  • Page 1 Home Cinema 2300 User's Guide...

  • Page 2: Table Of Contents

    Contents Notations Used in This Guide Remote Control Operation ......................24 Using Basic Projector Features Using the Manual to Search for Information ........6 Searching by Keyword ........................6 Turning On the Projector ..............27 Jumping Directly from Bookmarks.................... 6 Printing Only the Pages You Need....................
  • Page 3 Contents Input Signal Settings - Signal Menu..........70 Setting Frame Interpolation...................... 48 Adjusting the Scene Adaptive Gamma................. 49 Projector Feature Settings - Settings Menu ........71 Adjusting the Projector Lamp Brightness................50 Projector Setup Settings - Extended Menu ........73 Setting Auto Iris ..........................
  • Page 4 Contents Adjusting an Image that is not Rectangular ............... 95 Restriction of Use ........................115 Adjusting a Fuzzy or Blurry Image..................96 Operating System References....................116 Fixing Partial Image Problems....................96 Trademarks............................ 116 Adjusting an Image that Contains Noise or Static............96 Copyright Notice.........................

  • Page 5: Notations Used In This Guide

    Notations Used in This Guide Safety Symbols The projector and its manuals use graphical symbols and labels to indicate content that tells you how to use the projector safely. Read and carefully follow the instructions that are marked with these symbols and labels to avoid injury to persons or damage to property. This symbol indicates information that, if ignored, could possibly result in personal injury or even death.

  • Page 6: Using The Manual To Search For Information

    Using the Manual to Search for Information The PDF manual allows you to search for information you are looking for by Printing Only the Pages You Need keyword, or jump directly to specific sections using the bookmarks. You can also print only the pages you need. This section explains how to use a PDF You can extract and print only the pages you need.

  • Page 7: Getting The Latest Version Of The Documents

    Getting the Latest Version of the Documents You can get the latest version of the manuals and specifications on the Epson Web site. Visit latin.epson.com/support and search for your product.

  • Page 8: Introduction To Your Projector

    Introduction to Your Projector Refer to these sections to learn more about your projector's features and part names. g g Related Links • "Projector Parts and Functions"...

  • Page 9: Projector Parts And Functions

    Projector Parts and Functions The following sections explain the projector parts and their functions. Name Function g g Related Links Warning • "Projector Parts - Front" • "Projector Parts - Rear" p.10 Do not look into the vents. If the lamp •...

  • Page 10: Projector Parts - Rear

    Projector Parts and Functions Name Function Projector Parts - Rear Horizontal keystone Corrects horizontal distortion in the projected image. slider This slider cannot be used when Keystone is set to Quick Corner in the projector's Settings menu. Rear cover Open to access the HDMI2 or USB-A ports. Turns the projector on or off.

  • Page 11: Projector Parts - Base

    Projector Parts and Functions Name Function Name Function Service port This port is not normally used. Ceiling mount fixing Attach the optional ceiling mount here when points (three points) suspending the projector from a ceiling. Power inlet Connects the power cord to the projector. Air exhaust vent Exhaust vent for air used to cool the projector internally.

  • Page 12: Projector Parts - Projector Remote Control

    Projector Parts and Functions Projector Parts - Projector Remote Control Name Function Power button Turns the projector on or off. You can operate your projector using this remote control. Color Mode button Changes the color mode. Displays the Keystone adjustment screen or the Quick Keystone button Corner screen.
  • Page 13 Projector Parts and Functions Name Function Volume up/down Adjusts the volume for the speaker and headphones. buttons Playback control Controls playback of the connected streaming media button player or video equipment that supports the HDMI CEC standard. Menu button Displays and closes the projector's menu. You can use the projector's menus to adjust the settings that control how your projector works.

  • Page 14: Setting Up The Projector

    Setting Up the Projector Follow the instructions in these sections to set up your projector. g g Related Links • "Projector Placement" p.15 • "Installing the Safety Wire" p.18 • "Projector Connections" p.19 • "Installing Batteries in the Remote Control" p.24...

  • Page 15: Projector Placement

    • Failure to install the ceiling mount and projector may cause the projector to fall. After installing the specific Epson mount that supports your projector, make sure you secure the mount to all of the projector's ceiling mount fixing points.

  • Page 16: Precautions On Installation

    Projector Placement Precautions on Installation Warning Note the following precautions when installing the projector. • Do not cover the projector's air intake or air exhaust vents. If the vents are covered, the internal temperature could rise and cause a fire. Installation space •...

  • Page 17: Projection Distance

    Projector Placement Front/Rear See the Appendix for details about how far to place the projector from the screen based on the size of the projected image. When correcting keystone distortion, your image is slightly smaller. Front Ceiling/Rear Ceiling g g Related Links •...

  • Page 18: Installing The Safety Wire

    Installing the Safety Wire When installing the projector in a high location such as a ceiling, wall, or shelf, install the optional safety wire set to secure the projector to the installation location and prevent it from falling. Warning The safety wire is available as an optional Safety Wire Set V12H003W01. Pass the safety wire through the security cable attachment point on the projector.

  • Page 19: Projector Connections

    Projector Connections See these sections to connect the projector to a variety of projection sources. Connect the other end to the projector's HDMI port. Attention • Check the shape and orientation of the connectors on any cable you plan to connect.

  • Page 20: Connecting To A Streaming Media Player

    Projector Connections Connect the power supply USB cable to the projector's USB-A port. Connecting to a Streaming Media Player You can connect your streaming media player to the projector's HDMI2 port using the HDMI cable and power supply USB cable that come with the projector.

  • Page 21: Connecting To An Ipad/Iphone

    Projector Connections Connect the HDMI cable and power supply USB cable to the streaming Reattach the air filter cover, and then the rear cover. media player. If your streaming media player supports the HDMI CEC standard, you Place the streaming media player into the slot in front of the air filter can operate some of the player's functions by using the projector's remote control.

  • Page 22: Connecting To An Arc Compatible Av System

    Projector Connections • "Connecting to External Speakers" p.22 g g Related Links • "Projector Feature Settings - Settings Menu" p.71 Connecting to an ARC Compatible AV System Connecting to External Speakers If your AV system or speakers, such as a sound bar, has an HDMI port, you can connect them to the projector using an HDMI cable (with Ethernet) to You can connect the projector to external self-powered speakers.
  • Page 23 Projector Connections Connect the stereo mini-jack end of the cable to your projector's Audio Out port. g g Related Links • "Projector Feature Settings - Settings Menu" p.71...

  • Page 24: Installing Batteries In The Remote Control

    Installing Batteries in the Remote Control The remote control uses the two AAA batteries that came with the projector. Warning Attention Check the positions of the (+) and (–) marks inside the battery holder to ensure the batteries are inserted the correct way. If the batteries are not used Make sure you read the online Safety Instructions before handling the batteries.
  • Page 25 Installing Batteries in the Remote Control Make sure that you aim the remote control at the projector's receivers within the distance and angles listed here. • Avoid using the remote control in conditions with bright fluorescent lights or in direct sunlight, or the projector may not respond to commands.

  • Page 26: Using Basic Projector Features

    Using Basic Projector Features Follow the instructions in these sections to use your projector's basic features. g g Related Links • "Turning On the Projector" p.27 • "Turning Off the Projector" p.31 • "Selecting the Language for the Projector Menus" p.32 •...

  • Page 27: Turning On The Projector

    Turning On the Projector Turn on the computer or video device you want to use after you turn on the Connect the power cord to the projector's power inlet and plug it into projector. an electrical outlet. Connect the device to the projector. Remove the lens cover.
  • Page 28 Turning On the Projector Turn on the connected device. Warning • Never look into the projector lens when the lamp is on. This can damage your eyes and is especially dangerous for children. • When turning on the projector at a distance using the remote control, make sure there is no one looking into the lens.

  • Page 29: Home Screen

    Turning On the Projector Press the arrow buttons on the remote control to select a menu item, and then • When the Direct Power On setting is set to On in the projector's press [Enter]. Extended menu, the projector turns on as soon as you plug it in. Note that the projector also turns on automatically in cases such as recovery from a power outage.
  • Page 30 Turning On the Projector • "Using the Projector's Menus" p.66 • "Adjusting the Projector Lamp Brightness" p.50 • "Setting Auto Iris" p.51...

  • Page 31: Turning Off The Projector

    Turning Off the Projector Turn off the projector after use. • Turn off this product when it is not in use to prolong the life of the projector. Lamp life varies depending on the mode selected, environmental conditions, and usage. Brightness decreases over time. Press the power button on the projector or remote control.

  • Page 32: Selecting The Language For The Projector Menus

    Selecting the Language for the Projector Menus If you want to view the projector's menus and messages in another language, you can change the Language setting. Turn on the projector. Press the button on the remote control. Select the Extended menu and press [Enter]. Select the Language setting and press [Enter].

  • Page 33: Projection Modes

    Projection Modes Depending on how you positioned the projector, you may need to change the Select the Extended menu and press [Enter]. projection mode so your images project correctly. • Front lets you project from a table in front of the screen. •...

  • Page 34: Adjusting The Image Position Using Lens Shift

    Adjusting the Image Position Using Lens Shift If you cannot install the projector directly in front of the screen, you can Turn the lens shift dial on the projector to adjust the position of the adjust the vertical position of the projected image using the lens shift feature. projected image as necessary.
  • Page 35 Adjusting the Image Position Using Lens Shift Maximum range: V × 60%...

  • Page 36: Adjusting The Image Height

    Adjusting the Image Height If you are projecting from a table or other flat surface and the image is too Extend the rear foot high or low, you can adjust the image height using the projector's adjustable Retract the rear foot feet.

  • Page 37: Image Shape

    Image Shape You can project an even, rectangular image by placing the projector directly Correcting the Image Shape with the Horizontal in front of the center of the screen and keeping it level. If you place the Keystone Slider projector at an angle to the screen, or tilt it up or down, or off to the side, you may need to correct the image shape.

  • Page 38: Correcting The Image Shape With The Keystone Button

    Image Shape Use the arrow buttons on the remote control to select between vertical Correcting the Image Shape with the Keystone and horizontal keystone correction and to adjust the image shape as Button necessary. • V-Keystone You can correct the shape of an image that is unevenly rectangular. To correct the distortion in the horizontal and vertical directions independently, use the button on the remote control.

  • Page 39: Correcting The Image Shape With Quick Corner

    Image Shape Select Quick Corner and press [Enter]. Then press [Enter] again if Correcting the Image Shape with Quick Corner necessary. You can use the projector's Quick Corner setting to correct the shape and size of an image that is unevenly rectangular. You see the area selection screen.
  • Page 40 Image Shape If you see this screen, you cannot adjust the shape any further in the direction indicated by the gray triangle. Repeat steps 6 and 7 as needed to adjust any remaining corners. When you are finished, press The Keystone setting is now set to Quick Corner in the projector's Settings menu.

  • Page 41: Resizing The Image With The Zoom Slider

    Resizing the Image with the Zoom Slider You can resize the image using the projector's zoom slider.

  • Page 42: Focusing The Image Using The Focus Slider

    Focusing the Image Using the Focus Slider You can correct the focus using the projector's focus slider.

  • Page 43: Selecting An Image Source

    Selecting an Image Source When multiple image sources are connected to the projector, you can switch from one image source to the other. Make sure the connected image source you want to use is turned on. For video image sources, insert a DVD or other video media and press play.

  • Page 44: Image Aspect Ratio

    Image Aspect Ratio The projector can display images in different width-to-height ratios called Select Aspect and press [Enter]. aspect ratios. Normally, the input signal from your video source determines the image's aspect ratio. Select one of the available aspect ratios for your input signal and press [Enter].
  • Page 45 Image Aspect Ratio Aspect mode Description Normal Displays images using the full projection area and maintains the aspect ratio of the image. Full Displays images using the full size of the projection area, but does not maintain the aspect ratio. Zoom Displays images using the full width of the projection area and maintains the aspect ratio of the image.

  • Page 46: Adjusting Image Quality (Color Mode)

    Adjusting Image Quality (Color Mode) The projector offers different color modes to provide optimum brightness, Color mode Description contrast, and color for a variety of viewing environments and image types. Dynamic This is the brightest mode. Best for prioritizing You can select the mode designed to match your image and environment, or brightness.

  • Page 47: Adjusting The Image Quality

    Adjusting the Image Quality You can fine-tune various aspects of the quality of your projected images. Press the right or left arrow buttons to adjust the outline of the image. g g Related Links • "Adjusting the Sharpness" p.47 • "Adjusting the Image Resolution (Image Enhancement)" p.47 •...

  • Page 48: Image Enhancement Options

    Adjusting the Image Quality Select the Image menu and press [Enter]. Color mode Description Image Preset Mode Selects the settings prepared in advance as the settings for Noise Reduction, MPEG Noise Reduction, and Detail Enhancement. Noise Reduction Smooths out rough images. MPEG Noise Reduction Reduces dot and block noise that occurs in outlines when projecting MPEG movies.

  • Page 49: Adjusting The Scene Adaptive Gamma

    Adjusting the Image Quality Frame Interpolation is available in these conditions: Select the level of interpolation and press [Enter]. • Image Processing is set to Fine. Signal > Advanced > Image Processing • Image Preset Mode is set to any option other than Off. Image >...

  • Page 50: Adjusting The Projector Lamp Brightness

    Adjusting the Image Quality Select the Image menu, and press [Enter]. Turn on the projector and display an image. Press the button on the remote control. Select the Image menu and press [Enter]. Select Expert Settings > Scene Adaptive Gamma, and press [Enter]. Press the left or right arrow buttons to adjust the color tone.

  • Page 51: Setting Auto Iris

    Adjusting the Image Quality Choose one of the following options and press [Enter]: Setting Auto Iris You can turn on Auto Iris to automatically optimize the image based on the brightness of the content. Turn on the projector and switch to the image source you want to use. Press the button on the remote control.

  • Page 52: Adjusting The Image Color

    Adjusting the Image Color You can fine-tune various aspects of how colors are displayed in your Select Expert Settings > White Balance > Color Temp., and press projected images. [Enter]. g g Related Links Press the left or right arrow button to adjust the color tone of the •...

  • Page 53: Adjusting The Hue, Saturation, And Brightness

    Adjusting the Image Color Select the Image menu and press [Enter]. In the Gain setting, the bright areas become whiter and shading is lost when you select a high value. When you select a low value, shading for the bright areas is more vividly expressed. Press to exit the menus.

  • Page 54: Adjusting The Gamma

    Adjusting the Image Color Select Expert Settings > RGBCMY, and press [Enter]. Adjusting the Gamma Select the color to adjust, and press [Enter]. You can correct differences in projected image colors that occur between different image sources by adjusting the Gamma setting. Turn on the projector and display an image.
  • Page 55 Adjusting the Image Color Select and adjust the correction value. Press the left or right arrow buttons to select the color tone you want to adjust on the gamma adjustment graph. Then press the up or down arrow button to adjust the value and press [Enter]. When you select a smaller value, you can reduce the overall brightness of the image to make the image sharper.

  • Page 56: Saving Settings To Memory And Using Saved Settings

    Saving Settings to Memory and Using Saved Settings You can save the customized Image menu settings for your video inputs and • Rename Memory lets you rename a saved memory. then select the saved settings whenever you want to use them. Turn on the projector and display an image.

  • Page 57: Controlling The Volume With The Volume Buttons

    Controlling the Volume with the Volume Buttons The volume buttons control the projector's internal speaker system. You can also control the volume of any external speakers you connected to the projector. You must adjust the volume separately for each connected input source. •...

  • Page 58: Changing The Sound Mode

    Changing the Sound Mode The projector offers different sound modes to provide optimum sound for a Press to exit the menus. variety of image types. You can select the mode designed to match your image, or experiment with g g Related Links the available modes.

  • Page 59: Adjusting Projector Features

    Adjusting Projector Features Follow the instructions in these sections to use your projector's adjustment features. g g Related Links • "HDMI Link Features" p.60 • "Shutting Off the Image and Sound Temporarily (A/V Mute)" p.62 • "Turning Off the Sound Temporarily (Mute)" p.63 •...

  • Page 60: Hdmi Link Features

    HDMI Link Features When an audio/video source that meets the HDMI CEC standard is Select the Settings menu and press [Enter]. connected to the projector's HDMI port, you can use the projector's remote control to control certain features of the linked device. g g Related Links •...
  • Page 61 HDMI Link Features Select the device you want to control and project the image from, and • Power Off Link only works when the connected device's press [Enter]. CEC power link function is enabled. • Note that depending on the status of the connected device (for example, if it is recording), the device may not be turned off.

  • Page 62: Shutting Off The Image And Sound Temporarily (A/V Mute)

    Shutting Off the Image and Sound Temporarily (A/V Mute) You can temporarily turn off the projected image and sound. Any sound or video action continues to run, however, so you cannot resume projection at the point that you stopped it. Press the button on the remote control.

  • Page 63: Turning Off The Sound Temporarily (Mute)

    Turning Off the Sound Temporarily (Mute) You can temporarily turn off the sound. Press the button on the remote control. To turn the sound back on, press again.

  • Page 64: Projector Security Features

    Projector Security Features You can secure your projector to deter theft or prevent unintended use by Select On as the Child Lock setting. setting up the following security features: • Child lock to disable the power button on the projector to prevent children from turning on the projector.

  • Page 65: Adjusting The Menu Settings

    Adjusting the Menu Settings Follow the instructions in these sections to access the projector menu system and change projector settings. g g Related Links • "Using the Projector's Menus" p.66 • "Using the Displayed Keyboard" p.67 • "Image Quality Settings - Image Menu" p.68 •...

  • Page 66: Using The Projector's Menus

    Using the Projector's Menus You can use the projector's menus to adjust the settings that control how your Press to exit the menus. projector works. The projector displays the menus on the screen. Press the button on the remote control. You see the menu screen displaying the Image menu settings.

  • Page 67: Using The Displayed Keyboard

    Using the Displayed Keyboard You can use the displayed keyboard to enter numbers and characters. Text type Details Symbols ! " # $ % & ' ( ) * + , - . / : ; < = > ? @ [ \ ] Use the arrow buttons on the remote control to highlight the number ^ _ ` { | } ~ or character you want to enter and press the [Enter] button.

  • Page 68: Image Quality Settings - Image Menu

    Image Quality Settings - Image Menu Settings on the Image menu let you adjust the quality of your image for the Setting Options Description input source you are currently using. The available settings depend on the Sharpness Adjusts the sharpness or softness of currently selected input source.
  • Page 69 Image Quality Settings - Image Menu Setting Options Description Gamma Adjusts the coloring by selecting one of the gamma correction values, or referring to a gamma graph. RGBCMY Adjusts the hue, saturation, and brightness of each color R (red), G (green), B (blue), C (cyan), M (magenta), Y (yellow) individually.

  • Page 70: Input Signal Settings - Signal Menu

    Input Signal Settings - Signal Menu Normally the projector automatically detects and optimizes the input signal Setting Options Description settings. If you need to customize the settings, you can use the Signal menu. HDR10 Setting Changes the PQ (Perceptual Quantizer) The available settings depend on the currently selected input source.

  • Page 71: Projector Feature Settings - Settings Menu

    Projector Feature Settings - Settings Menu Options on the Settings menu let you customize various projector features. Setting Options Description HDMI Link Adjusts the HDMI Link options: Device Lists the devices connected to the HDMI Connections ports. HDMI Link Enables or disables the HDMI Link features.
  • Page 72 Projector Feature Settings - Settings Menu Setting Options Description Reset Settings — Resets all adjustment values on the Settings menu to their default settings, except for the following: • Audio Out Device • Power On Link • Power Off Link •...

  • Page 73: Projector Setup Settings - Extended Menu

    Projector Setup Settings - Extended Menu Settings on the Extended menu let you customize various projector setup Setting Options Description features. Startup Screen Set to On to display a logo when the projector starts up. Panel Alignment Manually corrects color misalignment in the projected image.
  • Page 74 Projector Setup Settings - Extended Menu Setting Options Description Direct Power On Lets you turn on the projector by plugging it in without pressing the power button. Set to On to automatically turn off the Sleep Mode projector after an interval of inactivity. Sleep Mode Timer Sets the interval for Sleep Mode.

  • Page 75: Projector Information Display - Info Menu

    Lamp Hours Displays the number of hours (H) the lamp has been used; if the information is displayed in yellow, obtain a g g Related Links genuine Epson replacement lamp soon. • "Info Menu - Projector Info Menu" p.75 Source Displays the name of the port to which the current input source is connected.
  • Page 76 Projector Information Display - Info Menu Information item Description Color Format Displays information on the Color Space and Dynamic Range. Status Displays information about projector problems that may be needed by a service technician. Serial Number Displays the projector's serial number.

  • Page 77: Projector Reset Options - Reset Menu

    Projector Reset Options - Reset Menu Setting Options Description Reset Lamp Hours — Reset the projector's lamp usage timer to zero when you replace the lamp. Reset Memory — Resets the name and settings of a saved memory. Reset All Config —...

  • Page 78: Maintaining The Projector

    Maintaining the Projector Follow the instructions in these sections to maintain your projector. g g Related Links • "Projector Maintenance" p.79 • "Cleaning the Lens" p.80 • "Cleaning the Projector Case" p.81 • "Air Filter and Vent Maintenance" p.82 • "Projector Lamp Maintenance" p.84 •...

  • Page 79: Projector Maintenance

    The only parts you should replace are the lamp, air filter, and remote control batteries. If any other part needs replacing, contact Epson or an authorized Epson servicer. Warning Before cleaning any part of the projector, turn it off and unplug the power cord.

  • Page 80: Cleaning The Lens

    Cleaning the Lens Clean the projector's lens periodically, or whenever you notice dust or smudges on the surface. • To remove dust or smudges, gently wipe the lens with clean and dry lens- cleaning paper. • If the lens is dusty, blow off dust using a blower, and then wipe the lens. Warning •...

  • Page 81: Cleaning The Projector Case

    Cleaning the Projector Case Before cleaning the projector case, turn off the projector and unplug the power cord. • To remove dust or dirt, use a soft, dry, lint-free cloth. • To remove stubborn dirt, use a soft cloth moistened with water and mild soap.

  • Page 82: Air Filter And Vent Maintenance

    Air Filter and Vent Maintenance Regular filter maintenance is important to maintain your projector. If dust Attention collects on the air filter, it can cause the internal temperature of the projector • If you have not connected the streaming media player, disconnect the to rise, and this can lead to problems with operation and shorten the optical HDMI cable and the power supply USB cable from the projector.
  • Page 83 Air Filter and Vent Maintenance Pull the air filter out of the projector. Close the air filter cover. g g Related Links • "Replacement Parts" p.102 Dispose of used air filters according to local regulations. • Filter frame: ABS • Filter: Polyurethane foam Place the new air filter in the projector as shown and push gently until it clicks into place.

  • Page 84: Projector Lamp Maintenance

    You should always have a spare lamp unit ready in case it is needed. • We recommend the use of genuine Epson replacement lamps. The use of non- genuine lamps may affect projection quality and safety. Any damage or malfunction caused by the use of non-genuine lamps may not be covered by Epson's warranty.
  • Page 85 Projector Lamp Maintenance Loosen the screws securing the lamp to the projector. The screws do Warning not come all the way out. When replacing the lamp, there is a possibility that the lamp may be broken. If replacing the lamp of a projector which has been installed on the ceiling, you should always assume that the lamp is cracked, and you should stand to the side of the lamp cover, not underneath it.
  • Page 86 Push in the lamp firmly and tighten the screws to secure it. • If you notice the lamp is cracked when removing the lamp, contact Epson for help. • The lamp(s) in this product contain mercury (Hg). Check your local laws and regulations regarding disposal or recycling. Do not put in the trash.

  • Page 87: Resetting The Lamp Timer

    Projector Lamp Maintenance Select Reset Lamp Hours and press [Enter]. • Make sure the lamp cover is securely installed or the lamp will not turn on. • Do not replace the lamp cover with too much force and make sure the lamp cover is not deformed. Reset the lamp timer to zero to monitor the new lamp's usage.

  • Page 88: Adjusting The Color Convergence (Panel Alignment)

    Adjusting the Color Convergence (Panel Alignment) You can use the Panel Alignment feature to manually adjust the color Select Panel Alignment and set it to On. convergence (the alignment of the red and blue colors) in the projected image. You can adjust the pixels horizontally and vertically in increments of 0.125 pixels within a range of ±...
  • Page 89 Adjusting the Color Convergence (Panel Alignment) Use the arrow buttons on the remote control to adjust the color alignment selected in Select Color, and then press [Enter]. Adjustment affects the grid lines in the entire screen. Select one of the following options: •...

  • Page 90: Solving Problems

    Solving Problems Check the solutions in these sections if you have any problems using the projector. g g Related Links • "Projection Problems" p.91 • "Projector Indicator Status" p.92 • "Solving Projector Power-On or Power-Off Problems" p.94 • "Solving Image Problems" p.95 •...

  • Page 91: Projection Problems

    If this does not solve the problem, check the following: • The indicators on the projector may indicate the problem. • The solutions in this manual can help you solve many problems. If none of these solutions help, contact Epson for technical support.

  • Page 92: Projector Indicator Status

    Temp: Off If the indicators display a pattern not listed in the table below, turn the All buttons are disabled during warm-up, shutting projector off, unplug it, and contact Epson for help. down, and cooling down. Status: Off Standby or sleep mode.

  • Page 93: Projector Indicator Status

    Lamp: Flashing orange Temp: Off Status: Off Internal projector error Lamp: Lit orange Turn the projector off, unplug it, and contact Epson for help. Temp: Lit orange g g Related Links • "Projector Setup Settings - Extended Menu" p.73 •...

  • Page 94: Solving Projector Power-On Or Power-Off Problems

    Unlock the lock feature using the following method. • To release Child Lock, hold down the power button on the control panel for three seconds. Disconnect the cord and contact Epson for help. g g Related Links • "Using the Child Lock Feature"...

  • Page 95: Solving Image Problems

    Solving Image Problems Check the solutions in these sections if you have any problems with projected Check the status of your video source: images. • If you are projecting from a streaming media player, make sure it is powered by the power supply USB cable on the projector. g g Related Links •...

  • Page 96: Adjusting A Fuzzy Or Blurry Image

    Solving Image Problems Adjust the image shape using the Keystone settings. If you are projecting from a computer, use a lower resolution or select a resolution that matches the projector's native resolution. Settings > Keystone > H/V-Keystone Settings > Keystone > Quick Corner g g Related Links •...

  • Page 97: Adjusting An Image With Incorrect Brightness Or Colors

    Solving Image Problems Check the cables connecting your video source to the projector. They Image > Expert Settings should be: Make sure you selected the correct Video Range setting in the • Separated from the power cord to prevent interference projector's Signal menu, if available for your image source.

  • Page 98: Solving Sound Problems

    Solving Sound Problems If there is no sound or the volume is too low, try the following steps until the problem is solved. Adjust the projector's volume settings using the button on the remote control. If you have adjusted the volume for your streaming media player using the remote control for the streaming media player, you may also need to adjust the volume again.

  • Page 99: Solving Remote Control Operation Problems

    If the projector does not respond to remote control commands, try the following steps until the problem is solved. If you lose the remote control, you can order another one from Epson. Check that the remote control batteries are installed correctly and have power.

  • Page 100: Solving Hdmi Link Problems

    Solving HDMI Link Problems If you cannot operate the connected devices using the HDMI Link features, try the following steps until the problem is solved. Make sure the cable meets the HDMI CEC standard. Make sure the connected device meets the HDMI CEC standard. See the documentation supplied with the device for more information.

  • Page 101: Appendix

    Appendix Check these sections for the technical specifications and important notices about your product. g g Related Links • "Optional Accessories and Replacement Parts" p.102 • "Screen Size and Projection Distance" p.103 • "Supported Monitor Display Resolutions" p.105 • "Projector Specifications" p.106 •...

  • Page 102: Optional Accessories And Replacement Parts

    • "Replacement Parts" p.102 Safety Wire Set Safety Wire Set V12H003W01 Use when connecting the projector to the installation mount to prevent the projector from falling down. Special expertise is required to suspend the projector from a ceiling. Contact Epson for help.

  • Page 103: Screen Size And Projection Distance

    Screen Size and Projection Distance Check the table here to determine how far to place the projector from the 16:9 screen size screen based on the size of the projected image. Minimum (Wide) to Vertical Lens Shift The maximum lens shift adjustment values are shown in the following table. Maximum (Tele) Bottom to Top 60"...
  • Page 104 Screen Size and Projection Distance 16:10 screen size Minimum (Wide) to Vertical Lens Shift Maximum (Tele) Bottom to Top 37" 80 × 50 116 - 189 -55 - 5 40" 86 × 54 125 - 205 -60 - 6 60" 129 ×...

  • Page 105: Supported Monitor Display Resolutions

    Supported Monitor Display Resolutions See the online Supplemental A/V Support Specification for detailed information on compatible refresh rates and resolutions for each compatible video display format. g g Related Links • "Getting the Latest Version of the Documents"...

  • Page 106: Projector Specifications

    Projector Specifications Product name Home Cinema 2300 Operating Altitude of 0 to 2,286 m: +5 to +35°C (Humidity of 20 to temperature ** 80%, No condensation) Dimensions 333 (W) × 123 (H) × 275 (D) mm (not including raised Altitude of 2,287 to 3,048 m: +5 to +30°C (Humidity of 20...

  • Page 107: Connector Specifications

    Projector Specifications Connector Specifications Audio Out port Stereo mini pin jack HDMI1 (ARC) port HDMI HDMI2 port HDMI port USB connector (Type A) Service port USB connector (Mini B) USB-A and Service port supports USB 2.0. However, USB ports are not guaranteed to operate all devices that support USB.

  • Page 108: External Dimensions

    External Dimensions Distance from center of lens to suspension bracket fixing point Center of lens...

  • Page 109: Warning Labels

    Warning Labels This product comes with warning labels. As with any bright source, do not stare into the beam, RG2 IEC/EN 62471- 5:2015.

  • Page 110: List Of Safety Symbols And Instructions

    List of Safety Symbols and Instructions The following table lists the meaning of the safety symbols labeled on the No. Symbol mark Approved Description equipment. standards — The same as No. 8. No. Symbol mark Approved Description standards IEC60417 Battery, general IEC60417 "ON"...
  • Page 111 List of Safety Symbols and Instructions No. Symbol mark Approved Description No. Symbol mark Approved Description standards standards IEC60417 Class II equipment IEC60417 Caution (Sharp Corners) No. 5172 To identify equipment meeting the No. 6043 To indicate sharp corners that should safety requirements specified for Class not be touched.

  • Page 112: Glossary

    Glossary This section briefly explains the difficult terms that are not explained in the HDTV An abbreviation for High-Definition Television that refers to text of this guide. For details, refer to other commercially available high-definition systems which satisfy the following conditions: publications.
  • Page 113 Glossary Sync. The signals output from computers have a specific frequency. If the projector frequency does not match this frequency, the resulting images are not of a good quality. The process of matching the phases of these signals (the relative position of the crests and the troughs in the signal) is called Synchronization.

  • Page 114: Notices

    Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a We: Epson America, Inc. residential installation. This equipment generates, uses, and can radiate radio Located at: 3131 Katella Avenue, Los Alamitos, CA frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.

  • Page 115: How To Dispose Of The Projector

    Notices Restriction of Use WARNING The connection of a non-shielded equipment interface cable to this When this product is used for applications requiring high reliability/safety equipment will invalidate the FCC Certification or Declaration of this device such as transportation devices related to aviation, rail, marine, automotive and may cause interference levels which exceed the limits established by the etc.;...

  • Page 116: Operating System References

    "Windows 10", and "Windows 11". Furthermore, the collective term herein. "Windows" is used to refer to them all. Neither Seiko Epson Corporation nor its affiliates shall be liable to the • macOS 11.x • macOS 10.13.x purchaser of this product or third parties for damages, losses, costs, or •...

Table of Contents
