Summary of Contents for amber connect Amber Vision C410
-
Page 2: Start Guide
1. Start Guide Packing List... - Page 3 Please check the product model you purchased carefully as the packing list varies with the model. Overview AVC400 series uses 4G network for communication. For these dual-channel digital video recorders (DVRs), except to be able to record simultaneously, the two cameras can also record locally and live stream remotely at the same time.
- Page 4 2. Subcamera Options Product AVC400 Integrated Version Model 1280x 720/15 FPS/F2. 01 Full color in daytime and Camera monochrome light/No remote camera Usage Monitor the cabin AVC410 DMS Version Product Model 1280x720/15F P S/F2.0/ Camera Monochrome all day Monitor the driver's Usage head Refer to the specifications and features of the product model you purchased.
- Page 5 Device in sleep (ACC OFF) Solid on Network healthy GPRS LED Blue Network error Blink every 1s No SIM Device in sleep (ACC OFF) Fast blink< for 30s Vibrating alert triggered Defense LED Blue Blink every 10s Defense on Defense off 4.
-
Page 6: Specifications And Features
To provide 450mAh backup battery for the Battery External Battery device to protect it against power outage resulted from sudden power disconnection. 2. Specifications and Features 1. Specifications Category Item Parameter Remarks Hardware Memory 1GB+16GB Standard FDD: B1/B3/B5/B71B8/B9/B20 IDD: Version B38/B39/B401B41(100M ) WCDMA: B1/B2/B5/B8 GSM: 850/900/1800/1900... -
Page 7: Installation
via the platform (web or app) to remotely cut off the fuel and power to the vehicle when an exception occurs. Note: For details about features, refer to the operation guide. 3. Installation Precautions: This device is not suitable for battery electric vehicles (BEVs) and hybrid electric vehicles (HEVs). - Page 8 3.3 TF Card Attachment Ensure that the device is ACC OFF before attaching a proper TF card.
- Page 9 3.4 Main Unit Installation 1. Connect the power cable of the device to B+, ACC, and GND of the fuse box on the vehicle. is a reference position. 2. Route the power cable along the A pillar of the vehicle to the upper center of the front ...
- Page 10 3.5 Installation of Accessories You can select a proper position to install the remote camera according to actual conditions 3.5.1 Remote AHD Camera 1. Face the camera inward and install it to the windshield behind the rear-view mirror (as ...
- Page 11 3.5.3 Other Accessories External battery It is used to power the device for a while after its main supply is cut off. Connect the external battery to the corresponding interface on the device and place it in a proper position (such as in the above figure).
- Page 12 3.6 Commissioning heck the LED, see 1. C 1.3.3 for reference. 2. Check the camera: The camera works correctly if you can view the live video of the camera and switch between the two cameras after logging in to the platform. You can also manually adjust the camera according to your needs.
- Page 13 5. FAQ How will the Software be upgraded? Firmware can be upgraded by SD card/USB cable/OTA. The result is Ok, but no connectivity Data is displayed. Commamnd is "PING,HTTP" The device will respond to a network delay value, for example, "50ms"...
- Page 14 Aspect ratio:16:9; Resolution: 640*360 Are the Historical videos stored on your server or device only? The video recorded by the device is stored in two places, the main video stream(1920*1080) stored on TF card and sub video stream (640*360) stored on the device's internal storage.
