  • Page 1 ID-Lock Smart Installation guide Version 1.3...

  • Page 2: Table Of Contents

    ID-Lock Smart Installation guide - Ver. 1.3 Contents ID-Lock Smart Overview ......................3 Advantages ........................3 What is ID-Lock Smart? ..................... 3 How does ID-Lock Smart work? ..................4 Installation of ID-Lock Smart ....................5 Package contents with part numbers ................5 Split mechanics (036-01-835 or 036-01-836) ..............

  • Page 3: Id-Lock Smart Overview

    • What is ID-Lock Smart? ID-Lock Smart is a lock system that prevents unwanted access to rooms in a nursing home or similar indoor environments. It is not designed for high security applications, such as external doors to a resident home or office.

  • Page 4: How Does Id-Lock Smart Work

    ID-Lock Smart Installation guide - Ver. 1.3 How does ID-Lock Smart work? The IDT, which is mounted next to each door, is transmitting an RF signal with a zone-ID that is unique to each door. The signal has a range of approx. 1 to 1.5 meters. The IDT RF signal is marked in in the illustration below.

  • Page 5: Installation Of Id-Lock Smart

    ID-Lock Smart Installation guide - Ver. 1.3 Installation of ID-Lock Smart Package contents with part numbers This is what a complete ID-Lock Smart package should contain, including part numbers for individual sub-kits: Split mechanics (036-01-835 or 036-01-836) See exploded view on the next page for more details.

  • Page 6: Exploded View Of The Split Mechanics

    ID-Lock Smart Installation guide - Ver. 1.3 Exploded view of the Split mechanics Item Name Satellite bottom Top cabinet Main spindle Circlip Wire sleeve Tooth module Support roller Steel wire Spring Outer wire sleeve Outer spacer Outer spindle Limit bracket...

  • Page 7: Tools Needed For Installation

    ID-Lock Smart Installation guide - Ver. 1.3 Tools needed for installation These are things you will need when you install ID-Lock Smart. In addition to this, you may need a large cutter or hacksaw to cut the screws. You will also need wires and a power supply for the TM2-box and IDT, some means of fastening the TM2-box (see below for an example) and finally the ID-Lock Config app for Android.

  • Page 8: Installation Of The Idt

    ID-Lock Smart Installation guide - Ver. 1.3 Carelock ACE Split has the optional feature that it will unlock the door 10 seconds after it loses its Bluetooth connection to the TM2-box. The idea behind this feature, which is enabled by default, is to function as a security measurement in case of fire; you connect the TM2-box’s power supply to a power source that will be cut off by the fire alarm.

  • Page 9: Step By Step Installation Of The Carelock Ace Split

    ID-Lock Smart Installation guide - Ver. 1.3 Step by step installation of the Carelock ACE Split Step 1 Remove the inside thumbturn knob… …and the exterior cylinder housing, which is fastened with the same screws.
  • Page 10 ID-Lock Smart Installation guide - Ver. 1.3 Step 2 Unscrew the thumbturn spindle bracket. The lock cylinder on the doors exterior is fastened with the same screws as the thumbturn spindle bracket, so you want to hold the lock cylinder in place while you remove the screws.
  • Page 11 ID-Lock Smart Installation guide - Ver. 1.3 …and remount the bracket with the same screws that also holds the lock cylinder. Step 3 Remove the handles and the spindle.
  • Page 12 ID-Lock Smart Installation guide - Ver. 1.3 Step 4 Prepare the satellite part by first mounting the support roller and then sliding on the tooth module. Step 5 Mount the circlip on the outer spindle.
  • Page 13 ID-Lock Smart Installation guide - Ver. 1.3 Step 6 Place the steel wires inside the outer wire sleeve. Step 7 Temporarily use the outer spindle to hold the steel wires in place by sliding it into the outer wire sleeve.
  • Page 14 ID-Lock Smart Installation guide - Ver. 1.3 Step 7 Slide the spring on to the outer wire sleeve. Step 8 Thread the outer wire sleeve assembly through the door from the outside.
  • Page 15 ID-Lock Smart Installation guide - Ver. 1.3 Step 9 Mount the satellite assembly from the inside of the door and let the steel wires go through the tooth module. It is easier to do this if you first rotate the satellite assembly and then adjust it to a vertical position.
  • Page 16 ID-Lock Smart Installation guide - Ver. 1.3 Step 11 Mount the circlip onto the main spindle… …followed by a shim washer.
  • Page 17 ID-Lock Smart Installation guide - Ver. 1.3 Step 12 Now press the main spindle assembly through the top cabinet. It may be a narrow fit, so some light force may be needed. Step 13 Mount the other shim washer…...
  • Page 18 ID-Lock Smart Installation guide - Ver. 1.3 …and the last circlip onto the main spindle in order to secure the top cabinet. Step 14 Slide the top cabinet assembly through the door. Rotate the main spindle so that the steel wires can slide through the cavity in the main spindle.
  • Page 19 ID-Lock Smart Installation guide - Ver. 1.3 Step 15 Spray a little lithium grease on the threaded end of the main spindle and inside the outer wire sleeve. Step 16 Now press the outer wire sleeve toward the door and, while holding it depressed, turn the cogwheel that protrudes from the bottom of the top cabinet assembly clockwise.
  • Page 20 ID-Lock Smart Installation guide - Ver. 1.3 Step 17 Screw on the outer spindle until it comes to a stop, then unscrew it between 180 to 270 degrees (½ to ¾ of a turn), and make sure it is aligned with the main spindle (the outer wire sleeve should be able to slide over the outer spindle).
  • Page 21 ID-Lock Smart Installation guide - Ver. 1.3 Step 19 Place the door plate on the outside of the door… …and remount the exterior cylinder housing that will keep the door plate in place.
  • Page 22 Step 20 Mount the new handles from the ID-Lock Smart kit, starting with the inside of the door. You may have to cut the screws to fit the thickness of your door. It is easier to start with one screw already threaded through the handle (the right-hand screw in the picture below) or both screws, before you try to push the screws through the door.
  • Page 23 ID-Lock Smart Installation guide - Ver. 1.3 Step 21 Mount the outer spacer after both screws are through the door. This is when you determine if you need to cut the screws to the right length; the screws should not protrude beyond the outer spacer more than 4 mm.
  • Page 24 ID-Lock Smart Installation guide - Ver. 1.3 Step 23 Mount the outer handle and the nipples. Step 24 Tighten the screws holding the exterior cylinder housing and cover plate.
  • Page 25 ID-Lock Smart Installation guide - Ver. 1.3 Step 25 Mount the Carelock ACE Split unit with the Torx screw from the kit.
  • Page 26 ID-Lock Smart Installation guide - Ver. 1.3 Step 26 Mount the battery in the battery cabinet as shown here. Note that the battery should slide into the cabinet with the cable first. Step 27 Snap the battery cabinet to the Carelock ACE Split unit after attaching the battery...

  • Page 27: Additional Information

    Tx75 transmitters There are many different Tx75 transmitters and most of them can be reprogrammed to act in different ways. The recommended types of transmitters and their IDs for ID-Lock Smart are: • K2315-ID4 or K2315-ID2 with IDs between 1 and 927 for residents •...
