- Page 1 Quick Start Guide AVC450 Amber Vision C450 Multi-Channel 4G DashCam Install Your device Download Amber Connect Activate the device...
-
Page 2: Appearance Description
1. Overview of Product Appearance 1.1. Appearance Description Description Description Front camera Memory card slot 1 Speaker Memory card slot 2 Wire harness External camera interface Status indicator USB port Microphone Upgrade operation hole Device cooling area Reset hole SIM card slot Mounting support 1.2. - Page 3 2.2. Optional External camera with internal recording Mounted in the vehicle, it is used for recording the internal environment of the vehicle. Pull-out waterproof camera Mounted outside the vehicle, it is used for recording the external environment of the vehicle. Pull-out DMS camera It is used for extension when the mounting distance is far from the host.
-
Page 4: Product Features
3. Overview of product functions AVC 450 is a 4G dashboard camera specially designed for commercial vehicles. It is equipped with four recording cameras, which can record video footage for multi views and multi scenes during driving. Provided with the visual AI function, it can support simultaneous computation of ADAS and DMS, so that it can analyze the early warning of the road conditions in front of the vehicle and the status of the driver in the vehicle and thus provide an alarm, so as to ensure driving safety and prevent potential hazards. -
Page 5: Product Performance
3.3. Product performance Performance Parameter Performance Parameter Working voltage 9-30V Under voltage protection Working temperature –20˚C-70˚C Overvoltage protection Storage temperature –30˚C-85˚C Reverse connection Support protection ESD protection Air ±14KV; Flame retardant UL94 V-0 contact ±7KV 4. Product installation 4.1 Notices This product is not applicable to battery electric vehicles and hybrid electric vehicles. -
Page 6: Product Wiring Diagram
4.4. Product wiring diagram Installation description The description of all harnesses is shown in the Figure above. Please check the procured accessories and connect and install them according to actual conditions. When installing the DMS camera, please connect it with the Camera B interface. ... -
Page 7: Camera Installation
Step 4: Install the device onto the base and connect it with the power cable. Refer to Figure 4.6. Camera installation AVC450 device can support simultaneous connection of up to 4 cameras; among them, the front camera is the built-in main body and the other three cameras can be selected and installed according to actual needs of the vehicle. -
Page 8: Device Testing
3. R232 installation (optional) It is used for connecting an external device. When the device itself cannot meet the application scenes, it can be connected with external professional device through the serial port to achieve the expansion function. 4.8. Device testing 1. -
Page 9: Remote Function
automatically. It can get the geographical location of the vehicle and upload the data to the platform. Event monitoring When the device is in operation, it can monitor the vehicle speed, gravitational acceleration, status of the driver and vehicle driving and etc.; when any abnormal condition occurs, the device will issue an alarm to remind the driver and upload the event to the platform for storage of geographical location and picture/video evidence. -
Page 10: Special Note
platform. 7. It is easy for the flat camera to loosen after angle adjustment. All cameras of C450 can be adjusted, with the support of adjustment locking. Please tighten the locking screw nearby after adjusting the lens angle to the appropriate position. - Page 11 Maintenance Record Service Start Date Problem and Solution Service End Date Customer Signature Important Please keep this warranty card in a safe place, as it is the proof for one-year free warranty services. If this card is lost, the Company will determine the date of purchase to be the thirtieth (30th) day after the date of production.
