Cubii Go Manual

DISPLAY MONITOR

1. Press the button under the display to wake it.
2. Top Line: Stride count.
3. Bottom Line: Cycles between Time, Calories, Distance, and RPM (Revolutions Per Minute).
4. Scan Mode: The display will automatically cycle through these metrics.
5. Reset The Strides To Zero: Hold button down for 3 seconds.
6. To Change The Units Between Miles And Kilometers: Hold button down for 5 seconds.

ADJUSTING THE RESISTANCE

Cubii Go comes with 8 resistance levels. Turn the knob clockwise to increase the resistance. The higher the number, the higher the resistance. We recommend you begin at Level 1 and increase the intensity gradually over time.

Please Note: Cubii Go is only to be used while sitting. Do not stand on the elliptical.

Not for use directly on shag carpet. Place a mat underneath the elliptical. Consult your physician before starting this or any exercise program.

TRANSPORTING AND POSITIONING

To extend the handle, hold down the handle release button, then pull out the handle. Hold down the button again to fully retract the handle. The Cubii Go can be used with the handle extended or retracted. The unit can also be lifted up to carry like a briefcase or rolled on the floor like a roller bag.

USING THE CHAIR WHEEL CUP

If you're using Cubii Go while sitting in a chair with wheels or castors, follow the steps below:

1. Extend the handle by at least 1 position to expose the wheel cup.


Assembly Guide

Cubii Go Compact Elliptical
Remove all of the components from the Cubii Go box.

1. CUBII GO UNIT BODY
2. LEFT AND RIGHT PEDALS
3. M5 ALLEN WRENCH
4. CROSS MEMBER

STEP 1 — Crossbar

Before installing the crossbar, orient the roller wheels to point away from the body of the unit, and with the screw holes facing up. Lower the unit onto the crossbar so that the holes line up with the screws. Tighten screws with the included wrench, taking care not to scratch your Cubii Go.

STEP 2 — Align Pedal

Align the right pedal tube with the tube shaft on the ring of the elliptical. Insert the pedal tube into the tube shaft and push in until the unit stops.

STEP 3 — Press and Insert Pedals

Align the pedal wheel with the wheel track on the bottom side of the elliptical. Once aligned, push the button on the pedal tube and continue pushing in the pedal into the tube shaft.

STEP 4 — Click and Lock

Continue pushing in the pedal into the tube shaft and wheel track until you hear a click or the pedal is pushed in all the way. To ensure your pedal is locked into place, release the button once the pedal is pushed in all the way and try to pull the pedal outwards. Your pedal should be locked into place.

STEP 5 — Repeat

Repeat steps 2-4 with the left pedal, then get moving!

The Cubii App

DOWNLOAD THE CUBII APP
Available for free where you download mobile applications.

• Personalize your profile and workout goals
• Track activity and see your progress
• Socialize in our one-of-a-kind Cubii Communitii^TM
• Create or participate in group leaderboards And much more!

Find detailed product manual, assembly demo, and warranty details at cubii.com/help
