MODEL 600015FRC
AUTOPSY CARRIER
w/FRONT AND REAR ELEVATION
CAUTION
• Inspect unit and all components
for any loosening that may have
occurred during shipping •
ATTENTION
Review entire manual before
starting assembly
Mortech™ Manufacturing Inc.
411 North Aerojet Avenue, Azusa, CA 91702
(626) 334-1471 www.mortechmfg.com
™
Technical Users' Manual
Installation and Operating Instructions
ISO Doc. #OM600015FRC (REV C)
JULY 2010
Advertisement
Table of Contents
Related Manuals for MORTECH 600015FRC
Summary of Contents for MORTECH 600015FRC
- Page 1 ™ Technical Users’ Manual Installation and Operating Instructions MODEL 600015FRC AUTOPSY CARRIER w/FRONT AND REAR ELEVATION CAUTION • Inspect unit and all components for any loosening that may have occurred during shipping • ATTENTION Review entire manual before starting assembly JULY 2010 Mortech™...
-
Page 2: Safety Information
• Do the moving parts operate smoothly? Modifying the equipment can cause injury and damage. • Is unit draining properly? Use the equipment only as designed by Mortech. • Are all nuts, bolts, and pins secured in place? If unit has an issue contact customer relations. -
Page 3: Parts Listing
STANDARD DESIGN FEATURES: Design Load: 500 lbs • Fabricated from 1.5 inch square, 11 gauge, 304 The Model 600015FRC Autopsy Carrier Series is stainless steel tubing designed for use with our stainless steel cadaver trays. It is • Stainless steel has a grained finish and all welds... -
Page 4: Operation
Pull handle outward to elevate head end of the carrier only. To lower keep handle in the same position and rotate lever counterclockwise. Lowered position with T3614 tray 600015FRC in a raised position JULY 2010 MFGISO DOC. #OM600015FRC (REV. C) - Page 5 600015FRC Autopsy Carrier Parts listing w/Front & Rear Height Elevation 600015FRC TABLE POSITIONS DRIVE SHAFT Raising both ends COUPLERS ENGAGED TO RAISE AND LOWER BOTH ENDS OF CART, PUSH HANDLE SO DRIVE SHAFT COUPLERS ARE ENGAGED AND TURN HANDLE IN DESIRED DIRECTION.
- Page 6 TURN Parts listing 600015FRC Autopsy Carrier w/Front & Rear Height Elevation 600015FRC TABLE POSITIONS Raising head ends DRIVE SHAFT COUPLERS DISENGAGED TO RAISE AND LOWER FRONT OF CART ONLY, PUSH HANDLE SO DRIVE SHAFT COUPLERS ARE DISENGAGED AND TURN HANDLE IN DESIRED DIRECTION.
-
Page 7: Troubleshooting
Hand crank assembly is designed to operate smoothly. If tension occurs or lever becomes difficult to rotate call Mortech Mfg. Inc. for assistance. Lever will stop when height is exhausted and lowest level is reached. DO NOT FORCE LEVER WHEN IT STOPS AT MAXIMUM OR MINIMUM HEIGHT. - Page 8 Parts listing 600015FRC Autopsy Carrier w/Front & Rear Height Elevation 600015FRC TRAY ASSEMBLY TABLE SLOTS PLACE THE TRAY ON THE TABLE BY LINING UP THE TABLE SLOTS AND LOWERING. PLACE DRAIN TO THE FOOT END OF THE TABLE. JULY 2010...
- Page 9 600015FRC Autopsy Carrier Parts listing w/Front & Rear Height Elevation MODEL T3614 A real time and energy saver, the detachable stainless steel top will ensure a secure fit with no mechanical fastening devices required. It is fabricated from 14 gauge 304 stainless steel with No.
-
Page 10: Component Data
METRIC CAP M8 X 1.25 X 50L Brake Lock METRIC NYLOC NUT Brake Lock Release TIGHTEN AND SECURE Mortech™ Manufacturing Inc. 411 North Aerojet Avenue, Azusa, CA 91702 (626) 334-1471 www.mortechmfg.com... -
Page 11: Maintenance Instructions
600015FRC Autopsy Carrier Maintenance w/Front & Rear Height Elevation MAINTENANCE INSTRUCTIONS Shop Oil and Grease - These soils may be corrosive and may not allow the surface to maintain passivity, and so MAINTENANCE SCHEDULE removal is a necessity. Soap or detergent and water may be The unit requires regular maintenance and follow the used or a combination of detergent and water plus a solvent. -
Page 12: Maintenance Record
Maintenance record 600015FRC Autopsy Carrier w/Front & Rear Height Elevation MAINTENANCE RECORD Date JULY 2010 MFGISO DOC. #OM600015FRC (REV. C) -
Page 13: Training Record
600015FRC Autopsy Carrier Training record w/Front & Rear Height Elevation TRAINING RECORD Date JULY 2010 MFGISO DOC. #OM600015FRC (REV. C) -
Page 14: Warranty
Customer Relations. FAX (626) 334-1704 www.mortechmfg.com PROPRIETARY NOTICE info@mortechmfg.com The information in this manual is the property of Mortech © COPYRIGHT MORTECH MANUFACTURING INC., ALL Manufacturing. Mortech Manufacturing reserves all patent RIGHTS RESERVED. rights, proprietary design rights, manufacturing rights,...
