 255. • If you enter a number larger than 255, the number Proxy Setting will automatically be 255.
- Page 52 SETUPS Connection Speed BD-Live Setting You can set connection speed as your preference. (The You can limit Internet access for BD-Live discs. (The default default setting is “Auto”.) setting is “Allow”.) 1) Follow steps 1) to 4) in “Connection Test” on page 1) Follow steps 1) to 4) in “Connection Test”...
-
Page 53: Software Upgrade
Press [OK]. Software Upgrade • The unit will start upgrading the software version. Philips continuously tries to improve its products and we • It may take a while to complete the upgrading. strongly recommend that you upgrade the software when 7) After upgrading finishes, this unit will restart and upgrades are available. -
Page 54: Sound Settings
SOUND SETTINGS Volume Control Selecting Sound Effect Mode You can control the volume level of the audio output from Select the sound effect mode for the audio output from 5.1ch speakers. 5.1ch speakers to suit your video or music. To increase or decrease the volume level : 1) During playback, press [SOUND MODE] repeatedly to select the desired sound effect mode. -
Page 55: Other Settings
OTHER SETTINGS Switching Active Source Mode Sleep Timer You can change the active source mode to the desired The sleep timer enables the unit to switch to the standby external audio inputs and enjoy audio from the connected mode automatically after the selected preset time. device with the multi-channel surround sound To set the sleep timer : capabilities. -
Page 56: Troubleshooting
TROUBLESHOOTING Problem No reaction to the remote control. Connect the product to the power outlet. Point the remote control at the product. Insert the batteries correctly. Insert new batteries in the remote control. No video signal on the display Turn on the TV. device. -
Page 57: Troubleshooting
Make sure that the file extension is .mp3 or .MP3 for MP3, and .wma or .WMA for Windows Media™ Audio. Error message appears when I Make sure that the unit is connected to the PHILIPS brand EasyLink TV and select “Auto” in the “Player Menu”. the “EasyLink (HDMI CEC)” is set to “On”. -
Page 58: Downloading An Electronic Copy
5) Under Product support, click “User manuals”. Contact Us If you cannot resolve your problem, refer to the FAQ for this Home Theater System at www.philips.com/support. If the problem remains unresolved, contact the Customer Support Center in your country. Note •... -
Page 59: Glossary
GLOSSARY Analog Audio Dolby Digital Plus An electrical signal that directly represents sound. Dolby Digital Plus is the next generation digital audio Compare this to digital audio which can be an electrical compression technology developed as an extension to signal, but is an indirect representation of sound. See also Dolby Digital. - Page 60 GLOSSARY LAN (Local Area Network) Track A group of computer networks covering a small area like a Audio CD uses tracks to divide up the content of a disc. company, school or home. The BD-video or DVD-video equivalent is called a chapter. See also “Chapter”.
-
Page 61: Specifications
SPECIFICATIONS General Signal system NTSC Color Power requirements 120 V AC, 60 Hz Power consumption 70 W (standby: 0.6 W) Total output power (Amplifier) Home theater mode: 1000 W FTC* output power : 700 W *(Main Ch @ 1 kHz within 10% THD, Sub Ch 60 Hz within 2.5% THD) Dimensions (width x height x depth) 17.2 x 2.4 x 11.7 inches (435 x 59 x 297 mm) Weight... -
Page 62: Network Service Disclaimer
NETWORK SERVICE DISCLAIMER Network Service Disclaimer Content and services made available through this product are transmitted by third parties by means of networks and transmission facilities over which Company has no control and third party services may be terminated or interrupted at any time, and Company makes no representation or warranty that any content or service will remain available for any period of time. -
Page 63: One (1) Year Limited Warranty
ANY EXPRESS OR IMPLIED WARRANTY ON THIS PROD- to it. This Limited Warranty does not apply to any non-Philips UCT. EXCEPT TO THE EXTENT PROHIBITED BY APPLICABLE hardware product or any software, even if packaged or sold LAW, ANY IMPLIED WARRANTY OF MERCHANTABILITY OR with the product. - Page 64 País de Origen : CHINA GARANTIA INCLUIDA EN EL INSTRUCTIVO DE USO LEA CUIDADOSAMENTE ESTE INSTRUCTIVO ANTES DE USAR SU APARATO. Printed in China JpnYN-1033/F7-3 1VMN29994★★★★ E1S07UD_E1S08UD Philips and Philips Shield are used under license of Koninklijke Philips Electronics NV.
