MODEL 600038
AUTOPSY CARRIER
w/ROLLERS
CAUTION
• Inspect unit and all components
for any loosening that may have
occurred during shipping •
ATTENTION
Review entire manual before
starting assembly
ATTENTION
All images and Drawing in this manual
may not represent your model.
Refer to your particular project for
exact specifications
Mortech™ Manufacturing Inc.
411 North Aerojet Avenue, Azusa, CA 91702
(626) 334-1471 www.mortechmfg.com
Technical Users' Manual
Installation and Operating Instructions
CAUTION
DO NOT USE CLEANERS
•
CONTAINING CHLORINE WHEN
CLEANING STAINLESS STEEL
•
Advertisement
Table of Contents
Related Manuals for MORTECH 600038
Summary of Contents for MORTECH 600038
- Page 1 Technical Users’ Manual Installation and Operating Instructions MODEL 600038 AUTOPSY CARRIER w/ROLLERS CAUTION CAUTION • Inspect unit and all components DO NOT USE CLEANERS • for any loosening that may have CONTAINING CHLORINE WHEN occurred during shipping • CLEANING STAINLESS STEEL •...
-
Page 2: Safety Information
• Is unit draining properly? WARNING • Are all nuts, bolts, and pins secured in place? It is crucial that any work performed on Mortech If unit has an issue contact Mortech Manufacturing Inc. Manufacturing Inc. manufactured items are carried out... -
Page 3: Equipment Description
CONSTRUCTION (4) Ø8" CASTER WHEEL w/BRAKE MECHANISM The Model 600038 Stainless Steel Autopsy Carrier with STANDARD DESIGN FEATURES: Rollers is designed as an integral part of the Total Roll • Stainless steel has a grained finish and all welds match System for cadaver handling. -
Page 4: Operation
Operation 600038 Autopsy Carrier w/Roller OPEN Open Position LOCKED Tray strop mechanism Rotate tray mechanism to the open position. Slide tray onto carrier. Rotate tray stop mechanism to the closed position to lock tray. Removal of tray is same operation. - Page 5 600038 Autopsy Carrier w/Roller Operation Total Roll Cadaver Handling System All equipment in the system incorporates roller assemblies which allow for easy tray transfer from one component to the next. No manual lifting is required and in many instances only one person is required to complete the transfer.
- Page 6 Series T3626 Standard Body Tray Series 86-129 Mortuary Rack System w/Rollers, M678 Hydraulic Cadaver Lift, Series T3614 Stainless Steel Autopsy Tray Series 600038 Standard Autopsy Carrier w/Rollers, M677 Hand Crank Cadaver Lift, Series T3626 Standard Body Tray Series 600038 Standard Autopsy Carrier w/Rollers,...
-
Page 7: Component Data
METRIC CAP M8 X 1.25 X 50L Brake Lock METRIC NYLOC NUT Brake Lock Release TIGHTEN AND SECURE Mortech™ Manufacturing Inc. 411 North Aerojet Avenue, Azusa, CA 91702 (626) 334-1471 www.mortechmfg.com... - Page 8 It features a depressed pattern allowing fluids to drain easily. Length: .....82 inches Height: .....1.5 inches Width:....31 inches Shipping wt: ..95 lbs. Design load: ..500 lbs. All measurements in inches Mortech™ Manufacturing Inc. 411 North Aerojet Avenue, Azusa, CA 91702 (626) 334-1471 www.mortechmfg.com...
-
Page 9: Spare Parts List
600038 Autopsy Carrier w/Roller Spare parts list PART#/SPARE PART# MANUFACTURER PART#/SPARE PART# ASSEMBLY, Roller, single M-122 Roller, nylon Mortech Manufacturing Inc. M-122 AA710-03 Bushing, bronze Mortech Manufacturing Inc. AA710-03 M-123 Spacer, roller Mortech Manufacturing Inc. M-123 End Uprights Shaft, STS-434... -
Page 10: Equipment Maintenance
600038 Autopsy Carrier w/Roller Equipment maintenance MAINTENANCE INSTRUCTIONS EFFECTIVE CLEANING METHODS Commercial Cleaners - Many commercial cleaners The unit requires regular maintenance and follow the compounded from phosphates, synthetic detergents, and manufactures directions. alkalis are available for the cleaning of severely soiled or DISINFECTING AND CLEANING stained stainless surfaces. -
Page 11: Maintenance Record
600038 Autopsy Carrier w/Roller Maintenance record MAINTENANCE RECORD Date... -
Page 12: Training Record
Training record 600038 Autopsy Carrier w/Roller TRAINING RECORD Date... -
Page 13: Warranty
Manufacturing. Inc. will receive the manufacturer’s warranty. Information in this Manual is subject to change without notice and does not represent a commitment on the part of Mortech PARTS AND SERVICE Manufacturing. Inc. Mortech Manufacturing. Inc. assumes Customer relations and product support are important no responsibility for any inaccuracies that may be contained aspects of Mortech Manufacturing.
