- Page 1 Quick Start Guide AVC425 Amber Vision C425 Dual AI 4G Telematics HD Dashcam Install Your device Download Amber Connect Activate the device...
-
Page 2: Packing List
Introduction Packing List Please check the product model you purchased carefully as the packing list varies with the model. Overview AVC425 series uses 4G network for communication. For these dual-channel digital video recorders (DVRs), except to be able to record simultaneously, the two cameras can also record locally and live stream remotely at the same time. - Page 3 Appearance and LEDs Main Unit Product Model: AVC425/AVC420 main unit Camera: 1920x1080/25FPS/F 2.2/Full color Subcamera Options AVC420 Integrated Version Product Model 1280x720/15FPS/F2.5/Full c o l o r i n d a y t i m e a n d Camera monochrome in dim light No r e m o t e c a m e r a...
- Page 4 AVC425 DMS Version Product Model 1280x720/15FPS/F2.0/Full Camera c o l o r i n d a y t i m e a n d mo n o c h r o m e in di m li g h t Usage Monitor the cabin AVC425...
- Page 5 GSM and GPRS networks are On for 5s and off for 1s available, but connection to server failed On for 1s and off for 1s Only GSM network is available GSM network is unavailable Solid on Location succeeded GNSS Green Device is locating/location On for 1s and off for 1s failed...
-
Page 6: Specifications And Features
Specifications and Features Specifications Category Item Parameter Remarks Hardware Memory 1GB+16GB AVC425-E FDD:B1/B3/B5/B7/B8/B9/B20 IDD:B38/B39/B40/B41(100M ) WCDMA: B1/B2/B5/B8 GSM: 850/900/1800/1900 AVC425-LA FDD: B2/B3/B4/B5/B7/B12/B17 IDD: B38/B41(100M) WCDMA: B2/B4/B5 GSM: 850/1800/1900 WiFi 2.4 GHz 802.11/b/g/n GNSS Support GPS/BDS Microphone Support For remote voice communication Speaker Support To notify drivers of status or events... -
Page 7: Installation
Note: For details about features, refer to the operation guide. Installation Precautions: This device is not suitable for battery electric vehicles (BEVs) and hybrid electric vehicles (HEVs). Use accessories specified by the manufacturer only. The standard supply for the device is DC9~30V, please use the original power cable and ensure that 1he positive and negative ends are correctly wired. -
Page 8: Main Unit Installation
Note: Fit the Nano-SIM into the tray and insert them into the SIM slot. To remove the card tray, use the ejector tool. TF Card Attachment Ensure that the device is ACC OFF before attaching a proper TF card. Note: ... -
Page 9: Installation Of Accessories
Route the power cable along the A pillar of the vehicle to the upper center of the front windshield. The red dashed line ( ) in the figure is for reference. Select a proper installation position and wipe the position clean. Remove the protective film from the 3M tape of the mounting base and attach it to the position. - Page 10 Face the camera inward and install it to the windshield behind the rear-view mirror (as shown in ① ) or to the middle of the dashboard (as shown in ② ). Wipe a selected position clean, remove the protective film from the 3M tape, and attach the device.
-
Page 11: Other Accessories
Other·Accessories SOS key It is used to seek help in emergencies. Connect the SOS key to the corresponding interface on the device, remove the protective film from the 3M tape, and then attach it to a proper position (such as ① in the above figure). ... - Page 12 2. Check the camera: The camera works correctly if you can view the live video of the camera and switch between the two cameras after logging in to the platform. You can also manually adjust the camera according to your needs.
