- Page 1 ORIGINAL INSTRUCTIONS >EN CORDLESS SPRAYER RACPVD16L USER GUIDE CAUTION: Read this manual before using this machine!
-
Page 2: Table Of Contents
CONTENTS 1. SAFETY INSTRUCTIONS........................3 2. PRODUCT DESCRIPTION........................7 3. PREPARATION BEFORE USE......................8 4. HOW TO USE............................10 5. AFTER-USE CHECK AND STORAGE.................... 12 6. SELF-CHECK BEFORE ASKING SERVICE.................. 13 7. PRODUCT SPECIFICATIONS......................13 8. DECLARATION OF CONFORMITY....................14 9. WARRANTY............................15 10. -
Page 3: Safety Instructions
1. SAFETY INSTRUCTIONS Safety precautions are safety precautions and safety precautions for safe use of rechargeable sprayers. Failure to observe these precautions can result in death, serious injury, product failure, or performance degradation. This sprayer is designed for forestry and agriculture use (lawns and gardens) to save the ... -
Page 4: Precautions Before Use
Do not use plant protection products Do not connect this sprayer to other equipment. The precautions are divided into three categories: "DANGER", "WARNING" and "CAUTION". If there is a possibility of serious injury or death in case of violation of the indication DANGER! If there is a possibility of serious injury or serious injury in case of violation of the... - Page 5 d. If the wind suddenly picks up during use, turn the sprayer in the direction of the wind and, if necessary, stop working. e. Considering the different parameters such as nozzles, pressure, spray height, wind speed, please follow our recommendations to choose the nozzle. WARNING! Please tighten the cap tightly so that the tank lid does not leak.
-
Page 6: Symbols Explanation
cause overheating and damage to the battery. d. Do not repair or modify the charger and battery. There is a danger of electric shock or fire. Be sure to apply for repair at the retailer you purchased or A / S. e. -
Page 7: Product Description
Do not dispose of batteries in water. Do not dispose of batteries in fire. They could explode and cause injury. keep bystanders away when spraying. 2. PRODUCT DESCRIPTION... -
Page 8: Preparation Before Use
3. PREPARATION BEFORE USE CAUTION! Make sure that there is a packing at the joined part as shown in the fig. Please join tightly so that the liquid would not leak 1) Unpacking and conformation of auxiliary parts Since all products go through test before shipping, there can be some water left in the sprayer ... - Page 9 CAUTION! Please join the hose to the main body tightly so that the liquid would not leak. CAUTION! A handle is located on the tank cap, it is used to lift and carry the full sprayer. Before use, adjust the shoulder strap as following. a.
-
Page 10: How To Use
Battery charge gauge The battery gauge indication is as following. Please correctly use it by checking the gauge during spraying or charging. a. When only “L” light is on: Voltage is low. Please charge the battery b. When “L” light and “N” light are on: The battery voltage is normal for use. c. - Page 11 CAUTION! Please remember that the spray pressure is always “high pressure” when using the power switch. If you turned on the sprayer using the power switch, the pressure control switch does not work. If you want to control the pressure, turn off the sprayer by the power switch and turn on again using the pressure control switch.
-
Page 12: After-Use Check And Storage
clockwise, the particles become smaller. We recommend this nozzle for insecticide on fruit trees because this nozzle sprays farther (to long distance) with bigger particles.(Pressure 0.01-0.56Mpa, flow rate 0.65-1.5 L/min) d. 8-opening nozzle This nozzle sprays the liquid in small eight circular shapes as shown in the figure. We recommend this nozzle for insecticide on lawns because this nozzle sprays bigger areas. -
Page 13: Self-Check Before Asking Service
CAUTION! For storage longer than six months, the battery should be fully charged every 2-3 months. If the battery discharges completely, its life will quickly decrease and charging will be difficult. CAUTION! The storage place should not get direct sunlight and has good ventilation. CAUTION! The charger and battery should be kept in safe place not reachable by children. -
Page 14: Declaration Of Conformity
ZI, 32 RUE ARISTIDE BERGES – 312070 CUGNAUX – FRANCE Declares that the machinery designated below : CORDLESS SPRAYER Mod el: RACPVD16L Serial number : 20241106251-20241110036 Complies with the provisions of the Directive « machinery » 2006/42/CE and national laws... -
Page 15: Warranty
9. WARRANTY The manufacturer guarantees the product against defects in material and workmanship for a period of 2 years from the date of the original purchase. It can be extended by one year if the user subscribes to website of myswap. The warranty only applies if the product is for household use. The warranty does not cover breakdowns due to normal wear and tear. -
Page 16: Product Failure
10. PRODUCT FAILURE WHAT TO DO IF MY MACHINE BREAKS DOWN? If you bought your product in a store: • Make sure that your machine is complete with all accessories supplied, and clean! If this is not the case, the repairer will refuse the machine. •... -
Page 17: Warranty Exclusions
11. WARRANTY EXCLUSIONS THE WARRANTY DOES NOT COVER: • Start-up and setting up of the product. • Damage resulting from normal wear and tear of the product. • Damage resulting from improper use of the product. • Damage resulting from assembly or start-up not in accordance with the user manual. •... - Page 18 BUILDER SAS 32 rue Aristide Bergès - Z.I. du Casque - 31270 Cugnaux - France MADE IN PRC...
