Assembly Guide
Cubii Go Compact Elliptical
Remove all of the components from the Cubii Go box.
Included you should find:
A CUBII GO UNIT BODY D CROSS MEMBER
B LEFT AND RIGHT PEDALS C M5 ALLEN WRENCH
A
B
C
STEP 1 — Crossbar
Before installing the crossbar, orient the roller wheels to point away from
the body of the unit, and with the screw holes facing up. Lower the unit
onto the crossbar so that the holes line up with the screws. Tighten screws
with the included wrench, taking care not to scratch your Cubii Go.
STEP 2 — Align Pedal
Align the right pedal tube with the tube shaft on the ring of the elliptical.
Insert the pedal tube into the tube shaft and push in until the unit stops.
B
STEP 3 — Press and Insert Pedals
D
Align the pedal wheel with the wheel track on the bottom side of the
elliptical. Once aligned, push the button on the pedal tube and continue
pushing in the pedal into the tube shaft.
STEP 4 —
Click and Lock
Continue pushing in the pedal
into the tube shaft and wheel track
until you hear a click or the pedal is
pushed in all the way. To ensure your
pedal is locked into place, release the
button once the pedal is pushed in
all the way and try to pull the pedal
outwards. Your pedal should be
locked into place.
STEP 5 —
Repeat
Repeat steps 2-4 with the left pedal, then get moving!
The Cubii App
DOWNLOAD THE CUBII APP
Available for free where you download mobile
applications.
Personalize your profile and workout goals
Track activity and see your progress
Socialize in our one-of-a-kind Cubii Communitii
TM
Create or participate in group leaderboards
And much more!
Find detailed product manual, assembly demo, and
warranty details at cubii.com/help
