Your machine doesn't need oil.
The vacuum pump is dry and
works with graphite pallets or
vanes that you will have to
replace every 6 or 8 months. It is
important to clean your machine
before using it. You can go to our
You Tube Channel "Mitty
Supply" and watch the video on
how to clean and disinfect your
machine prior to use.
Once your machine is cleaned
and ready to use, the first step
that you need to take is to adjust
your vacuum regulator.
Please notice that the latches
around the milk bucket are for the
metal transport lid, not for the
milking lid with the black gasket.
To make all of the connections to the
3E milking lids, please go to the page
titled, "HOW TO CONNECT THE
HOSES, BLACK PLUG AND
COW PULSATOR TO THE
MILKING LIDS."
Once you have made all
of the connections to the
3E milking lids, please
continue to the brochure
"How to Start Milking
for the First Time."
Assembly Instructions
for the Melasty TKM1-2PS
Portable Milking Machine
315 E. Banks St Glennville, GA
Advertisement
Related Manuals for melasty TKM1-2PS
Summary of Contents for melasty TKM1-2PS
- Page 1 Assembly Instructions Your machine doesn’t need oil. for the Melasty TKM1-2PS The vacuum pump is dry and Portable Milking Machine works with graphite pallets or Once you have made all vanes that you will have to of the connections to the replace every 6 or 8 months.
- Page 2 1. Unpack the machine, removing all 3. Insert the gauge on the top of the 5. Hang the cluster on the hook that contents. Take everything out of the rubber mount located on top of the is located on the back of the air box and milking bucket and stand the air tank.
- Page 3 HOW TO CONNECT THE HOSES, BLACK PLUG AND COW PULSATOR TO THE MILKING LIDS ILLUSTRATION 1 The buckets on your machine comes with 2 lids with 3 nozzles (entrances) on each of them. When you are milking your cow, this is how your hoses will connect to the nozzles (entrances) on the milking lids. Short Milk Hose Connect the cow pulsator to 5.
- Page 4 ILLUSTRATION 2 Short Milk Hose Pulsator Black Air Hose Y-Shape Fitting with Milk Hoses Connected Black Plug *This is the short hose, 4-5 inches long, that will *This is the milk be attached underneath stopper that will the same small nozzle attached underneath that the short milk hose the same big nozzle...
