zooby® Baby Monitor For Cars
*Plush Style May Vary
Thank you for purchasing Infanttech's zooby® video baby monitor for cars. This
unique monitor allows parents to safely operate a vehicle by reducing the need to
turn around while driving. Your zooby® will allow you to monitor your baby while he
or she is facing backward in a rear passenger seat. This versatile monitor can be used
at home, and you can take it with you wherever you go. Additionally, your zooby® can
also be used when your baby becomes a toddler and is facing forward in the rear
passenger seat. This unit is a digital video monitor that easily attaches to the
dashboard window of any vehicle, with a convenient car adapter charger, and a
camera installed in a soft plush that can be secured in various locations in the
backseat. Both the monitor and camera are equipped with a rechargeable battery.
Please note, that use of the zooby® does not replace a driver's need
to obey all traffic and safety laws and use reasonable safety
precautions while driving to minimize distracted driving. It is your
responsibility to to know and comply with the local and State laws
INSTRUCTION MANUAL
where you plan to use this device.
[Model numbers 1000-SG, 1000-PN, 1000-
GB, 1000-FX, 1000-K9]
PLEASE READ THE FOLLOWING
INSTRUCTIONS AND WARNINGS
CAREFULLY BEFORE USING YOUR
ZOOBY® BABY MONITOR. KEEP THIS
INSTRUCTION MANUAL FOR FUTURE
REFERENCE.
For Technical Support email us at
hello@infanttech.com.
For use with Children from birth to
toddlers.
WARNING:
Adult installation required.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the zooby 1000-SG and is the answer not in the manual?

Questions and answers

Summary of Contents for Infanttech zooby 1000-SG

  • Page 1 *Plush Style May Vary Adult installation required. Thank you for purchasing Infanttech’s zooby® video baby monitor for cars. This unique monitor allows parents to safely operate a vehicle by reducing the need to turn around while driving. Your zooby® will allow you to monitor your baby while he or she is facing backward in a rear passenger seat.
  • Page 2: Battery Warning

    Dispose of exhausted batteries properly. Use only the original rechargeable battery pack. Warranty is void if other batteries are used. Please contact Infanttech for a replacement battery, contact information can be found at the end of the instruction booklet.
  • Page 3 • Consult the dealer or an experienced radio/TV technician for help. NOTE: Use only the original rechargeable battery or approved battery replacement. Warranty void if other batteries are used. Please contact infanttech for replacement battery, contact information can be found at the back of the instruction booklet.
  • Page 4 Quick Reference for Daily Operation After your initial setup (see instructions below), follow these easy steps for optimal performance of your zooby® monitor: In the Car: Always use the safety buckle straps of the plush camera and adjust to fit snugly on any headrest posts the plush camera is mounted on.
  • Page 5 Quick Reference for Daily Operation (Continued) On The Go Simply unwrap and unbuckle the camera from the headrest posts of your vehicle. Unclip the monitor from the bracket and carry your zooby® with you. When you step inside any home you are visiting, simply place the camera plush pointing toward the location you want to view.
  • Page 6: Features And Components

    Features and Components:...
  • Page 7 Features and Components (Cont.):...
  • Page 8 Features and Components (Cont.):...
  • Page 9 Accessories: Note: Styles and Designs May Vary from Pictures Contents: 1- Plush with Camera 1- 1700mAh Lithium ion Battery (in plush camera) 1- 4.3" LCD Split Screen Monitor Note: Extra camera is 1- Monitor bracket with suction cup mount sold separately to use 1- USB Charging cable for plush split screen option on 1- Monitor charging cable...
  • Page 10 Pairing Monitor Screen and Camera Your camera and monitor should be paired when opening, if not, please follow these steps: Pair Mode Camera 1: Turn on MONITOR by holding down the power button for 5-6 seconds and release Turn on the CAMERA by sliding the slider switch to On position Now, on the right side of the MONITOR, there is a pinhole label“Pair”.
  • Page 11 Setup and Use for Car Monitor: Charge 3-4 hours prior to use or until the red light turns off Step 1: Plug both camera plush and monitor screen. Red charging lights will turn off to indicate a full charge. Step 2: Attach the mounting bracket to the back of the monitor slot and secure at top of monitor.
  • Page 12 Setup and Use for Car (Cont.) Step 4: Press On/Off button for 5 seconds to turn monitor Step 5: unvelcro the bottom of plush and slide On/Off switch to “On” position and release - green light will turn on. Reclose velcro. Step 6: Once the camera and monitor are on, they will pair.
  • Page 13 Setup and Use for Car (Cont.) Camera in Plush: (Charge for 6-8 hours prior to first use): For Rear Facing Installation for Infants Step 7: Wrap plush’s arms around the backseat headrest posts in front of car seat and attach palms together with the Velcro and attach the safety buckle straps and pull for a snug fit around the headrest posts.
  • Page 14 Setup and Use for Car (Cont.) Step 8: Adjust plush’s head by flexing the internal bendi- neck for optimal viewing. Step 9: Before you are ready to drive, make sure you have adjusted all of your vehicle’s options such as seats, mirrors, seatbelts, and the position of the camera in the plush facing your child.
  • Page 15 Setup and Use for Home Find optimal location for the camera. Ideally, find a location that will be close to an electrical outlet for charging purposes. Note: If using in the nursery, do not place the camera in the crib. Any cables must be at least 3 feet away from your baby.
  • Page 16: Battery Charging

    Battery Charging Monitor Connect USB adapter to the monitor, the light will be red. Once charging is complete, the RED light will turn OFF. Monitor screen indicates battery charge. Camera Connect USB adapter to the camera, the light will be red. Once charging is complete, the RED light will turn OFF.
  • Page 17: Problem Solving

    Problem Solving Infrared (IR) Lighting • In the dark, the IR lights will automatically work, but IR lights do not provide light. Plush Camera won’t stay put or constant camera repositioning • Make sure you have adjusted the buckle straps for a tight fit. If it is still loose, wrap the plush arms on the actual post of the headrest once on each side and then use the buckle.
  • Page 18 If in the car, bring the plush camera and monitor in the home and charge them there • NOTE the green light will not turn on or off while holding down the power button NOTE: Make sure both units are fully charged for optimal performance. See www.infanttech.com for more troubleshooting tips.
  • Page 19 24 hours a day at hello@infanttech.com. Infanttech Warranty Policy Infanttech will repair or replace your unit free of charge for 90 days from the date of purchase if the unit is defective in workmanship or materials. Customer covers shipping to infanttech warehouse. To claim your repair/replacement, the product must be returned to Infanttech along with a copy of the original purchase receipt.
  • Page 20 *Plush Style May Vary el producto. Gracias por su compra del infanttech zooby® video baby monitor for cars. Este monitor de características únicas permite que los padres puedan mejorar la seguridad al conducir vehículos, dado que reduce la necesidad de voltearse para mirar hacia atrás mientras se está...
  • Page 21 Deseche las baterías adecuadamente. Utilice exclusivamente el paquete original de baterías recargables. La garantía quedará anulada si se utilizan otras baterías. Comuníquese con Infanttech cuando necesite baterías de reemplazo. La información de contacto se puede encontrar al final del folleto de instrucciones.
  • Page 22 PRECAUCIÓN: Todo cambio o modificación del equipo que no haya sido aprobado previamente por Infanttech podría anular la licencia que tiene el usuario para operar este equipo. NOTA: Este equipo fue sometido a pruebas y demostró que cumple con los límites de los dispositivos digitales de la Clase A, establecidos en la Parte 15...
  • Page 23 REFERENCIA RÁPIDA PARA LA OPERACIÓN DIARIA: Después de la instalación original del equipo (vea las instrucciones más adelante), siga estos sencillos pasos para obtener el desempeño óptimo de su monitor zooby®: En el auto: Asegúrese de que siempre se utilicen los amarres de seguridad del muñeco de peluche, con las hebillas ajustadas de modo que el muñeco quede bien ajustado en el apoyacabezas correspondiente.
  • Page 24 REFERENCIA RÁPIDA PARA LA OPERACIÓN DIARIA (Continuación) Llévalo Contigo: Desenvolver y desabrochar la cámara de los postes de reposacabezas de su vehículo. Desenganche el monitor desde soporte y lleve su zooby® con usted. Cuando entras en cualquier casa que se visita, simplemente coloque la de peluche apuntando la cámara hacia donde desee ver.
  • Page 25 CARACTERÍSTICAS, FUNCIONES Y COMPONENTES:...
  • Page 26 CARACTERÍSTICAS, FUNCIONES Y COMPONENTES (continuación):...
  • Page 27 CARACTERÍSTICAS, FUNCIONES Y COMPONENTES (continuación):...
  • Page 28 ACCESORIOS: NOTA: El diseño de su equipo podría ser distinto del mostrado aquí Contenido: 1- Peluche con cámara 1- Batería de iones de litio de 1700 mAh NOTA: Cámara (dentro del peluche) 1- monitor de pantalla dividida LCD de 4.3 " adicional para utilizar 1- Soporte para monitor con base de ventosa la opción de pantalla...
  • Page 29 Sincronización del Pantalla de Monitor y de la cámara: La cámara y el monitor deben ser sincronizados cuando se abre la caja, si no, por favor, siga estos pasos: Modo de sincronización de la cámara 1: Presione durante 5-6 segundos el botón de encendido/apagado del monitor para encenderla.
  • Page 30 CONFIGURACIÓN Y USO PARA EL COCHE Unidad del conductor: (Cargue 3-4 horas antes de su uso o hasta que la luz roja se apague) Paso 1: Conecte el peluche cámara y la pantalla del monitor. Luces de carga roja se apagará para indicar una carga completa.
  • Page 31 CONFIGURACIÓN Y USO PARA EL COCHE (continuación): Paso 4: Presione durante 3-5 segundos el botón de encendido/apagado del monitor del conductor para encenderla. Paso 5: unvelcfro parte inferior del peluche y deslice el interruptor de encendido/apagado a la posición "Encendido" hasta que la luz verde se enciende. Cerrar de velcro.
  • Page 32 CONFIGURACIÓN Y USO PARA EL COCHE (continuación) Cámara en el peluche: (recárguela durante 6-8 horas antes de utilizarla por primera vez) CONFIGURACIÓN CON EL BEBÉ MIRANDO HACIA ATRÁS: Paso 7: Rodee con los brazos del peluche los postes apoyacabezas del asiento en el que se encuentra el asiento para bebés y una los brazos en las palmas con la tira de Velcro.
  • Page 33 CONFIGURACIÓN Y USO PARA EL COCHE (continuación): Paso 8: Flexione el cuello del peluche a fin de ajustar la posición de la cabeza y lograr una vista óptima. Paso 9: Antes de proceder a conducir el vehículo, asegúrese de haber ajustado todas las opciones de su vehículo, como la posición de los asientos, espejos, los cinturones de seguridad y la correcta posición de la cámara del peluche frente al bebé.
  • Page 34 CONFIGURACIÓN Y USO POR LA CASA: Encontrar la ubicación óptima para la cámara. Idealmente, encontrar un lugar que sea cerca de un enchufe eléctrico para cargar Note: Si se utiliza en el vivero, no coloque la cámara en la cuna. Cualquier cable deben tener por lo menos 3 pies de distancia de su bebé.
  • Page 35: Recarga De La Batería

    RECARGA DE LA BATERÍA Unidad del conductor Conecte el adaptador USB a la unidad del conductor; la luz se encenderá de color rojo. Una vez finalizada la recarga, la luz se apagará. La pantalla de la unidad del conductor muestra el nivel de carga de la batería. Cámara Conecte el adaptador USB a la cámara;...
  • Page 36: Solución De Problemas

    SOLUCIÓN DE PROBLEMAS: Iluminación infrarroja (IR) • En la oscuridad, las luces IR se activan automáticamente, pero estas luces no generan una luz visible. Cámara felpa no se queda o reposicionamiento cámara constante • Asegúrese de que ha ajustado las las correas de la hebilla para un ajuste perfecto.
  • Page 37 •NOTA: Para un óptimo desempeño, asegúrese de que ambas unidades estén totalmente cargadas. Si tiene algún problema que no se observó en este manual, por favor visite www.infanttech.com para más sugerencias para resolver problemas. Para obtener más información, por favor comuníquese nuestro Departamento de Servicio al Cliente por correo electrónico las 24 horas del día a la...
  • Page 38 Política de garantía de Infanttech Solutions, Inc. Infanttech Solutions, Inc reparará o reemplazará su equipo sin costo durante 90 dias a partir de la fecha de compra si presenta defectos de mano de obra o materiales. Para presentar solicitudes de reparación/reemplazo, se debe enviar de vuelta el producto a...
  • Page 39 *Plush Style May Vary Installation par un adulte requise. Merci d’avoir fait l’achat du infanttech zooby® baby monitor for cars. Ce moniteur unique permet aux parents de conduire un véhicule en toute sécurité en éliminant le besoin de se retourner pendant la conduite. Ce moniteur polyvalent peut être utilisé à la maison, et vous pouvez l'emporter avec vous partout où...
  • Page 40 Disposer des piles vides convenablement. N’utiliser que le bloc-piles rechargeable d’origine. La garantie est annulée si d’autres piles sont utilisées. Veuillez communiquer avec Infanttech pour obtenir une pile de rechange (les coordonnées se trouvent à la fin du livret d’instructions).
  • Page 41 MISE EN GARDE : Tout changement ou toute modification n’étant pas approuvé expressément par Infanttech peut annuler l’autorisation accordée à l’utilisateur de faire fonctionner cet équipement. REMARQUE: Cet équipement a subi des essais et il est conforme à la classe A pour les dispositifs numériques, en vertu de l’article 14 du règlement de la...
  • Page 42 RÉFÉRENCE RAPIDE POUR L’USAGE QUOTIDIEN: Une fois l’installation initiale (voir les instructions ci-dessous), suivre la marche à suivre simple pour obtenir un rendement optimal de la part du moniteur zooby®: Dans la Voiture: S’assurer que les sangles avec boucle de sécurité sur la peluche de la caméra sont toujours utilisées et ajustées pour bien se fixer sur l’appui-tête.
  • Page 43 RÉFÉRENCE RAPIDE POUR L’USAGE QUOTIDIEN (SUITE) Sur la Route: Déballer et déboucler la caméra à partir des messages d'appui-tête Détachez le moniteur du support et transporter votre zooby® avec vous Lorsque vous entrez dans ne importe quelle maison vous visitez, il suffit de placer la peluche de la caméra pointant vers l'emplacement que vous souhaitez afficher.
  • Page 44: Caractéristiques Et Composants

    CARACTÉRISTIQUES ET COMPOSANTS:...
  • Page 45 CARACTÉRISTIQUES ET COMPOSANTS (SUITE):...
  • Page 46 CARACTÉRISTIQUES ET COMPOSANTS (SUITE):...
  • Page 47 ACCESSOIRES: REMARQUE : Le style et la conception peuvent varier des images. Contenu: 1 – Peluche avec caméra Remarque: 1 – Pile au lithium-ion 1500 mA/h (dans la peluche) une caméra 1 – 4.3" ACL Monitor divisée supplémentaire est 1 – Équerre pour le moniteur avec support à ventouse vendue séparément 1 –...
  • Page 48 SYNCHRONISATION MONITEUR ET LA CAMÉRA: Votre caméra et le moniteur doivent être synchronisés lors de l'ouverture boîte, si non, se il vous plaît suivez ces étapes: Mode d'appairage Caméra 1: Allumez moniteur en appuyant sur le bouton d'alimentation pendant 5-6 secondes. Allumez la CAMÉRA en faisant glisser l'interrupteur coulissant sur la position On.
  • Page 49 NSTALLATION ET UTILISATION POUR VOITURE Moniteur: (Chargez 3 à 4 heures avant utilisation ou jusqu'à ce que le voyant rouge s'éteigne) Étape 1: Bouchez les deux en peluche de la caméra et l'écran du moniteur. Témoin de charge rouge se éteint pour indiquer une charge complète Étape 2: fixer l’équerre de fixation dans la fente au dos du moniteur.
  • Page 50 INSTALLATION ET UTILISATION POUR VOITURE (suite): Étape 4: tenir le bouton d’alimentation pendant 5 secondes pour allumer le moniteur. Étape 5: dévelcroz le bas de la peluche et faites glisser l'interrupteur ON/Off sur la position "On" jusqu'a ce que la lumière verte se allume.
  • Page 51 INSTALLATION ET UTILISATION POUR VOITURE (suite) Caméra dans la peluche: (charger la caméra 6-8 heures avant la première utilisation) INSTALLATION SUR UN SIÈGE FAISANT FACE VERS L’ARRIÈRE: Étape 7: placer les bras de la peluche autour des postes de l’appui-tête du siège du passager arrière en face du siège d’auto pour bébé...
  • Page 52 INSTALLATION ET UTILISATION POUR VOITURE (suite): Étape 8: ajuster la tête de la peluche à l’aide des tiges flexibles pour un visionnement optimal. Étape 9: avant de conduire, s’assurer que toutes les options du véhicule sont ajustées, comme les sièges, les miroirs, les ceintures de sécurité...
  • Page 53 INSTALLATION ET UTILISATION POUR LA MAISON: 1.Trouvez l'emplacement optimal pour la caméra. a. Idéalement, trouver un emplacement qui sera à proximité d'une prise électrique pour charger. 2. Remarque: Si vous utilisez la pépinière, ne pas placer la caméra dans la crèche.
  • Page 54: Chargement De La Batterie

    CHARGEMENT DE LA BATTERIE Moniteur Brancher l’adaptateur USB sur le moniteur, le voyant sera rouge. Une fois la charge terminée, le voyant rouge éteint. L’écran du moniteur indique la charge de la pile. Caméra Brancher l’adaptateur USB sur la caméra, le voyant sera rouge.
  • Page 55: Résolution De Problème

    RÉSOLUTION DE PROBLÈME: Éclairage infrarouge (IR) • Dans le noir, les lumières infrarouges s’allument automatiquement, mais elles ne servent pas d’éclairage. Caméra en peluche ne sera pas rester sur place ou de repositionnement de la caméra constante • Assurez-vous que vous avez réglé les sangles à boucle pour un ajustement serré.
  • Page 56 Si vous rencontrez un problème qui ne soit pas noté dans ce manuel, s'il vous plaît visitez www.infanttech.com pour plus de conseils de dépannage. Pour plus d'informations, s'il vous plaît communiquer avec notre service à la...
  • Page 57 Politique relative à la garantie d’Infanttech Solutions, Inc. Infanttech s’engage à réparer ou remplacer sans frais une unité dans les 90 jours à partir de la date d’achat si l’unité est défectueuse à cause de la main-d’œuvre ou des matériaux. Pour demander une réparation ou un remplacement, le produit doit être retourné...
