- Page 1 ID-Lock UZ Installation guide...
-
Page 2: Table Of Contents
ID-Lock UZ Installation guide - Version 1.0 Contents ID-Lock UZ Overview......................3 Advantages .......................... 3 What is ID-Lock UZ? ......................3 How does ID-Lock UZ work? ..................... 4 Installation of ID-Lock UZ ....................... 5 Before you begin ......................... 5 Installation of the TM2-box ....................6 Installation of the IDT ...................... -
Page 3: Id-Lock Uz Overview
You can always open doors in an ID-Lock UZ installation from the inside by just using the door handle without any key or transmitter, while the outside handle only works when the door is unlocked. -
Page 4: How Does Id-Lock Uz Work
ID-Lock UZ Installation guide - Version 1.0 How does ID-Lock UZ work? The IDT, which is mounted next to each door, is transmitting an RFID signal with a zone-ID that is unique to each door. The signal has a maximum range of approx. 1 to 1.5 meters (adjustable down to a few centimeters). -
Page 5: Installation Of Id-Lock Uz
(the square rod that connects the two handles on each side of the door) with an appropriate length. There are three different length of spindles that can be ordered from Tunstall: • Part no. 062 09 201 for doors 30-56 mm thick •... -
Page 6: Installation Of The Tm2-Box
ID-Lock UZ Installation guide - Version 1.0 Installation of the TM2-box This is one example how you may mount the TM2-box. Other examples are to mount it inside a plastic box or hide it above the ceiling. Make a simple mounting plate by using a metal- or plastic plate that you drill holes in and attach to the TM2 box with 7 mm wide screws made for plastic as illustrated here. -
Page 7: Installation Of The Idt
ID-Lock UZ Installation guide - Version 1.0 Installation of the IDT The IDT should be mounted next to the door, preferably close to the lock. If there are several doors next to each other in, e.g., a corridor, then it is important that all IDTs are mounted on the same side of their respective door. -
Page 8: Installation Of A Carelock Uz Handle
ID-Lock UZ Installation guide - Version 1.0 Installation of a Carelock UZ handle Assembling the spindle Carelock UZ Spiral clamping Spindle The spindle must be assembled before you can mount Carelock UZ on a door. Insert the spindle onto the square hole in Carelock UZ. Make sure it is pushed all the way in and then insert the spiral clamping pin into the spindle as shown here. -
Page 9: Additional Information
Additional information Any updates of this guide, as well as an installation guide for TM2 and the configuration app that is required for configuring and testing the ID-Lock UZ system, will be available in https://tunstalldownload.com/carelock/uz. The name of the configuration app is “Carelock Config Light”. It is only available for Android phones, running Android 7 or later. - Page 10 Our policy of continual development means that product specification and appearance may change without notice. Tunstall does not accept responsibility for any errors and omissions within this document. © 2023 Tunstall Group Ltd. Tunstall is a registered trademark. ®...
