MODEL 600039C
COVERED CADAVER
CARRIER
CAUTION
Inspect unit and all components for
any loosening that may have
occurred during shipping
ATTENTION
Review entire manual before
starting assembly
ATTENTION
All images and Drawing in this manual
may not represent your model.
Refer to your particular project for
exact specifications
Mortech™ Manufacturing Inc.
411 North Aerojet Avenue, Azusa, CA 91702
(626) 334-1471 www.mortechmfg.com
Technical Users' Manual
Installation and Operating Instructions
CAUTION
DO NOT USE CLEANERS
CONTAINING CHLORINE WHEN
CLEANING STAINLESS STEEL
WARNING
Biohazard Label is place on the
equipment signifying the potentially
infectiousness due to the samples
or reagents
Advertisement
Table of Contents
Related Manuals for MORTECH 600039C
Summary of Contents for MORTECH 600039C
- Page 1 Technical Users’ Manual Installation and Operating Instructions MODEL 600039C COVERED CADAVER CARRIER CAUTION CAUTION Inspect unit and all components for DO NOT USE CLEANERS any loosening that may have CONTAINING CHLORINE WHEN occurred during shipping CLEANING STAINLESS STEEL ATTENTION WARNING...
-
Page 2: Safety Information
• Is unit draining properly? WARNING • Are all nuts, bolts, and pins secured in place? It is crucial that any work performed on Mortech If unit has an issue contact Mortech Manufacturing Inc. Manufacturing Inc. manufactured items are carried out... -
Page 3: Equipment Description
Equipment description 600039C Covered Cadaver Carrier The unit allows for a concealed removal/transport of a deceased patient from the hospital room to the morgue. The carrier gives the illusion of being a standard empty gur- ney while hiding the cadaver beneath a specially fabricated top cover. -
Page 4: Parts Listing
Parts listing 600039C Covered Cadaver Carrier 600039C COVERED CADAVER CARRIER USE AND OPERATION - Deceased Removal Hydraulic Carrier Base should be placed in lowest position. - Aluminum Top Frame should be set in place over deceased. - Cover should be placed over Aluminum Top Frame... - Page 5 Parts listing 600039C Covered Cadaver Carrier 600039C HAND CRANK ASSEMBLY - Table can be raised by clockwise motion and lowered in a counter-clockwise motion - Hand crank assembly is designed to operate smoothly. - If tension occurs or lever becomes difficult to rotate call Mortech Mfg.
- Page 6 Parts listing 600039C Covered Cadaver Carrier MODEL 600039C HAND CRANK ASSEMBLY 1. THREADED SHAFT 2. BEARING HOUSING 3. ROLLER BEARING 4. SPIRAL GEAR 5. CRANK HANDLE 6. CRANK HANDLE ARM 7. CRANK SHAFT 8. BRONZE BUSHING 9. BUSHING HOUSING 10. CRANK GEAR 11.
- Page 7 Parts listing 600039C Covered Cadaver Carrier FABRIC COVER MODEL 600039 CADAVER CARRIER Remove fabric covering and aluminum cover frame by lifting off of carrier tray. Situate carrier next to bed and apply brakes on caster wheels. (Figure-1) Using crank handle, raise carrier tray to bed top height and transfer cadaver to carrier top.(Figure-2)
-
Page 8: Operation
Operation 600039C Covered Cadaver Carrier USE AND CARE FOR CASTERS 1. To engage brake mechanism, press gray tab down, until you feel it lock. To release brake mechanism, press forward to 3/4” X 25/32” 45º OFFSET WRENCH return to full range of motion. Mechanisms are located on all (4) wheels. - Page 9 Operation 600039C Covered Cadaver Carrier DIRECTIONAL CASTERS USE & CARE: 1. To engage directional locking mechanism, press GREY tab down and straighten/adjust wheel to lock in direction. To disengage multi- directional movement, PUSH down GREEN tab located on wheel. 2. When unit is in use, all necessary wheels METRIC CAP M8 X 1.25 X 50L...
-
Page 10: Maintenance Instructions
Stainless steel equipment maintenance MAINTENANCE INSTRUCTIONS had time to oxidize or decompose. The preferred solvent is one that does not contain chlorine, such as acetone, methyl The unit requires regular maintenance and follow the alcohol, and mineral spirits. manufactures directions. EFFECTIVE CLEANING METHODS DISINFECTING AND CLEANING Commercial Cleaners - Many commercial cleaners... -
Page 11: Maintenance Record
Maintenance record MAINTENANCE RECORD Date... -
Page 12: Training Record
Training record TRAINING RECORD Date... -
Page 13: Warranty
PARTS AND SERVICE Information in this Manual is subject to change without notice Customer relations and product support are important and does not represent a commitment on the part of Mortech aspects of Mortech Manufacturing. Inc. Manufacturing. Inc. Mortech Manufacturing. Inc. assumes...
