1 S Q C 17 3 0 1 8 M 0 2 0 1
ReliaGear
TM
XT5 2P 600A VERTICAL MAIN BREAKER KIT INSTALLATION
WARNING
Danger of electrical shock or injury. Turn OFF power ahead of the panel board or switchboard before working inside the equipment
or removing any component. Equipment is to be installed and maintained by properly trained and qualified personnel only.
A
B
C
D
E
Lighting Panelboards
Description
Breaker Mounting
Bracket
Breaker Mounting
Barrier
Breaker XT5 600A
2P
Separately
M4X95 Hex Socket
Head Screw
Breaker Straps
Quantity
1X
F
G
1X
Ordered
H
2X
I
J
2X
Description
Quantity
Cerrated Belleville
3X
Washer M10
Metric Hex Socket
3X
HD Cap SCREW
M10X25
XT5 Phase Barrier
2X
10-32X3/8
Screw,Steel T-Roll
6X
Shield Support
2X
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for ABB ReliaGear XT5
Summary of Contents for ABB ReliaGear XT5
- Page 1 1 S Q C 17 3 0 1 8 M 0 2 0 1 ReliaGear Lighting Panelboards XT5 2P 600A VERTICAL MAIN BREAKER KIT INSTALLATION WARNING Danger of electrical shock or injury. Turn OFF power ahead of the panel board or switchboard before working inside the equipment or removing any component.
- Page 2 Description Quantity Base Barrier 10-32X1/4 Screw T-Roll Steel Neutral Assembly 10-32X7/16 Ordered Taptite,Hex Head Separately Screw Optional XT5 600A Vertical with Shield Load Side Barrier Interior Shield Insert Rivet(Plastic) Vertical XT5-600A 5/16-18 XT5 Handle Sticker Nut&Washer ReliaGear neXT | ABB...
- Page 3 Remove screw from the subassembly, then remove handle Use provided sticker to hide the square holes on the primary handle ReliaGear neXT | ABB...
- Page 4 Breaker Assembly 10lb-in (1.12Nm) 300lb-in (33.9Nm) Remove Shield Supports Note: Unscrew item ''I'' at two locations to remove item ''J'' and keep them safe for re-use. ReliaGear neXT | ABB...
- Page 5 Install Base Barrier Note: Remove the 4 indicated push rivets "N" and re install them after all the holes are visibly aligned. Install Shield Supports 40lb-in (4.5Nm) ReliaGear neXT | ABB...
- Page 6 Install Neutral Assembly Kit, when applicable Install Vertical Load Side Barrier Bus support Note: Install Item "N" such that its edges are against the bus support. ReliaGear neXT | ABB...
- Page 7 Install Breaker Assembly 100lb-in (11.2Nm) 40lb-in (11.2Nm) Install Shield On Shield Supports Shield Support 40lb-in (4.5Nm) ReliaGear neXT | ABB...
- Page 8 Any reproduction, disclosure purchase orders, the agreed particulars to third parties or utilization of its contents shall prevail. ABB AG does not accept any re- – in whole or in parts – is forbidden without sponsibility whatsoever for potential errors prior written consent of ABB AG.
