ZH 用户手册 / 组装说明
EN Instructions for use / assembly instructions
2
3
Talis Select E 240
Talis Select S 190
71752007
72044007

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Talis Select E 240 71752007 and is the answer not in the manual?

Questions and answers

Summary of Contents for Hans Grohe Talis Select E 240 71752007

  • Page 1 ZH 用户手册 / 组装说明 EN Instructions for use / assembly instructions Talis Select E 240 71752007 Talis Select S 190 72044007...
  • Page 2 中文 符号说明 安全技巧 请勿使用含有乙酸的硅胶! 装配时为避免挤压和切割受伤,必须戴上手 套。 调节 (参见第页 8) 本产品只允许作为洗浴、卫生和洁身之用。 冷热水管间过大的压力差必须予以平衡。 热水温度调节。如果使用即热式喷头,则不建议 安装热水阀门。 安装提示 保养 (参见第页 7) • 安装前必须检查产品是否受到运输损害。 安装 后将不认可运输损害或表面损伤。 单向阀必须在符合国家或当地的法律的情况下按 • 管道和阀门必须根据通用标准进行安装、冲洗 照DIN EN 1717定期检查 (至少一年一次) 。 和检查。 大小 (参见第页 14) • 请遵守当地国家现行的安装规定。 • 只能按规定使用溢流阀。禁止将半露柱及其他 流量示意图 (参见第页 14) 部件固定到溢流阀上。  ® 带有 EcoSmart • 如果使用即热式热水器时出现问题,或要求更  ® 无 EcoSmart 大的水流量,可以把位于水波器后面的 备用零件 (参见第页 12) EcoSmart ® (流量限制器) 拆除。...
  • Page 3: Safety Notes

    English Symbol description Safety Notes Do not use silicone containing acetic acid! Gloves should be worn during installation to prevent crushing and cutting injuries. Adjustment (see page 8) The product may only be used for bathing, hygienic To adjust the hot water limiter. Using a hot water limiter and body cleaning purposes. in combination with a continuous flow water heater is The hot and cold supplies must be of equal not recommended. pressures. Maintenance (see page 7) Installation Instructions • Prior to installation, inspect the product for transport The check valves must be checked regularly according damages. After it has been installed, no transport or to DIN EN 1717 in accordance with national or surface damage will be honoured. regional regulations (at least once a year). • The pipes and the fixture must be installed, flushed Dimensions (see page 14) and tested as per the applicable standards. • The plumbing codes applicable in the respective Flow diagram (see page 14) countries must be observed.  with EcoSmart ®  • The drain valve must only be used as intended. It is without EcoSmart ®...
  • Page 4 (3 Nm) 58085000 SW 19 mm SW 10 mm (4 Nm) SW 24 mm (max. 7 Nm) (4 Nm)
  • Page 5 58085000 (max. 7 Nm) (50 Ncm)
  • Page 6 SW 22 mm SW 22 mm (2 Nm) > 2 min 开 / open 关 / close 热 / hot 冷 / cold...
  • Page 7 SW 19 mm SW 10 mm SW 10 mm SW 19 mm (4 Nm)
  • Page 8 60 °C 10 °C 0,3 MPa 35°C 39°C 43°C 47°C 57°C 60°C...
  • Page 9 最大 / max. 至少 /min. (0,5 Nm)
  • Page 10 • • • • Hansgrohe • Hansgrohe • www.hansgrohe-int.com/guarantee • • QuickClean • QuickClean • • QUICK CLEAN...
  • Page 11: Warranty

    English Cleaning Recommendation for Hans- • After cleaning rinse thoroughly with clean water to remove any cleaner residue. grohe Products • The use of steam cleaners is not permitted. The high Today, modern sanitary and kitchen tapware, showers, temperatures can damage the products. accessories, washstands, tubs and radiators consist of Important very different materials to comply with the needs of the...
  • Page 12 Talis Select E 240 92525000 71752007 92526000 92528000 (M30x1,5) SW 28 mm 92527000 (27x1,5) 92529000 98194000 (28x2) EcoSmart® 98866000 98398000 98422000 (23x2) (7x1,5) 13185000 (M24x1 - 5 l/min) 96657000 95664000 (600 mm) 98749000 97548000 13961000 94139007 96456000 96324000 95291000 (340 mm) 93395000...
  • Page 13 Talis Select S 190 92525000 72044007 92526000 92528000 (M30x1,5) SW 28 mm 92527000 (27x1,5) 92529000 98398000 98866000 (23x2) EcoSmart® 98398000 98422000 (23x2) (7x1,5) 13185000 (M24x1 - 5 l/min) 96657000 95664000 (600 mm) 98749000 97548000 13961000 94139007 96456000 96324000 95291000 (340 mm) 93395000...
  • Page 14 Talis Select E 240 Talis Select S 190 71752007 72044007 Ø Ø 94139007 Ø Ø G 3 / 8 G 3 / 8 G 3 / 8 G 3 / 8 G 1 / 2 G 1 / 2 Talis Select E 240 0,60 0,55 71752007...
  • Page 16 Hansgrohe · Auestraße 5 - 9 · D-77761 Schiltach · Telefon +49 (0) 78 36/51-1282 · Telefax +49 (0) 7836/511440 E-Mail: info@hansgrohe.com · Internet: www.hansgrohe.com...
