- Page 1 NEXUS WALL CABINET ASSEMBLY Also applies to: Galaxy, Nexus, Ridgeline, Statesman, and Waterford Series...
-
Page 2: What You Will Need
NEXUS SERIES CABINETS STANDARD WALL ASSEMBLY INSTRUCTIONS Also applies to: Galaxy Series, Nexus Series, Ridgeline Series, Statesman Series, and Waterford Series FOR YOUR INFORMATION: These assembly instructions serve as a general guideline for most wall cabinets. While the assembly method is basically consistent across cabinet types, the sizes, confgurations, number of shelves, and number of doors may vary. - Page 3 B. SLIDING IN THE SIDE PANELS 1. With the face frame lying face down on the protected surface, run a modest bead of glue in the dovetailed channel . 2. Slide the side panel into the groove you just glued. Be sure that the fnished side is facing outside.
- Page 4 D. FASTENING THE BACK PANEL 1. Apply glue to the two grooves on the back panel. 2. Apply a bead of glue onto the notched edges of both side panels. 3. Place the back panel into place, lining up the grooves of the back panel with the top and bottom panel edges.
- Page 5 G. HANGING THE CABINET DOOR Determine whether a left-hinged or a right-hinged door is desired. 1. Screw each hinge to the face frame of the cabinet, using the pre-drilled holes as a guide. The hinges can be adjusted by the installer to ensure that the doors are straight. H.
